PVCu CABLE MANAGEMENTSection ContentManufacturing in Britain for nearly 50 years, Centaur has become a leading name in the PVCu cable management market.Centrally located in Redditch, England, Centaur utilise a fast and efficient distribution network.Combining continued investment and a wealth of expertise, Centaur boast a vast selection of cable management products enabling a complete installation. A dedicated fabrication section allows bespoke offerings tailor made for individual requirements.Striving to do our utmost for the environment, Centaur aim to minimise the output of CO2 emissions through the recycling of raw materials.Meridian PVCu Trunking 4 President PVCu Trunking 10 President Aluminium Trunking 16President Bench Trunking 20President Power Poles & Posts 24Campus Range 26Kensington Trunking 32Maxi Trunking 36Mini Trunking 38Red Range & Non-Combustible 40Conduit 42Surface & Socket Boxes 50Dry Lining Boxes 52Bespoke Products 54Technical Information 583

4CENTAUR |MERIDIAN FEATURESMeridian PVCu TrunkingKEYFEATURES:THREE COMPARTMENT MERIDIAN PVCu DADO TRUNKING1.Adaptor16 x 25 mm Mini trunking adaptor for aesthetically pleasing connections1.Adaptor2.Hinged lidHinged lid that acts as a cable retainer to ease installation2.Hinged LidAdjustable internal & external bends for wall inaccuracies4.Adjustable BendsAll accessories overlap trunking to prevent need for joint couplers, screw kits also available3.Accessories3.Accessories

5| CENTAURCENTAURMERIDIAN FEATURESMeridian PVCu TrunkingDesigned with today’s cable management challenges in mind, Centaur’s latest innovative product range, Meridian dado trunking and accessories balances practicality with aesthetics. This easy to install 173 x 60 mm range provides ample cabling space and boasts a large selection of key features suitable for a wide range of applications. Once the protective film covering is removed, the curved lid design gives a sleek but unobtrusive look to modern day installations.FEATURES:4.Adjustable Bends5.Pre-Pierced6.Cable SweepExternal data cable sweep for corner protection and segregation6.Cable Sweep7.ComplianceCat 6 & 7 compliant bend radii & contrasting lids or plates for Part M compliance7.Compliance8.Boxes & PlatesOutlet boxes or plates suited to wiring accessory installation8.Boxes & PlatesPre-pierced fixing holes for easy installation5.Pre-Pierced

6CENTAUR |COUPLER END CAPFLAT ANGLE17360DO NOT SCALE DRAWINGMerian ProfileSHEET 1 OF 1UNLESS OTHERWISE SPECIFIED:SCALE: 1:5WEIGHT: REVDWG. NO.ASIZETITLE:NAMEDATECOMMENTS:Q.A.MFG APPR.ENG APPR.CHECKEDDRAWNFINISHMATERIALINTERPRET GEOMETRICTOLERANCING PER:DIMENSIONS ARE IN INCHESTOLERANCES:FRACTIONALANGULAR: MACH BEND TWO PLACE DECIMAL THREE PLACE DECIMAL APPLICATIONUSED ONNEXT ASSYPROPRIETARY AND CONFIDENTIALTHE INFORMATION CONTAINED IN THISDRAWING IS THE SOLE PROPERTY OF<INSERT COMPANY NAME HERE>. ANY REPRODUCTION IN PART OR AS A WHOLEWITHOUT THE WRITTEN PERMISSION OF<INSERT COMPANY NAME HERE> IS PROHIBITED.5432155173608440THREE COMPARTMENT DADO TRUNKING173 mm x 60 mm 3 Compartment radius dado trunking white [3 m length]• Radius design for maximum aesthetic appeal• Multi compartment to accommodate power and data cable segregation• Light oak wood effect finish available• Available in antimicrobial on request• Supplied with protective film and pierced base• Hinged lid to act as a cable retainer• Various colours available on requestFLAT TEERadius dado trunking flat angle - white Radius dado trunking flat tee - whitePVCu THREE COMPARTMENT TRUNKINGDESCRIPTION CAT. NO. PACK QTYCat 6 & 7 compliant trunking c/w lids ACD 3 2 x 3 mDESCRIPTION CAT. NO. PACK QTYCat 6 & 7 compliant radius dado flat angle c/w segregatorAFA 3 1DESCRIPTION CAT. NO. PACK QTYCat 6 & 7 compliant radius dado flat tee c/w segregatorAFT 3 1DESCRIPTION CAT. NO. PACK QTYRadius dado coupler ACC 3 2DESCRIPTION CAT. NO. PACK QTYRadius dado end cap AECC 3 2HIGHIMPACTRESISTANCEANTIMICROBIALAVAILABLEMETRELENGTHS3 Meridian PVCu TrunkingMeasurements:Millimetres (mm) unless stated otherwise

7| CENTAURCENTAURADJUSTABLE INTERNAL ANGLEADJUSTABLE EXTERNAL ANGLE1 GANG OUTLET BOXESASB 2ASP 1OUTLET PLATES10 mm EXTENSION COLLARSECR 110WASB 1PVCu THREE COMPARTMENT TRUNKINGDESCRIPTION CAT. NO. PACK QTYRadius dado adjustable internal anglec/w internal plate (between 83° & 95°)AIC 3 1DESCRIPTION CAT. NO. PACK QTYRadius dado adjustable external angle c/w data cable sweep (between 40° & 95°)AEC 3 1DESCRIPTION CAT. NO. PACK QTY1 gang, 32 mm ASB 1 11 gang, 32 mm, 4 pillar ASB 1V 101 gang, 40 mm ASBC6 1 10DESCRIPTION CAT. NO. PACK QTYOutlet plate, 1 gang ASP 1 15Outlet plate, 2 gang ASP 2 15DESCRIPTION CAT. NO. PACK QTY1 Gang, round corners ECR 110W 101 Gang, square corners ECS 110W 102 Gang, round corners ECR 210W 102 Gang, square corners ECS 210W 10Meridian PVCu TrunkingMeasurements:Millimetres (mm) unless stated otherwiseDESCRIPTION CAT. NO. PACK QTY2 gang, 32 mm ASB 2 13 gang, 32 mm ASB 3* 52 gang, 40 mm ASBC6 2 102 & 3 GANG OUTLET BOXES* - Product made to order.

8CENTAUR |SEPARATE PROFILESACL 1SPARESAMC 2/3DESCRIPTION CAT. NO. PACK QTYBase unit AB 3 2 x 3 mRadius lid ACH 3 4 x 3 mCentre lid ACL 1 4 x 3 mPart M centre lid - grey ACL 1G* 4 x 3 mDESCRIPTION CAT. NO. PACK QTYMini Trunking Adaptor (16 x 25 mm) AMC 2/3 2Contrast plate - blue APM 1BL* 20Contrast plate - grey APM 1G 20External corner data cable sweep ACGE 3 6Locking device c/w cap ALD 3 50Q-CLIPNON-COMBUSTIBLE FIRE CLIPS• 18th Edition wiring regulations section 521.10.202 compliant• Non-combustible• Manufactured from steel• Suitable for a range of different sized compartmentsQ-CLIP222Meridian PVCu TrunkingMeasurements:Millimetres (mm) unless stated otherwise* - Product made to order.* - Product made to order.PVCu THREE COMPARTMENT TRUNKINGDESCRIPTION CAT. NO.80 mm Long fire resistant steel cable retainer Q-CLIP80222 mm Long fire resistant steel cable retainerSuitable for Meridian TrunkingQ-CLIP222Designed to be installed where cable capacity does not exceed 45% of the trunking.

9| CENTAURProduct ApplicationMeasurements:Millimetres (mm) unless stated otherwiseILLUMINATED TRUNKINGUNIVERSITIES / EDUCATIONPRODUCT APPLICATION• Made to order• Bespoke sizes and lengths• Populated and pre-wired on request• Available in a range of different colours or finishesDESIGN FEATURES:Available from loose lengths all the way through to pre-wired, cut to length units, the Centaur Meridian illuminated trunking provides a practical, simple to install and aesthetically pleasing method for power and data distribution. Illuminated trunking units are specially made to suit installation requirements and significantly reduce labour time on site. A wide variety of wiring accessory configurations and circuit protection is available for a selection of applications. LED lighting is available in cool or warm white and can be fitted into either the top or bottom compartment of the dado trunking. Pre-wired units will be fully 18th edition compliant and in accordance with other relevant British Standards.

10CENTAUR |PRESIDENT FEATURESKEYFEATURES:MULTI COMPARTMENT PRESIDENTPVCu DADO & SKIRTING TRUNKING1.ProfilesChamfered, square or skirting profiles1.Profiles2.Cable CapacityLarge capacity multi-compartment design2.Cable CapacityCentaur offer a range of colours as well as wood effects available in light oak and mahogany.4.Colours/FinishesDouble-skinned walls for added strength, stability and segregation3.Double-Skinned Wall3.Double Skinned WallPresident PVCu Trunking

11| CENTAURCENTAURPRESIDENT FEATURESAn innovative design and aesthetically pleasing solution for cable management in hospitals, offices, schools, colleges, laboratories, hotels and public buildings. Offering substantial cable capacity and design appeal for today’s modern buildings.The President PVCu cable management system allows a fast, easy and cost-effective solution. Providing variation of chamfered, square or skirting profiles, in high impact resistant PVCu.Centaur President trunking is an all British design and manufactured in accordance with the requirements of BS 4678, Part 4 (1982) and allows the installer to comply with BS 7671 (wiring regulations).FEATURES:4.Colours/Finishes5.Pre-Pierced6.Moulded FittingsLocking device & caps for the moulded fittings provide fast installation and a neat appearance6.Moulded Fittings7.ComplianceSquare dado trunking available with Cat 6 & 7 fittings 7.Compliance8.Boxes & PlatesChoice of 32 mm or 40 mm deep outlet boxes8.Boxes & PlatesPre-pierced fixing holes for easy installation5.Pre-PiercedPresident PVCu Trunking

