SSV Brochure

KUBOTA SKID STEER LOADER

SSV65/SSV75

Excellent power and exceptional operator comfort bring new levels of

performance and productivity to Kubota’s SSV-Series Skid Steer Loaders.

Taking performance to all new

levels of comfort and efficiency

Outstanding performance, exceptional comfort, easy maintenance,

and excellent durability make Kubota’s new Skid Steer Loaders the

clear choice for the job.

SSV75

Engine HP Gross (SAE J 1995): 74.3 hp (55.4 kW)

Rated operating capacity (50% of tipping load):

2690 lbs. (1220 kg)

Bucket breakout force: 5884 lbs. (2669 kg)

Operating weight: 8157 lbs. (3700 kg)

SSV65

Engine HP Gross (SAE J 1995): 64.0 hp (47.7 kW)

Rated operating capacity (50% of tipping load):

1950 lbs. (885 kg)

Bucket breakout force: 4839 lbs. (2195 kg)

Operating weight: 6790 lbs. (3080 kg)

SKID STEER LOADER

●

Outstanding performance

● Exceptional comfort

● Easy maintenance

●

Powerful Kubota engine

The powerful and reliable Kubota-built

engine gets the job done quickly and easily

with 64.0 hp* (SSV65) or 74.3 hp* (SSV75).

* Engine HP Gross (SAE J 1995)

Injector

ECU

Sensor

SSV

Main

Control

Supply

pump

Common

Rail

Common

Rail

Supply

pump

Sensor

ECU

Tractor

Main

Control

Injector

OUTSTANDING

PERFORMANCE

Common Rail System and Diesel Particulate

Filter (DPF) Muffler

The Common Rail System (CRS) electronically controls the fuel injection timing and

amount in stages rather than all at once for optimal combustion; resulting in greater

efficiency, better fuel economy and less engine noise.

The combination of Exhaust Gas Re-circulation

(EGR) and Diesel Particulate Filter (DPF) reduces

the emissions making the SSV Series engine

Tier IV certified.

●

Automatic Regeneration System

Kubota's Automatic Regeneration System

burns away the soot that accumulates in the

DPF muffler to keep the muffler clean and let

you work longer. For safety, the automatic

regeneration

can be turned

off when

operating in

fire-prone areas.

Kubota engineKubota engine

Fresh air

Hot air

●

Electronic Travel Torque Management (ISO pilot control)

Electronic Travel Torque Management System lets you work faster

with more power. The ECU constantly monitors the load of the

machine to optimally control hydraulic pump output according to

the load, preventing engine stalls for smoother operation even

under severe conditions.

Stall!

OUTSTANDING

PERFORMANCE

Multi-function levers (optional)

The optional multi-function levers provide fingertip control of all major vehicle and attachment operations, including the main

hydraulic line and three electrical lines, letting you keep both hands on the levers at all times for optimal operating efficiency.

Cooling system and variable fan

A hydraulically driven fan optimizes cooling and engine efficiency

by varying the fan speed to maintain the appropriate water and oil

temperatures. In cold weather the fan turns more slowly, allowing

for faster engine warm-up.

●

Dial and foot throttle

The dial throttle is ideal for jobs that require

a constant engine speed, such as cold

planning, trenching, and snow blowing, and

conveniently located to let you change the

engine speed setting while operating the

levers. The foot throttle for ISO pilot control

lets the operator vary engine speed for

other applications.

A. Horn

B. KSR (Kubota Shockless Ride)

C. AUX1

D. AUX Mode Change or

Turn Signal

E. Travel Speed

F. AUX3

G. AUX2

H. Proportional Aux. Switch

I. AUX Hold Switch

"Hand and foot control"

A. Horn

B. KSR (Kubota Shockless Ride)

C. AUX1

D. AUX3 or Turn Signal

E. Travel Speed

F. Proportional AUX Switch

G. AUX Hold Switch

H. AUX2

I. AUX Mode Change

J. Float Switch

"ISO pilot control"

●

High-flow hydraulics (optional)

The optional high-flow hydraulics system

can handle attachments requiring extra

hydraulic power. With high-flow hydraulics,

the standard hydraulic flow increases from

18.0 gpm to 28.0 gpm on the SSV65 and

from 20.9 to 30.4 gpm on the SSV75.