12CENTAUR |2180.6222504580.6PVCu MULTI COMPARTMENT TRUNKINGCHAMFERED DADO TRUNKING SKIRTING TRUNKINGWhen used with Cat 6 & 7 compliant accessories.21504580.251355580.61926048.55580.61926048.55580.61926048.5THREE COMPARTMENT DADO TRUNKING192 mm x 60 mm 3 Compartment square dado trunking white [3 m length]• Clean line design for maximum aesthetic appeal• Multi compartment to accommodate power and data cable segregation• Light oak & mahogany wood effect finish available• Available in antimicrobial on request• Supplied with protective film and pierced base• Various colours available on requestDESCRIPTION CAT. NO. PACK QTYCat 6 & 7 compliant trunking c/w lids ASD 1 2 x 3 mHIGHIMPACTRESISTANCEANTIMICROBIALAVAILABLEMETRELENGTHS3 President PVCu TrunkingMeasurements:Millimetres (mm) unless stated otherwiseDESCRIPTION CAT. NO. PACK QTY3 Compartment trunking c/w lids ACD 2 2 x 3 mDESCRIPTION CAT. NO. PACK QTY3 Compartment trunking c/w lids ASKT 3 2 x 3 mSEMI CHAMFERED DADO TRUNKINGDESCRIPTION CAT. NO. PACK QTY3 Compartment trunking c/w lids ACD 4 2 x 3 mDESCRIPTION CAT. NO. PACK QTY4 Compartment trunking c/w lids ACD 5 1 x 3 mSEMI CHAMFERED DADO TRUNKINGMade to order

13| CENTAURCENTAURPVCu MULTI COMPARTMENT ACCESSORIESCOUPLERINTERNAL ANGLEEXTERNAL ANGLEAISC6 1ACS 1AEC 4AECC 2END CAPPresident PVCu TrunkingMeasurements:Millimetres (mm) unless stated otherwiseDESCRIPTION CAT. NO. PACK QTYASD 1 coupler ACS 1 2ACD 2 coupler ACC 2 2ASKT 3 coupler ACSK 3 2ACD 4 coupler ACC 4 2 ACD 5 coupler ACC 5* 2DESCRIPTION CAT. NO. PACK QTYASD 1 end cap AECS 1 2ACD 2 end cap AECC 2 2ASKT 3 right-hand end cap AECSK-3RH 2ASKT 3 left-hand end cap AECSK-3LH 2ACD 4 end cap AECC 4 2 ACD 5 end cap AECC 5* 2DESCRIPTION CAT. NO. PACK QTYCat 6 & 7 compliant ASD 1 internal angle AISC6 1 1ASD 1 internal angle AIS 1 1ASD 1 45º internal angle (fabricated) AIS 1/45* 1ACD 2 internal angle AIC 2 1ACD 2 45º internal angle (fabricated) AIC 2/45* 1ASKT 3 internal angle AISK 3 1ASKT 3 45º internal angle (fabricated) AISK 3/45* 1ACD 4 internal angle AIC 4 1ACD 4 45º internal angle (fabricated) AIC 4/45* 1ACD 5 internal angle AIC 5* 1DESCRIPTION CAT. NO. PACK QTYASD 1 external angle AES 1 1ASD 1 45º external angle (fabricated) AES 1/45* 1ACD 2 external angle AEC 2 1ACD 2 45º external angle (fabricated) AEC 2/45* 1ASKT 3 external angle AESK 3 1ASKT 3 45º external angle (fabricated) AESK 3/45* 1ACD 4 external angle AEC 4 1ACD 4 45º external angle (fabricated) AEC 4/45* 1ACD 5 external angle AEC 5* 1* - Product made to order.* - Product made to order.* - Product made to order.* - Product made to order.

14CENTAUR |PVCu MULTI COMPARTMENT ACCESSORIESFLAT ANGLES1 GANG OUTLET BOXESAFAU 3ASB 1FLAT TEESAFT 11 GANG OUTLET PLATEDESCRIPTION CAT. NO. PACK QTYASD 1 flat angle AFA 1 1ACD 2 flat angle AFA 2 1ASKT 3 upward flat angle AFAU 3 1ASKT 3 downward flat angle AFAD 3* 1ACD 4 flat angle AFA 4 1ACD 5 flat angle AFA 5* 1President PVCu TrunkingMeasurements:Millimetres (mm) unless stated otherwiseDESCRIPTION CAT. NO. PACK QTYASD 1 flat tee AFT 1 1ACD 2 flat tee AFT 2 1ASKT 3 upward flat tee AFTU 3 1ASKT 3 downward flat tee AFTD 3* 1ACD 4 flat tee AFT 4 1ACD 5 flat tee AFT 5* 1DESCRIPTION CAT. NO. PACK QTYOutlet box, 1 gang, 32 mm ASB 1 1Outlet box, 1 gang, 32 mm, 4 pillar ASB 1V 10Outlet box, 1 gang, 40 mm ASBC6 1 10DESCRIPTION CAT. NO. PACK QTYOutlet plate, 1 gang ASP 1 152 GANG OUTLET PLATEDESCRIPTION CAT. NO. PACK QTYOutlet plate, 2 gang ASP 2 15DESCRIPTION CAT. NO. PACK QTYOutlet box, 2 gang, 32 mm ASB 2 1Outlet box, 3 gang, 32 mm ASB 3* 5Outlet box, 2 gang, 40 mm ASBC6 2 102 & 3 GANG OUTLET BOXESASB 2* - Product made to order. * - Product made to order.* - Product made to order.

15| CENTAURCENTAURPVCu MULTI COMPARTMENT ACCESSORIESMINI TRUNKING ENTRYEXTENSION COLLARSPARESAMC 2ALD 1ECR 110WSCREENING INSERTASI/4President PVCu TrunkingMeasurements:Millimetres (mm) unless stated otherwiseSEPARATE PROFILESACH 4DESCRIPTION CAT. NO. PACK QTYBase unit AB 1 2 x 3 mSquare lid ASQ 1 4 x 3 mChamfered lid ACH 1 4 x 3 mCentre lid ACL 1 4 x 3 mPart M compliant centre lid - grey ACL 1G* 4 x 3 mBase unit (ACD 4) AB 4 2 x 3 mSemi chamfered lid ACH 4 4 x 3 mDESCRIPTION CAT. NO. PACK QTYCMT 2 square lid AMS 2* 2CMT 5 square lid AMS 5* 2CMT 2 chamfered lid AMC 2* 2CMT 5 chamfered lid AMC 5* 2CMT 2 semi chamfered lid AMC 2/4 2DESCRIPTION CAT. NO. PACK QTY1 Gang, round corners, 10 mm ECR 110W 101 Gang, square corners, 10 mm ECS 110W 102 Gang, round corners, 10 mm ECR 210W 102 Gang, square corners, 10 mm ECS 210W 10DESCRIPTION CAT. NO.PACK QTYMetal screen insert (60 mm)ASI 10 x3 mMetal screen insert (50 mm)ASI/4* 10 x3 mCORNER GUARDACGE 60DESCRIPTION CAT. NO. PACK QTY50 mm ACGE 50*660 mm ACGE 60*6CONTRAST PLATESAPM 1BLDESCRIPTION CAT. NO. PACK QTYBlue APM 1BL*20Grey APM 1G20DESCRIPTION CAT. NO.PACK QTY20 g Bottle, super fast adhesiveSA 3 1Locking devices c/w capsALD 1 5* - Product made to order.* - Product made to order.* - Product made to order.* - Product made to order.* - Product made to order.Q-CLIPNON-COMBUSTIBLE FIRE CLIPSQ-CLIP222Designed to be installed where cable capacity does not exceed 45% of the trunking.DESCRIPTION CAT. NO.80 mm Long fire resistant steel cable retainerSuitable for outer compartments of ACD 4 & ACD 5Q-CLIP80222 mm Long fire resistant steel cable retainerSuitable for President centre compartment & ASD 1, ACD 2 & ASKT 3 outer compartmentsQ-CLIP222

16CENTAUR |ALUMINIUM THREE COMPARTMENT TRUNKINGTHREE COMPARTMENT SQUARE DADO TRUNKING48.580.6192556048.580.619255 6048.580.61925560FEATURES:Selected accessories available moulded or fabricated.All President aluminium trunking and fabricated accessories are powder coated traffic white (RAL 9016) & moulded accessories sprayed traffic white.When used with Cat 6 & 7 compliant accessories. Product made to order.CAT. NO. PACK QTYBSD 1W 1 x 2 m192 mm x 60 mm 3 Compartment Aluminium Square Dado Trunking White (2 m Length). Cat 6 & 7 CompliantCAT. NO. PACK QTYBCD 2W 1 x 2 mTHREE COMPARTMENT CHAMFERED DADO TRUNKING192 mm x 60 mm 3 Compartment Aluminium Chamfered Dado Trunking White (2 m Length)THREE COMPARTMENT SKIRTING TRUNKING192 mm x 60 mm 3 Compartment Aluminium Skirting Trunking White (2 m Length)CAT. NO. PACK QTYBSKT 3W 1 x 2 mPresident Aluminium TrunkingMeasurements:Millimetres (mm) unless stated otherwiseProduct made to order. Product made to order.

17| CENTAURCENTAURALUMINIUM THREE COMPARTMENT ACCESSORIESPresident Aluminium TrunkingMeasurements:Millimetres (mm) unless stated otherwiseCOUPLERINTERNAL ANGLEEXTERNAL ANGLEBISC6 1WBCS 1WBEC 2WBECS 1WEND CAPDESCRIPTION CAT. NO. PACK QTYBSD 1W coupler (PVCu) BCS 1W 2BCD 2W coupler (PVCu) BCC 2W 2BSKT 3W coupler (PVCu) BCSK 3W 2DESCRIPTION CAT. NO. PACK QTYBSD 1W end cap (PVCu) BECS 1W 2BCD 2W end cap (PVCu) BECC 2W 2BSKT 3W right-hand end cap (PVCu) BECSK-3RHW 2BSKT 3W left-hand end cap (PVCu) BECSK-3LHW 2DESCRIPTION CAT. NO. PACK QTYCat 6 & 7 compliant BSD 1W internal angle (PVCu)BISC6 1W 1BSD 1W internal angle (PVCu) BIS 1W 1BSD 1W 45º internal angle (fabricated) BIS 1/45W 1BCD 2W internal angle (PVCu) BIC 2W 1BCD 2W 45º internal angle (fabricated) BIC 2/45W 1BSKT 3W internal angle (PVCu) BISK 3W 1BSKT 3W 45º internal angle (fabricated) BISK 3/45W 1DESCRIPTION CAT. NO. PACK QTYBSD 1W external angle (PVCu) BES 1W 1BSD 1W 45º external angle (fabricated) BES 1/45W 1BCD 2W external angle (PVCu) BEC 2W 1BCD 2W 45º external angle (fabricated) BEC 2/45W 1BSKT 3W external angle (PVCu) BESK 3W 1BSKT 3W 45º external angle (fabricated) BESK 3/45W 1All accessories made to order.All accessories made to order.All accessories made to order.All accessories made to order.

18CENTAUR |ALUMINIUM THREE COMPARTMENT ACCESSORIESBFT 2WFLAT ANGLE FLAT TEEBFA 1W1 GANG OUTLET BOXES ASB 1BSQ 1WSEPARATE PROFILESSPARESALD 1President Aluminium TrunkingMeasurements:Millimetres (mm) unless stated otherwiseDESCRIPTION CAT. NO. PACK QTYBSD 1W flat angle BFA 1W 1BCD 2W flat angle BFA 2W 1BSKT 3W upward flat angle BFAU 3W 1BSKT 3W downward flat angle BFAD 3W 1DESCRIPTION CAT. NO. PACK QTYBSD 1W flat tee BFT 1W 1BCD 2W flat tee BFT 2W 1BSKT 3W upward flat tee BFTU 3W 1BSKT 3W downward flat tee BFTD 3W 1DESCRIPTION CAT. NO. PACK QTYOutlet box, 1 gang, 32 mm ASB 1 1Outlet box, 1 gang, 32 mm, 4 pillar ASB 1V 10Outlet box, 1 gang, 40 mm ASBC6 1 102 & 3 GANG OUTLET BOXES ASB 2DESCRIPTION CAT. NO. PACK QTYOutlet box, 2 gang, 32 mm ASB 2 1Outlet box, 3 gang, 32 mm ASB 3* 5Outlet box, 2 gang, 40 mm ASBC6 2 101 GANG OUTLET PLATEDESCRIPTION CAT. NO. PACK QTYOutlet plate, 1 gang ASP 1 152 GANG OUTLET PLATEDESCRIPTION CAT. NO. PACK QTYOutlet plate, 2 gang ASP 2 15DESCRIPTION CAT. NO. PACK QTYLocking device with cap ALD 1 100Earth strap BBS 1* 10Earth lead BBS 2* 10DESCRIPTION CAT. NO. PACK QTYBase unit BB 1 2 x 2 mSquare lid BSQ 1W 4 x 2 mChamfered lid BCH 1W 4 x 2 mCentre lid BCL 1W 4 x 2 mAll accessories made to order.All accessories made to order.* - Product made to order.* - Product made to order.Products made to order.

19| CENTAURProduct ApplicationPRODUCT APPLICATIONGas & air outlets and nurse call points can be a challenge to install after a project has been completed.Centaur can produce vertical or horizontal bedhead units in any ward and laboratory areas and make them a breeze to install from their bespoke fabrication department. This comes with a complete Cat 6 cable management system to any general office areas.HEALTHCARE SECTORGAS & AIR OUTLETS• Option of Penlon or Gem 10 fixing plate• Anti-microbial available• Designed to fit multi-compartment trunkingDESIGN FEATURES:

20CENTAUR |PVCu & ALUMINIUM BENCH UNITSALUMINIUM BENCH UNITSALUMINIUM DUAL BENCH UNITSDBU 2DBUD 11102203022011030President Bench TrunkingMeasurements:Millimetres (mm) unless stated otherwiseDESCRIPTION CAT. NO. PACK QTY1 Gang x 2 DBUD 1* 12 Gang x 2 DBUD 2* 11 + 2 Gang x 2 DBUD 1/2* 1DESCRIPTION CAT. NO. PACK QTY1 Gang DBU 1* 12 Gang DBU 2 13 Gang DBU 3* 11 + 2 Gang DBU 1/2* 12 + 2 Gang DBU 2/2* 11 + 1 + 2 Gang DBU 1/1/2* 1PVCu DUAL BENCH UNITSABUD 1/2DESCRIPTION CAT. NO. PACK QTY1 Gang x 2 ABUD 1* 12 Gang x 2 ABUD 2 11 + 2 Gang x 2 ABUD 1/2 1PVCu BENCH UNITSABU 1DESCRIPTION CAT. NO. PACK QTY1 Gang ABU 1 12 Gang ABU 2 13 Gang ABU 3* 11 + 2 Gang ABU 1/2 12 + 2 Gang ABU 2/2 11 + 1 + 2 Gang ABU 1/1/2* 1FEATURES:Available plain, populated or pre-wired, President bench units offer a sleek and sophisticated look to a variety of applications, such as; laboratories, classrooms, offices etc.11030110* - Product made to order. * - Product made to order.* - Product made to order. * - Product made to order.

21| CENTAURCENTAURPVCu BENCH TRUNKINGPVCu BENCH TRUNKINGCOUPLERINTERNAL & EXTERNAL ANGLESEND CAP* - For use where a work surface and wall meet.** - For use with back to back bench trunking.ABT 1ABI 1ABEC 1*OUTLET BOXESASB 2ASP 1OUTLET PLATES11030110President Bench TrunkingMeasurements:Millimetres (mm) unless stated otherwiseFEATURES:Easy to install clip-in dividers. Two or three completely segregated compartments for power and data cables.DESCRIPTION CAT. NO. PACK QTYTrunking c/w lid ABT 1 2 x 3 m40 mm Clip-in divider DIV 40 10 x 3 mDESCRIPTION CAT. NO. PACK QTYCoupler ABC 2Bench Trunking with Lid White (3 m Length)• Ideal for large cable capacities• Easily adapted to suit a range of installations such as under-shelf or in a vertical corner position• Easy to access• Aesthetically pleasing design• Dividers available for compartment segregationDESCRIPTION CAT. NO. PACK QTYEnd cap ABEC 1* 2Dual end cap ABEC 2** 2Right-hand end cap ABEC 1RH 2Left-hand end cap ABEC 1LH 2DESCRIPTION CAT. NO. PACK QTYInternal angle (fabricated) ABI 1 1External angle (fabricated) ABE 1* 1DESCRIPTION CAT. NO. PACK QTYOutlet box, 1 gang, 32 mm ASB 1 1Outlet box, 2 gang, 32 mm ASB 2 1Outlet box, 3 gang, 32 mm ASB 3* 5DESCRIPTION CAT. NO. PACK QTYOutlet plate, 1 gang ASP 1 15Outlet plate, 2 gang ASP 2 15* - Product made to order.* - Product made to order.

22CENTAUR |ALUMINIUM BENCH TRUNKINGALUMINIUM BENCH TRUNKINGCOUPLERINTERNAL & EXTERNAL ANGLESEND CAP* - For use where a work surface and wall meet.** - For use with back to back bench trunking.ABEC 1TWDBI 1DBT 1/2M11030110FEATURES:Selected accessories available moulded or fabricated.All President aluminium bench trunking and fabricated accessories are powder coated traffic white (RAL 9016) & moulded accessories sprayed traffic white.President Bench TrunkingMeasurements:Millimetres (mm) unless stated otherwiseDESCRIPTION CAT. NO. PACK QTYAluminium trunking c/w lid DBT 1/2M* 2 x 2 mAluminium trunking c/w lid DBT 1/3M* 1 x 3 mAluminium base c/w PVCu lid DBT 2/2M* 2 x 2 mAluminium base c/w PVCu lid DBT 2/3M* 1 x 3 mPVCu 40 mm clip-in divider DIV 40 10 x 3 mHIGHIMPACTRESISTANCEANTIMICROBIALAVAILABLEMETRELENGTHS3 Aluminium Bench Trunking with Aluminium Lid White• Design provides added strength when under mechanical stress• Provision for earth continuity• Supplied in a glossy traffic white finish• Ideal for large cable capacities• Easily adapted to suit a range of installations such as under-shelf or in a vertical corner position• Easy to access• Aesthetically pleasing designDESCRIPTION CAT. NO. PACK QTYCoupler (PVCu) ABC TW* 2DESCRIPTION CAT. NO. PACK QTYInternal angle (fabricated) DBI 1 1Internal angle c/w PVCu lid (fabricated)DBI 2 1External angle (fabricated) DBE 1 1External angle c/w PVCu lid (fabricated)DBE 2 1DESCRIPTION CAT. NO. PACK QTYEnd cap (PVCu) ABEC 1TW* 2Dual end cap (PVCu) ABEC 2TW** 2Right-hand end cap (PVCu) ABEC 1RH TW 2Left-hand end cap (PVCu) ABEC 1LH TW 2* - Product made to order.* - Product made to order.All accessories made to order.All accessories made to order.

23| CENTAURCENTAUROUTLET BOXESASB 2ASP 1OUTLET PLATESSPARESBBS 2ALUMINIUM BENCH TRUNKING ACCESSORIESBench trunking is an ideal solution for laboratories, schools, colleges and universities.Centaur are able to integrate both power socket outlets and gas outlets into bench trunking, helping to keep trailing pipes/cables clear from the work space. Dual-sided options are also available in the form of both trunking and bench units, they’re available as standard, pre-wired/populated or bespoke.PRODUCT APPLICATIONMeasurements:Millimetres (mm) unless stated otherwiseDESCRIPTION CAT. NO. PACK QTYOutlet box, 1 gang, 32 mm ASB 1 1Outlet box, 2 gang, 32 mm ASB 2 1Outlet box, 3 gang, 32 mm ASB 3* 5DESCRIPTION CAT. NO. PACK QTYOutlet plate, 1 gang ASP 1 15Outlet plate, 2 gang ASP 2 15DESCRIPTION CAT. NO. PACK QTYEarth strap BBS 1* 10Earth lead BBS 2* 10EDUCATION SECTORBENCH TRUNKINGPresident Bench Trunking* - Product made to order.* - Product made to order.