Fast and smooth operational responseFast and smooth operational response

Left Control Lever

B E

Left Control Lever

B E

Right Control Lever

F G

Right Control Lever

Hand and foot control/

ISO pilot control

●

Self-leveling function (optional)

The optional self-leveling function maintains

the position of the bucket or fork as the

attachment is raised, eliminating the need

to manually adjust the angle during this

operation.

OUTSTANDING PERFORMANCE

●

Long reach and high bucket

hinge pin height

Kubota’s unique vertical lift design

delivers an exceptionally long reach of

32.7 inches (SSV65) or 36.9 inches

(SSV75). The tip of the arm is optimally

shaped to provide an exceptionally high

hinge-pin height of 121.5 inches

(SSV65) or 128.3 inches (SSV75) for

easier dumping into trucks and other

lifting and dumping tasks.

Kubota's Unique

vertical lift design

Kubota’s unique

vertical lift design

SSV65:

32.7 in (831 mm)

SSV75:

36.9 in (936 mm)

SSV65: 121.5 in (3085 mm)

SSV75: 128.3 in (3258 mm)

With KSR on

With KSR off

3 2

Standard two-speed travel

Shift from low gear at 6.9 mph (SSV65) / 7.4 mph (SSV75) to high gear

at 11.1 mph (SSV65) / 11.8 mph (SSV75) to get the job done faster.

1. Kubota Shockless Ride (KSR) (optional)

KSR helps minimize fatigue by “smoothing out” the ride. You’ll

appreciate KSR when carrying heavy loads over rough terrain on the

farm or at a construction job site.

2. Heavy duty tires

The crack-resistant heavy-duty tires feature a long-wearing tread pattern

for superior grip and stability. The sidewalls are wider than the wheel to

prevent stones and dirt from becoming wedged between them.

3. High ground clearance

Travel over large obstacles with ease, thanks to the high ground

clearance of 7.6 inches (SSV65) or 8.1 inches (SSV75).

Travel performanceTravel performance

ExCEPTIONAl

COMFORT AND

CONvENIENCE

Comfortable interiorComfortable interior

●

Excellent 360˚ visibility

The edges of the bucket can be seen from

the seat. Improved visibility means greater

safety on the job.

●

Ready for radio installation

The SSV-series Factory cab comes prewired

with speakers already installed, all that

needs to be added is the radio.

●

12V power outlet

A convenient 12V socket can be used for

recharging mobile phones and powering

other small electronic devices.

●

Suspension seat

Wide and supportive, the SSV series’

suspension seat will keep you working

comfortably for hours.

●

Cup holder

A cup holder under the right armrest

conveniently holds drinks to quench your

thirst while on the job.

●

Front Post Switch panels

Switch panels on the front posts provide

quick and convenient access to important

functions.

Shown with ISO Pilot Controls

Left Right

Air conditioningAir conditioning

●

Ample legroom

The spacious cabin provides ample legroom to help reduce

operator fatigue.

●

Rear view mirror

The wide mirror in the middle of the cabin ensures an excellent

view of conditions behind the loader.

Shown with ISO Pilot Controls

●

Optimized air conditioning

Optimized airflow through nine vents

provides outstanding cooling and

heating comfort throughout the year.

●

Enhanced defrosting and

demisting functions

Ample airflow prevents the windows

from fogging up or freezing during the

cold months of the year.

Shown with ISO Pilot Controls

ExCEPTIONAl SAFETy AND

FUNCTIONAlITy

Rugged exterior

●

ROPS/FOPS cabin

The OSHA-certified ROPS/FOPS cabin provides protection

in the event of accidental rollovers or falling objects.

●

Bolt-on replaceable handles

The handles are bolted to the cab to allow for quick and

easy replacement in the event they become damaged.

Sliding front door

Standard on all closed-cab models and a dealer-installed option on the open-

cab models, the tall and wide sliding front door can be opened regardless of

the loader position,

ensuring quick and

easy entry and exit.

Pressurized Cab

The pressurized cab keeps out dust, flying debris,

and insects so that you can work comfortably with

fewer distractions. Lower noise levels let you work

long hours with minimal fatigue.

30.7 in

(780 mm)

39.3 in

(998 mm)

●

Front and side work lights

●

Turn signals (optional)

●

Rear lights

●

Coupler protection

●

Aux. hydraulic lines routed

inside the arm

●

Cylinder protection plates

●

Sliding side windows

The front sections of both side windows slide

open towards the back of the cab.

●

Side-window grille

The side-window grilles are installed on the

inside to let you easily clean the outer glass

surfaces of the windows.