24CENTAUR |PVCu POWER POLE & POST SYSTEMSPOWER POLE & POST* - 3m lengths for AP 2.EACH POWER POLE PACK COMPRISESACCESSORIESASB 1VAP 680EACH POWER POST PACK COMPRISESAccessories supplied separately.14080.5102452222FEATURES:Double-sided for a larger distribution, President PVCu power poles & posts are ideal for supplying commercial applications, large power, data and multimedia demand through one location.Measurements:Millimetres (mm) unless stated otherwisePresident Power Poles & PostsDESCRIPTION CAT. NO. PACK QTYOutlet box, 1 gang, 32 mm, 4 pillars ASB 1V 10Top cover for suspended & solid ceilings APF 1 1Tee used for suspended and solid ceilings, and floors. Compatible with President trunking ACD 4APT 1* 1Top slide for slab fixing (standard) ATS 1* 1Top slide 1 m extension for slab fixing ATS 1500* 1DESCRIPTION CAT. NO. PACK QTYPower pole 3.6 m length AP 1 1Power pole 3 m length AP 2 1Power post 680 mm length AP 680 1DESCRIPTIONPost body 1 x 680 mmSide lids 2 x 680 mmCentre lids 2 x 680 mmBase foot (metal) 1Base moulding 1Top cap 1DESCRIPTIONPole body* 1 x 3.6 mSide lids* 2 x 3.6 mCentre lids* 2 x 3.6 mFixing bracket 1Base foot (metal) 1Base moulding 1• Compatible with ACD 4 President profile• Fixing brackets and bases included• Full range of accessories to compliment • Painted colour finishes availableHIGHIMPACTRESISTANCEANTIMICROBIALAVAILABLEAP 1 AP 2For coloured lid options or non standard heights contact Centaur sales office.3 STANDARDOPTIONS* - Product made to order.

25| CENTAURCENTAURALUMINIUM POWER POLE SYSTEMSSINGLE SIDED POWER POLEEACH POWER POLE PACK COMPRISESOUTLET BOXOUTLET PLATE1005047 2222Measurements:Millimetres (mm) unless stated otherwisePresident Power Poles & PostsFEATURES:Single-sided power pole offering distribution in applications where it may be subject to mechanical stress.Aluminium power poles are powder coated traffic white (RAL 9016) & selected moulded accessories sprayed traffic white.DESCRIPTION CAT. NO. PACK QTYSingle sided power pole 3 m length AP 3W 1HIGHIMPACTRESISTANCEANTIMICROBIALAVAILABLEMETRELENGTHS3 • Fixing brackets, top cover and bases included• Full range of accessories to compliment • Painted colour finishes availableDESCRIPTIONPole body 1 x 3 mPole lid 1 x 3 m1 Gang outlet box 6Top cover 1Fixing bracket 1Base foot (metal) 1Base moulding 1DESCRIPTION CAT. NO. PACK QTY1 Gang outlet box, 32 mm, 4 pillars CSPB 1W 1DESCRIPTION CAT. NO. PACK QTY1 Gang outlet plate, 4 pillars CSP 1W 10BESPOKE CONFIGURATIONSMANUFACTURETECHNICAL SUPPORTDESIGNCentaur offer a department that is dedicated to providing customer specials. Direct contact with the factory can enable purpose-made items, professionally produced and delivered directly to site.

26CENTAUR |CAMPUS FEATURESCampus RangeKEYFEATURES:CAMPUSMULTI COMPARTMENT TRUNKING1.Compliance2.Manufactured to comply with BS 4678: Part 4 Heavy Duty ClassificationClip-on one piece fittings for quick and easy installation1.Compliance2.Clip-On AccessoriesOutlet boxes have square knock out in base to allow for deeper accessories3.Outlet Boxes & PlatesClip-on divider for 50 mm deep trunking.Self-adhesive divider for 30 mm deep trunking4.DividersClip-On Accessories

27| CENTAURCENTAURCAMPUS FEATURESA cost effective trunking system in PVCu or aluminium for use in schools, college halls of residence, hospitals, offices, government and local authority buildings or wherever an economical cable management system is required.The Centaur Campus dado trunking systems are an easy to install method of cable management, having clean, uncluttered lines for aesthetic appeal and the flexibility to fit additional accessories and outlets when required.PVCu Campus available in 3 sizes:100 mm x 30 mm100 mm x 50 mm (Aluminium option available)200 mm x 50 mmFEATURES:Campus RangeOverlapping one-piece cover for fast installation7.Radius internal angle & external corner guards for data cable protection6.Two module MCB/RCD housing with DIN rail fitted option available8.18th Edition compliant when used with Centaur Q-Clip5.5.Corner Guards4.Dividers6.Covers3.Boxes & PlatesCorner Guards Covers

28CENTAUR |PVCu DADO TRUNKING & ACCESSORIESTRUNKINGCOUPLERINTERNAL ANGLEEND CAPCMXT 42WCXC 42WCIAM 42WCES 42WDIVIDERDIV 42WFEATURES:Practical in its design, Campus dado trunking offers a cost effective solution to large cable demands. The option of clip-on and fabricated accessories allows both a neat and efficient installation.Cat 6 & 7 options available. Measurements:Millimetres (mm) unless stated otherwiseCampus RangeDESCRIPTION CAT. NO. PACK QTY30 mm Self-adhesive divider DIV 41W 10 x 3 m50 mm Clip-in divider DIV 42W 10 x 3 mDESCRIPTION CAT. NO. SIZE (mm) PACK QTYTrunking c/w lids CMXT 41W 100 x 30 2 x 3 mTrunking c/w lids CMXT 42W 100 x 50 2 x 3 mTrunking c/w lids DMXT 42W 200 x 50 2 x 3 m• Anti-tamper locking lid provides a clean exterior line to the trunking• Firm locking action defies accident removal• Dividers available for compartment segregationHIGHIMPACTRESISTANCEANTIMICROBIALAVAILABLEMETRELENGTHS3 DESCRIPTION CAT. NO. SIZE (mm) PACK QTYExternal coupler CXC 41W* 100 x 30 2External coupler CXC 42W 100 x 50 2External coupler DXC 42W 200 x 50 2Internal coupler CIC 41W* 100 x 30 1Internal coupler CIC 42W 100 x 50 1DESCRIPTION CAT. NO. SIZE (mm) PACK QTYEnd cap CES 41W 100 x 30 15End cap CES 42W 100 x 50 1End cap DES 42W 200 x 50 15DESCRIPTION CAT. NO. SIZE (mm)PACK QTYInternal angle CIAM 41W* 100 x 30 1Internal angle Cat 6&7 compliant CIAM 42W 100 x 50 1Internal angle Cat 6&7 compliant DIAM 42W 200 x 50 1* - Product made to order.* - Product made to order.

29| CENTAURCENTAURPVCu DADO ACCESSORIESFLAT ANGLECABLE RETAINEREXTERNAL ANGLECXAM 42WFLAT TEECFAM 42WCFTM 42WSPARESCSPB 1W* - Suitable for Campus Dado Trunking profiles CMXT 42W & DMXT 42W. ** - Product made to order.Measurements:Millimetres (mm) unless stated otherwiseCampus RangeDESCRIPTION CAT. NO. PACK QTYOutlet box, 1 gang, 32 mm, 4 pillars CSPB 1W* 1Outlet box, 2 gang, 32 mm CSPB 2W* 1Outlet plate, 1 gang CSP 1W 15Outlet plate, 2 gang CSP 2W 1515 mm Outlet box spacer CS 42W** 6External corner guard CG 42** 10DESCRIPTION CAT. NO. PACK QTYCable retainer CRT 42W* 6DESCRIPTION CAT. NO. SIZE (mm) PACK QTYFlat tee CFTM 41W* 100 x 30 1Flat tee CFTM 42W 100 x 50 1Flat tee (fabricated) DFTT 42W* 200 x 50 1DESCRIPTION CAT. NO. SIZE (mm) PACK QTYFlat angle CFAM 41W* 100 x 30 1Flat angle CFAM 42W 100 x 50 1Flat angle DFAM 42W 200 x 50 1DESCRIPTION CAT. NO. SIZE (mm) PACK QTYExternal angle CXAM 41W* 100 x 30 1External angle CXAM 42W 100 x 50 1External angle DXAM 42W 200 x 50 1Q-CLIPNON-COMBUSTIBLE FIRE CLIPSQ-CLIP222* - Product made to order. * - Product made to order.* - Product made to order.* - Product made to order.Designed to be installed where cable capacity does not exceed 45% of the trunking.DESCRIPTION CAT. NO.80 mm Long fire resistant steel cable retainerSuitable for Campus Range when dividers are installedQ-CLIP80222 mm Long fire resistant steel cable retainerSuitable for Campus Range when dividers are not installedQ-CLIP222

30CENTAUR |Products made to order.ALUMINIUM DADO TRUNKING & ACCESSORIESEXTERNAL ANGLEFEATURES:Selected accessories available moulded or fabricated.All Campus aluminium trunking & fabricated accessories are powder coated traffic white (RAL 9016) & moulded accessories sprayed traffic white.Cat 6 & 7 options available.Measurements:Millimetres (mm) unless stated otherwiseCampus RangeDESCRIPTION CAT. NO. SIZE (mm) PACK QTYExternal angle (PVCu) BXAM 42W 100 x 50 1External angle (fabricated) BXAT 42W 100 x 50 1INTERNAL ANGLEDESCRIPTION CAT. NO. SIZE (mm) PACK QTYCat 6 & 7 compliant internal angle (PVCu)BIAM 42W 100 x 50 1Internal angle (fabricated) BIAT 42W 100 x 50 1END CAPDESCRIPTION CAT. NO. SIZE (mm) PACK QTYEnd cap (PVCu) BES 42W 100 x 50 15COUPLERDESCRIPTION CAT. NO. SIZE (mm) PACK QTYCoupler (PVCu) BXC 42W 100 x 50 2TRUNKINGBMXT 42WDESCRIPTION CAT. NO. SIZE (mm) PACK QTYTrunking c/w lids BMXT 42W 100 x 50 2 x 3 m50 mm Clip-in divider DIV 42/S - 10 x 3 m• Anti-tamper locking lid provides a clean exterior line to the trunking• Firm locking action defies accident removal• Dividers available for compartment segregationHIGHIMPACTRESISTANCEANTIMICROBIALAVAILABLEMETRELENGTHS3 Product made to order. Product made to order.Product made to order. Product made to order.

31| CENTAURCENTAURALUMINIUM DADO ACCESSORIESMeasurements:Millimetres (mm) unless stated otherwiseCampus RangeCOLOURS / FINISHESMANUFACTURETECHNICAL SUPPORTDESIGNCentaur have invested heavily in the necessary PVCu cutting, welding and assembly equipment in its recently upgraded department including their spray shop, offering cable management solutions in a wide range of colours and finishesFLAT TEESPARESFLAT ANGLEBFAM 42WCRT 42WOUTLET BOXES & PLATESBFTM 42WCSPB 1WDESCRIPTION CAT. NO. PACK QTY100 x 50 mm Cable retainer CRT 42W 6Earth strap BBS 1 10Earth lead BBS 2 10External corner guard CG 42 10DESCRIPTION CAT. NO. SIZE (mm) PACK QTYFlat tee (PVCu) BFTM 42W 100 x 50 1Flat tee (fabricated) BFTT 42W 100 x 50 1DESCRIPTION CAT. NO. SIZE (mm) PACK QTYFlat angle (PVCu) BFAM 42W 100 x 50 1Flat angle (fabricated) BFAT 42W 100 x 50 1DESCRIPTION CAT. NO. PACK QTYOutlet box, 1 gang, 32 mm, 4 pillars CSPB 1W 1Outlet box, 2 gang, 32 mm CSPB 2W 1Outlet plate, 1 gang CSP 1W 15Outlet plate, 2 gang CSP 2W 1515 mm Outlet box spacer CS 42W* 6Products made to order. Products made to order.Products made to order.* - Product made to order.

32CENTAUR |KENSINGTON MULTI COMPARTMENT TRUNKINGUnobtrusive skirting, architrave/small dado cable management system. Ideal for installation in hotels, sheltered housing, nursing homes, and portable buildings where inconspicuous cabling is required to blend into the existing surroundings. The Centaur Kensington PVCu range comprises of one or two compartments.A door kit is available with pre-cut lengths of architrave and accessories to help with ease of ordering, keeping installation time and wastage to a minimum.Kensington Trunking• Smooth lines for cleaning. • Architrave profile can be run as a small dado system.• Ideal for solid floor buildings.• Outlet boxes for electrical accessories.DESIGN FEATURES:3.Door frame kit available for ease of ordering and reduction of waste. 2.Fittings overlap for more cutting tolerance, facilitating ease of installation.1.Single or twin compartments for cable segregation (removable divider).

33| CENTAURCENTAURDesigned to be installed where cable capacity does not exceed 45% of the trunking.Products made to order.SKIRTING TRUNKINGCOUPLERINTERNAL & EXTERNAL ANGLECKDCKIEND CAP CKE-RHSKIRTING TO ARCHITRAVE ADAPTORCKA-RHSPARES CKS 18025The Kensington skirting range offers a practical solution to cable management in domestic and commercial environments as the lids are easily separated from the base, allowing cables to be removed and added.DESCRIPTION CAT. NO. PACK QTYCMT 2 adaptor CKMT 2* 2Cable retainer CKR* 10Outlet box, 1 gang CKS 1 5Outlet box, 2 gang CKS 2 5DESCRIPTION CAT. NO. PACK QTYRight-hand adaptor CKA-RH 2Left-hand adaptor CKA-LH 2DESCRIPTION CAT. NO. PACK QTYInternal angle CKI 10External angle CKX 10DESCRIPTION CAT. NO. PACK QTYRight-hand end cap CKE-RH 5Left-hand end cap CKE-LH 5DESCRIPTION CAT. NO. PACK QTYCoupler CKC 10DESCRIPTION CAT. NO. PACK QTY1 Compartment CKD 1 15 m2 Compartment CKD 15 mSKIRTING TRUNKINGMeasurements:Millimetres (mm) unless stated otherwiseKensington TrunkingQ-CLIP80DESCRIPTION CAT. NO.80 mm Cable retainerSuitable for CKD & CKD 1Q-CLIP80222 mm Cable retainer Q-CLIP222Q-CLIP NON-COMBUSTIBLE FIRE CLIP* - Product made to order.

34CENTAUR |ARCHITRAVE TRUNKINGARCHITRAVE TRUNKINGCOUPLERINTERNAL & EXTERNAL ANGLECDAThe Kensington architrave range provides an efficient method to cabling around door ways, eliminating the need to install under floor cable management. This range can also be adapted to use as a dado trunking.CDIFLAT ANGLE & FLAT TEECDFA8025Measurements:Millimetres (mm) unless stated otherwiseKensington TrunkingDESCRIPTION CAT. NO. PACK QTY1 Compartment CDA 1 15 m2 Compartment CDA 15 mEND CAPDESCRIPTION CAT. NO. PACK QTYEnd cap CDE 10DESCRIPTION CAT. NO. PACK QTYCoupler CDC 10SPARES CDS 1DESCRIPTION CAT. NO. PACK QTYCMT 2 adaptor CDMT 2 2Cable retainer CDR 10Outlet box, 1 gang CDS 1 5Outlet box, 2 gang CDS 2 5DESCRIPTION CAT. NO. PACK QTYFlat angle CDFA 2Flat tee CDFT 2DESCRIPTION CAT. NO. PACK QTYInternal angle CDI 10External angle CDX 10Products made to order.Product made to order. Product made to order.Product made to order. Product made to order. Product made to order.Designed to be installed where cable capacity does not exceed 45% of the trunking.Q-CLIP80DESCRIPTION CAT. NO.80 mm Cable retainerSuitable for CDA & CDA 1Q-CLIP80222 mm Cable retainer Q-CLIP222Q-CLIP NON-COMBUSTIBLE FIRE CLIP

35| CENTAURCENTAURKENSINGTON TRUNKINGKensington TrunkingUtilising a slick and inconspicuous design, cabling is well hidden and blends into the room surroundings, along with the easy adaptability for the future.The Kensington door kit enables bespoke lengths to be cut, reducing waste and time on site.LEISURE INDUSTRYKENSINGTON TRUNKING• Smooth lines for cleaning. • Architrave profile can be run as a small dado system.• Ideal for solid floor buildings.• Outlet boxes for electrical accessories.DESIGN FEATURES:PRODUCT APPLICATION

36CENTAUR |Products made to order.MAXI TRUNKING & ACCESSORIESTRUNKING CMXT 22WBoasting a unique anti-tamper locking lid, Centaur Maxi Trunking provides a clean line to the exterior appearance. Dividers available separately allowing the option for multiple compartments.DIVIDERSDIV 22W16mm16mm25mm16mm50mm25mm38mm16mm16mm10mm38mm25mmCES 22WINTERNAL COUPLERCIC 22WEND CAPMeasurements:Millimetres (mm) unless stated otherwiseAdditional colours: Available on request.Maxi TrunkingDESCRIPTION CAT. NO. SIZE (mm) PACK QTYTrunking c/w lid CMXT 22W 50 x 50 4 x 3 mTrunking c/w lid CMXT 32W 75 x 50 4 x 3 mTrunking c/w lid CMXT 33W 75 x 75 4 x 3 mTrunking c/w lid CMXT 44W 100 x 100 2 x 3 mDESCRIPTION CAT. NO. PACK QTYSelf-adhesive divider DIV 22W 10 x 3 mSelf-adhesive divider DIV 33W 10 x 3 mSelf-adhesive divider DIV 44W 10 x 3 mDESCRIPTION CAT. NO. SIZE (mm) PACK QTYEnd cap CES 22W 50 x 50 1End cap CES 32W 75 x 50 1End cap CES 33W 75 x 75 1End cap CES 44W 100 x 100 1DESCRIPTION CAT. NO. SIZE (mm) PACK QTYInternal coupler CIC 22W 50 x 50 1Internal coupler CIC 32W 75 x 50 1Internal coupler CIC 33W 75 x 75 1Internal coupler CIC 44W 100 x 100 1

37| CENTAURCENTAURDesigned to be installed where cable capacity does not exceed 45% of the trunking.MAXI TRUNKING ACCESSORIESINTERNAL ANGLECIAM 22WCFAM 22WFLAT ANGLEFLAT TEECFTM 22WMeasurements:Millimetres (mm) unless stated otherwiseMaxi TrunkingFEATURES:Standard colour white, RAL/BS colours available on request are subject to order quantity.Specially fabricated fittings can be made to order.DESCRIPTION CAT. NO. SIZE (mm) PACK QTYFlat tee (moulded) CFTM 22W 50 x 50 2Flat tee (fabricated) CFTT 22W* 50 x 50 1Flat tee (fabricated) CFTT 32W 75 x 50 1Flat tee (fabricated) CFTT 33W 75 x 75 1Flat tee (fabricated) CFTT 44W 100 x 100 1DESCRIPTION CAT. NO. SIZE (mm) PACK QTYFlat angle (moulded) CFAM 22W 50 x 50 2Flat angle (fabricated) CFAT 22W* 50 x 50 1Flat angle (fabricated) CFAT 32W 75 x 50 1Flat angle (fabricated) CFAT 33W 75 x 75 1Flat angle (fabricated) CFAT 44W 100 x 100 1EXTERNAL ANGLECXAM 22WDESCRIPTION CAT. NO. SIZE (mm) PACK QTYExternal angle (moulded) CXAM 22W 50 x 50 2External angle (fabricated) CXAT 22W* 50 x 50 1External angle (fabricated) CXAT 32W 75 x 50 1External angle (fabricated) CXAT 33W 75 x 75 1External angle (fabricated) CXAT 44W 100 x 100 1DESCRIPTION CAT. NO. SIZE (mm) PACK QTYInternal angle (moulded) CIAM 22W 50 x 50 2Internal angle (fabricated) CIAT 22W* 50 x 50 1Internal angle (fabricated) CIAT 32W 75 x 50 1Internal angle (fabricated) CIAT 33W 75 x 75 1Internal angle (fabricated) CIAT 44W 100 x 100 1DESCRIPTION CAT. NO.80 mm Long fire resistant steel cable retainerSuitable for Maxi Trunking when divider is installedQ-CLIP80222 mm Long fire resistant steel cable retainerSuitable for Maxi Trunking when divider is not installedQ-CLIP222Q-CLIPNON-COMBUSTIBLE FIRE CLIPS• 18th Edition wiring regulations section 521.10.202 compliant• Non-combustible• Manufactured from steel• Suitable for a range of different sized compartmentsQ-CLIP222* - Product made to order. * - Product made to order.* - Product made to order.* - Product made to order.