EASy MAINTEN ANCE

Simple AccessSimple Access

●

Routine checks

The rear door opens wide, providing

access to all components for daily routine

inspection.

●

Door enclosed fuel tank and easy

refill access

No need to open the door. Simply lift a flap

for quick and easy refueling.

●

Easy battery access

The battery is easily accessed

without tools.

A. Engine oil ﬁller tube

B. Engine oil dipstick

C. Battery

D. Engine oil ﬁlter

E. Diesel fuel ﬂler tube

F. Air cleaner indicator

Air cleaner

H. Coolant reserve tank

I. Water separator

Fuel ﬁlter

Door lock

Top-mounted radiator and oil cooler

Conveniently located on the top of the engine

compartment, the radiator components are

protected from damage from the rear yet

within easy reach for cleaning and routine

maintenance.

EASy MAINTEN ANCE

●

Tilt-up cabin

The cabin can be tilted 64° without

having to lift the arm, allowing easy

access to the hydraulic pumps,

valves, lines and hydraulic tank.

●

Mud-cleaning ports

Three mud-cleaning ports ensure fast and

simple removal of mud and debris from

the lower part of the machine.

●

Easy-clean Floor Mat and

Drain Outlet

The soft rubber floor mat is easy to remove

and clean. And with the built-in drain

outlet, the mat can be washed in the cab.

Shown with ISO Pilot Controls

Bale Spear

vERSATIlITy

With a wide variety of attachments available*, Kubota skid steer loaders are the most versatile

machines on the jobsite.

EqUIPMENT

Pallet Fork

Hydraulic Coupler

Bucket

STANDARD EQUIPMENT OPTIONAL EQUIPMENT

• Open CAB (ROPS/FOPS Level1)

• Top/Rear window

• Type of Control (Hand & Foot

control/ISO pilot control)

• Suspention Seat

• 2” Retractable seat belt

• Fold down arm rests

• Dial throttle

• 12V electic outlet

• Radio Ready (Closed Cab only)

• Horn

• Backup alarm

• Work lights (Front 2/Rear 2)

• Side lights

• Bucket Cylinder Guards

• Protection for AUX coupler

• Mechanical quick coupler

• Heavy Duty Tire

SSV65 10-16.5

SSV75 12-16.5

• High flow hydraulics

• Multifunction lever

• 14 pin coupler for attachments

• Kubota Shockless Ride (KSR)

• Self leveling (on/off)

• Air ride suspention seat

• 3” Retractable seat belt

• Door lock key

• Various buckets and other

attachments

• Tire options

• Hydraulic quick coupler

• Hazard Lamp/Turn Signals

• Strobe light

• Beacon light

• Polycarbonate door

• Additional counterweight

• Engine block heater

…and much more.

An optional Hydraulic quick coupler is

available. You can attach or remove

attachments using a switch without

leaving the seat.

*Not all attachments are OEM-KUBOTA.

Auger

Angle Broom

Grapple

Power Rake

Rock Bucket

Rotary Cutter

Rotary Tiller

Stump Grinder

Snow Blade

Snow Blower

Snow Pusher

3-Point Hitch

Tree Puller

SPECIFICATIONS

The company reserves the right to change the above specifications without notice. This brochure is for descriptive purposes only. Please contact your local Kubota dealer

for warranty infomation. For your safety, Kubota strongly recommends the use of a Rollover Protective structure

(

ROPS

)

and seat belt in almost all applications.

Model

Type of operator station

Engine

Loader

performance

Power train

Hydraulic

system

Service refill

capacities

Operating weight (Include operator weight 175 lbs.)

Model

Emission certification

Gross HP（SAE J1995）

Net HP（SAE J1349）

Displacement

Cylinders

Bore Stroke

Aspiration

Rated operating capacity-50% tipping load

Tipping load

Breakout force

Lift arm path

Standard tire size

Chain size ASA#

Travel speed

Traction force

Ground clearance

Loader hydraulic flow

Loader hydraulic pressure

Aux. hydraulic flow

Hydraulic tank

Fuel tank

Bucket

Lift arm

Low

High

Standard

High

(

)

/rpm

(

)

/rpm

cu.in. (cc)

in.(mm)

lbs. (kg)

lbf. (kgf)

mph（km/h）

lbf.