38CENTAUR |MINI TRUNKING & ACCESSORIESTRUNKINGCMT 1WCMT 1SASELF-ADHESIVE TRUNKINGAdding extra strength to the integral cross section, the specially designed tamper proof lid eliminates accidental removal. Self-adhesive dividers in selected size enables cable segregation.MEC 1WEND CAP16mm16mm25mm16mm50mm25mm38mm16mm16mm10mm38mm25mmMeasurements:Millimetres (mm) unless stated otherwiseAdditional colours: Available on request.Mini TrunkingDESCRIPTION CAT. NO. SIZE (mm) PACK QTYTrunking c/w lid CMT 0W 16 x 10 20 x 3 mTrunking c/w lid CMT 1W 16 x 16 20 x 3 mTrunking c/w lid CMT 2W 25 x 16 20 x 3 mTrunking c/w lid CMT 3W 38 x 16 15 x 3 mTrunking twin compartment c/w lid CMT 3W T/C* 38 x 16 15 x 3 mTrunking c/w lid CMT 4W 38 x 25 15 x 3 mTrunking c/w lid CMT 5W 50 x 25 12 x 3 mTrunking twin compartment c/w lid CMT 5W T/C* 50 x 25 12 x 3 mDESCRIPTION CAT. NO. SIZE (mm) PACK QTYEnd cap MEC 0W 16 x 10 100End cap MEC 1W 16 x 16 10End cap MEC 2W 25 x 16 100End cap MEC 3W 38 x 16 10End cap MEC 4W 38 x 25 30End cap MEC 5W 50 x 25 1DESCRIPTION CAT. NO. SIZE (mm) PACK QTYTrunking c/w lid CMT 0SA 16 x 10 20 x 3 mTrunking c/w lid CMT 1SA 16 x 16 20 x 3 mTrunking c/w lid CMT 2SA 25 x 16 20 x 3 mTrunking c/w lid CMT 3SA 38 x 16 15 x 3 mTrunking c/w lid CMT 4SA 38 x 25 15 x 3 mTrunking c/w lid CMT 5SA 50 x 25 12 x 3 mMC 1WCOUPLERDESCRIPTION CAT. NO. SIZE (mm)PACK QTYCoupler MC 0W* 16 x 10 60Coupler MC 1W 16 x 16 10Coupler MC 2W 25 x 16 40Coupler MC 3W 38 x 16 1Coupler MC 4W 38 x 25 10Coupler MC 5W 50 x 25 1CMT 2BR/SASELF-ADHESIVE TRUNKINGDESCRIPTION CAT. NO. SIZE (mm) PACK QTYBlack trunking c/w lidCMT 2B/SA 25 x 16 20 x 3 mBrown trunking c/w lidCMT 2BR/SA 25 x 16 20 x 3 mCMT 2B/SA* - Products made to order.* - Product made to order.

39| CENTAURCENTAURMINI TRUNKING ACCESSORIESMIB 1WSELF-ADHESIVE DIVIDERINTERNAL ANGLEDIV 2WMeasurements:Millimetres (mm) unless stated otherwiseMini TrunkingDESCRIPTION CAT. NO. PACK QTYSelf-adhesive DIV 2W 10 x 3 mSelf-adhesive DIV 3W 10 x 3 mSelf-adhesive DIV 4W 10 x 3 mSelf-adhesive DIV 5W 10 x 3 mDivider (metal) DIV 5 METAL 10 x 3 mMT 1-1WEQUAL TEESURFACE BOX ADAPTORMA 1WEXTERNAL ANGLEFLAT ANGLEMEB 1WMFB 1WCEILING ROSE ADAPTORDESCRIPTION CAT. NO. PACK QTYCeiling rose adaptor CMT 2/CMT 1MCR 2W 30DESCRIPTION CAT. NO. PACK QTYTo fit CMT 1 (centre) MA 1W 10To fit CMT 2 (centre) MA 2W 50DESCRIPTION CAT. NO. SIZE (mm)PACK QTYFlat angle MFB 0W 16 x 10 60Flat angle MFB 1W 16 x 16 60Flat angle MFB 2W 25 x 16 40Flat angle MFB 3W 38 x 16 40Flat angle MFB 4W 38 x 25 25Flat angle MFB 5W 50 x 25 2DESCRIPTION CAT. NO. SIZE (mm)PACK QTYEqual tee MT 0-0W* 16 x 10 50Equal tee MT 1-1W 16 x 16 10Equal tee MT 2-2W 25 x 16 30Equal tee MT 3-3W 38 x 16 10Equal tee MT 4-4W 38 x 25 10Equal tee MT 5-5W 50 x 25 1DESCRIPTION CAT. NO. SIZE (mm)PACK QTYExternal angle MEB 0W 16 x 10 50External angle MEB 1W 16 x 16 50External angle MEB 2W 25 x 16 40External angle MEB 3W 38 x 16 10External angle MEB 4W 38 x 25 25External angle MEB 5W 50 x 25 2DESCRIPTION CAT. NO. SIZE (mm) PACK QTYInternal angle MIB 0W 16 x 10 50Internal angle MIB 1W 16 x 16 50Internal angle MIB 2W 25 x 16 40Internal angle MIB 3W 38 x 16 10Internal angle MIB 4W 38 x 25 25Internal angle MIB 5W 50 x 25 2DESCRIPTION CAT. NO.80 mm Cable retainerSuitable for CMT 0 - CMT 4Q-CLIP80222 mm Cable retainerSuitable for CMT 5Q-CLIP222Q-CLIP NON-COMBUSTIBLE FIRE CLIPSQ-CLIP80* - Product made to order.Products made to order.Designed to be installed where cable capacity does not exceed 45% of the trunking.

40CENTAUR |RED 202 MINI TRUNKINGTRUNKINGCOUPLERBENDS & TEEMFB 2RTERMINAL BOXES & LIDSSB 201ROUTLET BOXESAll terminal boxes are complete with glands and earth terminalCB 2RCB 7RFEATURES:The Red 202 Mini Trunking range is ideal for use on installations such as computer and power supply switches, emergency stops, panic alarms, smoke Measurements:Millimetres (mm) unless stated otherwiseAll Red 202 products are also available in white.Red Range & Non-Combustibledetectors and sounders. Red 202 surface boxes have mini trunking opening ready prepared and are complete with earth terminals. Red 202 provides immediate identification of critical safety and alarm circuits.DESCRIPTION CAT. NO. SIZE (mm) PACK QTYTrunking c/w lid CMT 2R 25 x 16 20 x 3 mSelf-adhesive trunking c/w lidCMT 2R/SA 25 x 16 20 x 3 m25 mm x 16 mm PVC Mini Trunking Red (3 m Length)CAT. NO. SIZE (mm)PACK QTYMC 2R 25 x 16 40DESCRIPTION CAT. NO. SIZE (mm) PACK QTYInternal bend MIB 2R 25 x 16 40External bend MEB 2R 25 x 16 40Flat bend MFB 2R 25 x 16 40Equal tee MT 2-2R 25 x 16 40DESCRIPTION CAT. NO. D PACK QTYSquare terminal box (1 outlet) SB 201R 44 10Square terminal box (2 outlet) SB 202R 44 10Square lid, 1 gang FL 1R - 20Square lid, 2 gang FL 2R - 10DESCRIPTION CAT. NO. PACK QTY20 mm Back outlet box CB 1R 1020 mm Terminal box CB 2R 1020 mm Through outlet box CB 3R 1020 mm Angle box CB 4R 1020 mm T box CB 5R 1020 mm 4 Way box CB 6R 1020 mm U box CB 7R 1020 mm Y box CB 8R 1020 mm H box CB 9R 10Circular lid CCL 1R 100Steel cheesehead screw M4 X 12 MM 100END CAPCAT. NO. SIZE (mm) PACK QTYMEC 2R 25 x 16 100Products made to order.Products made to order.

41| CENTAURCENTAUR18th EDITION WIRING REGULATION PRODUCTSMeasurements:Millimetres (mm) unless stated otherwiseRed Range & Non-CombustibleFEATURES:521.10.202“Regulation requires cables to be adequately supported against the premature collapse in the event of a fire.”DESCRIPTION CAT. NO.80 mm Long fire resistant steel cable retainerSuitable for: Outer compartments of ACD 4 & ACD 5, Kensington, CMT 0 - CMT 4 & CMT 5 when divider is installedQ-CLIP80222 mm Long fire resistant steel cable retainerSuitable for: Meridian, President centre compartment & ASD 1, ACD 2 & ASKT 3 outer compartments, Campus Range, Maxi Trunking & CMT 5Q-CLIP222Q-CLIPNON-COMBUSTIBLE FIRE CLIPS• 18th Edition wiring regulations section 521.10.202 compliant• Non-combustible• Manufactured from steel• Suitable for a range of different sized compartmentsQ-CLIP222NON-COMBUSTIBLE STEEL SPACER BAR SADDLESDESCRIPTION CAT. NO. PACK QTY20 mm Steel saddle bar, white SSBS 20W4025 mm Steel saddle bar, white SSBS 25W4020 mm Steel saddle bar, black SSBS 20B4025 mm Steel saddle bar, black SSBS 25B40• Colour coordinated to suit Centaur’s 20 & 25 mm conduit• Compliant to the 18th Edition of the Wiring Regulations• Ensure suitably non-combustible fixings are used to secure to wall surfacesSSBS 20W SSBS 25BDesigned to be installed where cable capacity does not exceed 45% of the trunking.

42CENTAUR |PVCu HIGH IMPACT CONDUITSUPER HIGH IMPACT CONDUIT, HEAVY GAUGEHG 20WManufactured to comply with BS 4607 Part 5.SUPER HIGH IMPACT CONDUIT, LIGHT GAUGEHIGH IMPACT OVAL CONDUITHIGH IMPACT CHANNELOCO 1500WLG 20WCH 150WFEATURES:Manufactured in accordance to: BS 4607 Part 5; BSEN 50086-2-1 (1996); BSEN 61386-21 (2004) formerly BS 6099. Measurements:Millimetres (mm) unless stated otherwiseConduit & accessories: Available as standard black or white.ConduitTested regularly to high quality standards, the Centaur super high impact conduit provides an easy and secure method of cable management. Heavy gauge and light gauge options are available to suit a variety of applications.SIZE NOM. DEPTH CAT. NO. PACK QTY13 mm 7.4 mm CH 050W 50 x 2 m25 mm 8.0 mm CH 100W 50 x 2 m38 mm 8.5 mm CH 150W 50 x 2 mSIZE NOM. WALL THICKNESS CAT. NO. PACK QTY13 mm 0.9 mm OCO 500W 50 x 3 m16 mm 0.9 mm OCO 625W 50 x 3 m20 mm 0.9 mm OCO 750W 50 x 3 m25 mm 1.0 mm OCO 1000W 50 x 3 m32 mm 1.0 mm OCO 1250W 20 x 3 m38 mm 1.3 mm OCO 1500W 20 x 3 mSIZE NOM. WALL THICKNESSCAT. NO. PACK QTY20 mm 1.3 mm LG 20 30 x 3 m25 mm 1.52 mm LG 25 30 x 3 m32 mm 1.52 mm LG 32* 10 x 3 m38 mm 1.52 mm LG 38* 10 x 3 m50 mm 1.9 mm LG 50* 10 x 3 mSIZE NOM. WALL THICKNESSCAT. NO. PACK QTY20 mm 1.8 mm HG 20* 30 x 3 m25 mm 1.9 mm HG 25* 30 x 3 m32 mm 2.4 mm HG 32 10 x 3 m38 mm 2.44 mm HG 38 10 x 3 m50 mm 3.05 mm HG 50 10 x 3 m* - Selected conduit & accessories also available in red.* - Products made to order.

43| CENTAURCENTAURFLEXIBLE CONDUIT & FIXINGS ACCESSORIESFLEXIBLE CONDUITFLEXIBLE CONDUIT ADAPTORCOUPLEREXPANSION COUPLERExpansion couplers should be installed when a run exceeds 6m or on lengths adjacent to two fixed points.MALE ADAPTORCAF 2WCEC 20WCSC 50W CMA 38WCFP-25W-10M-CP*Measurements:Millimetres (mm) unless stated otherwiseConduit & accessories: Available as standard black or white.ConduitDESCRIPTION CAT. NO. PACK QTY20 mm Male adaptor CMA 20 10025 mm Male adaptor CMA 25 7032 mm Male adaptor CMA 32* 2538 mm Male adaptor CMA 38 2550 mm Male adaptor CMA 50* 10DESCRIPTION CAT. NO. PACK QTY20 mm Coupler CSC 20 10025 mm Coupler CSC 25 5032 mm Coupler CSC 32 2538 mm Coupler CSC 38 1550 mm Coupler CSC 50* 10DESCRIPTION CAT. NO. PACK QTY20 mm Flexible conduit adaptor CAF 2 5025 mm Flexible conduit adaptor CAF 3 50DESCRIPTION CAT. NO. PACK QTY20 mm Expansion coupler CEC 20 5025 mm Expansion coupler CEC 25 25DESCRIPTION CAT. NO.20 mm Flexible conduit, 50 m CFP 225 mm Flexible conduit, 50 m CFP 320 mm Ø, 10 m Flexible conduit c/w 10x glands. White (PVCu) CFP-20W-10M-CP25 mm Ø, 10 m Flexible conduit c/w 10x glands. White (PVCu) CFP-25W-10M-CP20 mm Ø, 10 m Flexible conduit c/w 10x glands. Black (PVCu) CFP-20B-10M-CP25 mm Ø, 10m Flexible conduit c/w 10x glands. Black (PVCu) CFP-25B-10M-CP* - Products made to order. * - Products made to order.

44CENTAUR |CONDUIT FIXING ACCESSORIESSCREWED LOCKRING FEMALE ADAPTORSCREWED LOCKNUTSCREWED MALE BUSHSPACER BAR SADDLE STRAP SADDLECFA 50WCMB 32WCLR 20W93WSBS 32W SS 32WScrews not included.Measurements:Millimetres (mm) unless stated otherwiseConduit & accessories: Available as standard black or white.ConduitDESCRIPTION CAT. NO. PACK QTY20 mm Female adaptor CFA 20 10025 mm Female adaptor CFA 25 5032 mm Female adaptor CFA 32 2538 mm Female adaptor CFA 38* 2550 mm Female adaptor CFA 50* 10DESCRIPTION CAT. NO. PACK QTY20 mm Screwed lockring CLR 20 10025 mm Screwed lockring CLR 25 10032 mm Screwed lockring CLR 32 5038 mm Screwed lockring CLR 38* 2550 mm Screwed lockring CLR 50* 25DESCRIPTION CAT. NO. PACK QTY20 mm Screwed male bush CMB 20 10025 mm Screwed male bush CMB 25 10032 mm Screwed male bush CMB 32 5038 mm Screwed male bush CMB 38* 2550 mm Screwed male bush CMB 50* 25DESCRIPTION CAT. NO. PACK QTY20 mm Screwed locknut 93 10025 mm Screwed locknut 94 100DESCRIPTION CAT. NO. PACK QTY20 mm Spacer bar saddle SBS 20 10025 mm Spacer bar saddle SBS 25 10032 mm Spacer bar saddle SBS 32 5038 mm Spacer bar saddle SBS 38 2550 mm Spacer bar saddle SBS 50 25DESCRIPTION CAT. NO. PACK QTY20 mm Strap saddle SS 20 10025 mm Strap saddle SS 25 10032 mm Strap saddle SS 32 10038 mm Strap saddle SS 38 2550 mm Strap saddle SS 50 25NON-COMBUSTIBLE STEEL SPACER BAR SADDLESDESCRIPTION CAT. NO. PACK QTY20 mm Steel saddle bar, white SSBS 20W4025 mm Steel saddle bar, white SSBS 25W4020 mm Steel saddle bar, black SSBS 20B4025 mm Steel saddle bar, black SSBS 25B40• Colour coordinated to suit Centaur’s 20 & 25 mm conduit• Compliant to the 18th Edition of the Wiring Regulations• Ensure suitably non-combustible fixings are used to secure to wall surfacesSSBS 20W SSBS 25B18thEDITION* - Products made to order. * - Products made to order.* - Products made to order.

45| CENTAURCENTAURCONDUIT FIXING ACCESSORIESROUND CONDUIT CLIPOVAL CONDUIT CLIPINSPECTION ELBOW, BEND & TEESLIP BENDHEAVY GAUGE BENDREDUCER & ADAPTORSCS 20WCOC 4WCIE 20WCSB 20WCHB 25WCR 2WMeasurements:Millimetres (mm) unless stated otherwiseConduit & accessories: Available as standard black or white.ConduitDESCRIPTION CAT. NO. PACK QTY20 mm Round conduit clip SCS 20 10025 mm Round conduit clip SCS 25 100DESCRIPTION CAT. NO. PACK QTY13 mm Oval conduit clip COC 1W 10016 mm Oval conduit clip COC 2W 10020 mm Oval conduit clip COC 3W 10025 mm Oval conduit clip COC 4W 100DESCRIPTION CAT. NO. PACK QTY20 mm Inspection elbow CIE 20 5020 mm Inspection bend CIB 20 3025 mm Inspection bend CIB 25 2020 mm Inspection tee CIT 20 4025 mm Inspection tee CIT 25 5DESCRIPTION CAT. NO. PACK QTY20 mm Slip bend CSB 20 2525 mm Slip bend CSB 25 20DESCRIPTION CAT. NO. PACK QTY25-20 mm Reducer CR 2 10020 mm Oval to round conduit adaptorCOR 20 100DESCRIPTION CAT. NO. PACK QTY20 mm c/w Couplers CHB 20 2525 mm c/w Couplers CHB 25 1532 mm c/w Couplers CHB 32 238 mm c/w Couplers CHB 38* 250 mm c/w Couplers CHB 50* 2* - Products made to order.