(

kgf

)

in. (mm)

gpm ( /min.)

psi

(

kgf/cm

)

gpm ( /min.)

gal. ( )

lbs. (kg)

SSV65

Open CAB / Closed CAB

V2607-CR-TE4

Tier 4

64.0 (47.7)/ 2700

61.3 (45.7)/ 2700

159.7

(

2615

)

3.5 (87) × 4.4

(

110

)

Turbocharged

1950 (885)

3900 (1770)

4839 (2195)

3858 (1750)

Vertical

10-16.5-8PR

6.9 (11.1)

11.1 (17.8)

7339 (3329)

7.6 (193)

18.0 (68.0)

3271 (230)

18.0 (68.0)

28.0 (106.0)

4.2 (16.0)

25.4 (96.0)

6790 (3080) / 7055 (3200)

SSV75

Open CAB / Closed CAB

V3307-CR-TE4

Tier 4

74.3 (55.4)/ 2600

71.6 (53.4)/ 2600

203.3

(

3331

)

3.8

(

)

× 4.8

(

120

)

Turbocharged

2690 (1220)

5380 (2440)

5884 (2669)

4850 (2200)

Vertical

12-16.5-10PR

100

7.4 (11.9)

11.8 (19.0)

8494 (3853)

8.1 (207)

20.9 (79.0)

3271 (230)

20.9 (79.0)

30.4 (115.0)

4.2 (16.0)

26.9 (102.0)

8157 (3700) / 8422 (3820)

DIMENSIONS

44.3 (1125) / 47.2 (1200)

7.6 (193) /

8.1 (207)

106.3 (2700) / 115.0 (2920)

135.4 (3439) / 144.1 (3660)

41˚/

43˚

27˚/

27˚

23.9˚/

24.6˚

32.7 (831) /

36.9 (936)

Unit: in. (mm)

79.9 (2029) /

81.3 (2065)

69.0 (1753) /

75.0 (1905)

92.3 (2345) / 98.5 (2503)

66.5 (1689) /

71.8 (1823)

53.7 (1364) / 56.5 (1435)

121.5 (3085) /

128.3 (3258)

92.4 (2347) /

98.0 (2490)

44.3 (1125) / 47.2 (1200)

7.6 (193) /

8.1 (207)

106.3 (2700) / 115.0 (2920)

135.4 (3439) / 144.1 (3660)

41˚/

43˚

27˚/

27˚

23.9˚/

24.6˚

32.7 (831) /

36.9 (936)

Unit: in. (mm)

79.9 (2029) /

81.3 (2065)

69.0 (1753) /

75.0 (1905)

92.3 (2345) / 98.5 (2503)

66.5 (1689) /

71.8 (1823)

53.7 (1364) / 56.5 (1435)

121.5 (3085) /

128.3 (3258)

92.4 (2347) /

98.0 (2490)

SSV65 / SSV75

KUBOTA TRACTOR CORPORATION

Kubota Tractor Corporation, 3401 Del Amo Boulevard, Torrance CA 90503

Western Division: 1175 S. Guild Ave., Lodi, CA 95240 Tel (209) 334-9910

Central Division: 14855 FAA Boulevard, Fort Worth, TX 76155 Tel (817) 571-0900

Northern Division: 6300 at One Kubota Way, Groveport, OH 43125 Tel (614) 835-1100

Southeast Division: 1025 Northbrook Parkway, Suwanee, GA 30024 Tel (770) 995-8855

Visit our web site at: www.kubota.com

From compact track loaders and excavators to wheel loaders and

tractor/loader/backhoes, Kubota offers a wide range of reliable,

high-performance construction equipment to get the job done right.

R530/R630

M62SVL75-2/SVL95-2

Cat. No.8876-01-US Printed in Japan ’16-03D. 30

KX040-4

Kubota Tractor Corporation reserves the right to change the stated specifications without notice. This brochure is for descriptive purposes only and reasonable efforts were used to set forth the contained information; some items shown may

be optional and some products shown may not be available at all dealerships. Kubota disclaims all representations and warranties, express or implied, or any liability from the use of this brochure. For complete warranty, safety and product

information, consult your local Kubota dealer and the operator's manual. Power (HP/KW) and other specifications are based on various standards or recommended practices. For your safety, Kubota strongly recommends the use of a Rollover

Protective Structure (ROPS) and seat belt in almost all applications. This brochure is intended for the United States and US territories only. For information regarding Kubota products or services outside these areas, see Kubota Corporation's

global web site. Kubota does not provide parts, warranty or service for any Product which is re-sold or retailed in any country other than the country for which the Product(s) were designed or manufactured.