46CENTAUR |CONDUIT BOXESPLAIN BOXTERMINAL BOXTHROUGH BOXANGLE BOXTEE BOX 4 WAY BOX20 CRB 2W20 CRB 3W 20 CRB 4W20 CRB 5W 20 CRB 6WFEATURES:Lid fixing centres approx. 50.8 mm. M4 brass inserts in pillars. Moulded recess for earth terminals (Ref ET 1). Boxes without lugs are suitable for loads up to 3kg centrally, at 60º maximum. Measurements:Millimetres (mm) unless stated otherwiseConduit & accessories: Available as standard black or white.ConduitBoxes with external lugs, riveted to M4 brass inserts in pillars are suitable for suspending loads up to 10kg centrally, at 60º maximum. External lugs can be used for screw fixing to the structure or keyed into concrete slab.DESCRIPTION CAT. NO. PACK QTYPlain box 20 CRB 1 5DESCRIPTION CAT. NO. PACK QTY20 mm Terminal box 20 CRB 2 3025 mm Terminal box 25 CRB 2 20DESCRIPTION CAT. NO. PACK QTY20 mm Through box 20 CRB 3 3025 mm Through box 25 CRB 3 20DESCRIPTION CAT. NO. PACK QTY20 mm Angle box 20 CRB 4 3025 mm Angle box 25 CRB 4 20DESCRIPTION CAT. NO. PACK QTY20 mm Tee box 20 CRB 5 2025 mm Tee box 25 CRB 5 20DESCRIPTION CAT. NO. PACK QTY20 mm 4 Way box 20 CRB 6 2025 mm 4 Way box 25 CRB 6 5

47| CENTAURCENTAURCONDUIT BOXESLOOP IN BOXY & U BOXLIDS & EARTH ELECTRODE BOX20 CRB 14WEXTENSION RINGCONDUIT BOX GASKET SEALCXR 20WCCL 1WADAPTABLE BOXMeasurements:Millimetres (mm) unless stated otherwiseConduit & accessories: Available as standard black or white.ConduitDESCRIPTION CAT. NO. PACK QTY20 mm With 4 x 20 mm knockouts 20 CRB 13 1DESCRIPTION CAT. NO. PACK QTY20 mm Y box 20 CRB 14 120 mm U box 20 CRB 15 1DESCRIPTION CAT. NO. PACK QTYCircular lid CCL 1 100Overlapping lid, 85 mm dia. CCL 0 10020 mm Earth electrode box, black CEB 1B 1DESCRIPTION CAT. NO. PACK QTY12.5 mm Extension ring CXR 12* 5020 mm Extension ring CXR 20 5025 mm Extension ring CXR 25 5038 mm Extension ring CXR 38* 2050 mm Extension ring CXR 50* 10DESCRIPTION CAT. NO. PACK QTYRubber gasket seal CRG 1 100DESCRIPTION CAT. NO. PACK QTY75 x 75 x 50 mm Adaptable box CAB 1 5* - Products made to order.

48CENTAUR |CONDUIT BOXES & ACCESSORIESTERMINAL & THROUGH BOXANGLE BOX32 SRB 2WBELL MOUTH BUSHCBB 20WSCREWED CONDUIT PLUGHEAVY GAUGE CONDUIT BENDING SPRING LIGHT GAUGE CONDUIT BENDING SPRINGCHS 20 CLS 20IP55 NYLON COMPRESSION GLANDS251WCPS 20WCompression glands available in white, black & red.Measurements:Millimetres (mm) unless stated otherwiseConduit & accessories: Available as standard black or white.ConduitDESCRIPTION CAT. NO. PACK QTY32 mm Terminal box 32 SRB 2 532 mm Through box 32 SRB 3 5DESCRIPTION CAT. NO. PACK QTY32 mm Angle box 32 SRB 4 5DESCRIPTION CAT. NO. PACK QTY20 mm Bell mouth bush CBB 20 10025 mm Bell mouth bush CBB 25 100DESCRIPTION CAT. NO. PACK QTY20 mm Screwed conduit plug CPS 20 10025 mm Screwed conduit plug CPS 25 100DESCRIPTION CAT. NO. PACK QTY20 mm Heavy gauge bending spring (green tips)CHS 20 125 mm Heavy gauge bending spring (green tips)CHS 25 1DESCRIPTION CAT. NO. PACK QTY20 mm Light gauge bending spring (red tips)CLS 20 125 mm Light gauge bending spring (red tips)CLS 25 1DESCRIPTION CAT. NO. PACK QTY20 mm Small for 7.0-10.5 dia. cables 251 10020 mm Large for 8.0-13.0 dia. cables 252 10020 mm Large plain end for 8.0-13.0 dia. cables 252 P 10025 mm For 12.0-18.0 dia. cables 254* 100Products made to order. Product made to order.* - Product made to order.

49| CENTAURCENTAURCONDUIT ACCESSORIESADHESIVEWaterproof adhesive (Permanent) 250 ml tin vinyl solvent cement for making watertight joints between PVCu conduit and fittings.NYLON DRAW TAPECDT 30SLEEVING HANKSBLUE 5/6MULTI SLEEVING REELSMulti 2/3SINGLE SLEEVING REELSBROWN REEL 3/4Add suffix: 3/4 (3 mm i/d 4 mm o/d). 4/5 (4 mm i/d 5 mm o/d). 5/6 (5 mm i/d 6 mm o/d)Add suffix: 3/4 (3 mm i/d 4 mm o/d). 4/5 (4 mm i/d 5 mm o/d).Measurements:Millimetres (mm) unless stated otherwiseConduitDESCRIPTION CAT. NO. PACK QTY250 ml Waterproof adhesive, permanent SA 2 1DESCRIPTION CAT. NO. PACK QTY10 m Nylon draw tape CDT 10 120 m Nylon draw tape CDT 20 130 m Nylon draw tape CDT 30 1DESCRIPTION CAT. NO. PACK QTY2 mm i/d 3 mm o/d - Blue BLUE 2/3 100 m2 mm i/d 3 mm o/d - Brown BROWN 2/3 100 m2 mm i/d 3 mm o/d - Green / yellow GYE 2/3 100 mDESCRIPTION CAT. NO. PACK QTY2 mm i/d 3 mm o/d - blue BLUE REEL 2/3 100 m2 mm i/d 3 mm o/d - brown BROWN REEL 2/3 100 m2 mm i/d 3 mm o/d - Green / yellow GYE REEL 2/3 100 mDESCRIPTION CAT. NO. PACK QTY2 mm i/d 3 mm o/d MULTI 2/3 60 m G/Y, 20 m blue & brown3 mm i/d 4 mm o/d MULTI 3/4 60 m G/Y, 20 m blue & brown4 mm i/d 5 mm o/d MULTI 4/5 40 m G/Y, 10 m blue & brownST 2TAPEDESCRIPTION L (m) CAT. NO. PACK QTY12 mm Double sided self adhesive foam tape 50 ST 1 118 mm Double sided self adhesive foam tape 50 ST 2 1

50CENTAUR |SURFACE & SOCKET BOXESFLUSH FITTING SOCKET BOXCSU/8/1ALSBR/3W1 GANG SURFACE BOX CONDUIT KNOCKOUT1 GANG SURFACE BOX PLAIN SIDES1 GANG SURFACE BOX MINI TRUNKING CUTOUTS1 GANG SURFACE BOX MULTI ENTRYSBP 9WSB 3WSB 3/20WSupplied with 1 fixed lug & 1 adjustable lug.Measurements:Millimetres (mm) unless stated otherwiseSurface & Socket BoxesDESCRIPTION CAT. NO. PACK QTY1 Gang, 35 mm deep. 8 x 20 mm round knockoutsCSU/8/1AL 202 Gang, 35 mm deep. 12 x 20 mm round knockoutsCSU/8/2AL 10DESCRIPTION CAT. NO. PACK QTY32 mm Deep, square corners SBR/3W 2032 mm Deep, rounded corners SBR/7W 2044 mm Deep, square corners SBR/9W 10DESCRIPTION CAT. NO. PACK QTY25 mm Deep, square corners SBP 1W* 2032 mm Deep, square corners SBP 3W 2025 mm Deep, rounded corners SBP 5W* 2032 mm Deep, rounded corners SBP 7W 2044 mm Deep, square corners SBP 9W 10PVCu Surface Box Plain Sides Round Corners White• Self-extinguishing• High Impact Resistant PVCu• Compliant to BS 4662DESCRIPTION CAT. NO. PACK QTY25 mm Deep, square corners SB 1W 2032 mm Deep, square corners SB 3W 2025 mm Deep, rounded corners SB 5W 2032 mm Deep, rounded corners SB 7W 20DESCRIPTION CAT. NO. PACK QTY32 mm Deep, square corners SB 3/20W 2032 mm Deep, rounded corners SB 7/20W 20* - Products made to order.

51| CENTAURCENTAURSBR/4WSurface boxes manufactured to comply with BS 4662.2 GANG SURFACE BOX CONDUIT KNOCKOUT2 GANG SURFACE BOX PLAIN SIDES2 GANG SURFACE BOX MINI TRUNKING CUTOUTS2 GANG SURFACE BOX - MULTI ENTRYSBP 2WSB 4WSB 4/20WSURFACE & SOCKET BOXESMeasurements:Millimetres (mm) unless stated otherwiseSurface & Socket BoxesDESCRIPTION CAT. NO. PACK QTY32 mm Deep, square corners SBR/4W 1032 mm Deep, rounded corners SBR/8W 1044 mm Deep, square corners SBR/10W 5DESCRIPTION CAT. NO. PACK QTY25 mm Deep, square corners SBP 2W* 1032 mm Deep, square corners SBP 4W 1025 mm Deep, rounded corners SBP 6W* 1032 mm Deep, rounded corners SBP 8W 1044 mm Deep, square corners SBP 10W 5DESCRIPTION CAT. NO. PACK QTY25 mm Deep, square corners SB 2W 1032 mm Deep, square corners SB 4W 1025 mm Deep, rounded corners SB 6W 1032 mm Deep, rounded corners SB 8W 10DESCRIPTION CAT. NO. PACK QTY32 mm Deep, square corners SB 4/20W 1032 mm Deep, rounded corners SB 8/20W 10* - Products made to order.

52CENTAUR |FASTERFIX DRY LINING BOXES1 GANG DRY LINING BOX SPRING ACTION LUGS2 GANG DRY LINING BOX SPRING ACTION LUGS1 GANG DEEP DRY LINING BOX SPRING ACTION LUGS2 GANG DEEP DRY LINING BOX SPRING ACTION LUGSDUAL 1 + 1 GANG DRY LINING BOX SPRING ACTION LUGSDUAL 1 + 2 GANG DRY LINING BOX SPRING ACTION LUGS Measurements:Millimetres (mm) unless stated otherwiseDry Lining BoxesDESCRIPTION CAT. NO. QTYDepth 35 mm, board thickness 6 - 16 mm CDLB 1+2W 6DESCRIPTION CAT. NO. QTYDepth 35 mm, board thickness 6 - 16 mm CDLB 1+1W 10DESCRIPTION CAT. NO. QTYDepth 47 mm, aperture 73 mm x 134 mm, board thickness 10 mm - 26 mm CDLB2-47 5DESCRIPTION CAT. NO. QTYDepth 35 mm, aperture 73 mm x 133 mm, board thickness 6 mm - 16 mm CDLB2-35 5DESCRIPTION CAT. NO. QTYDepth 47 mm, aperture 74 mm x 73 mm, board thickness 10 mm - 26 mmCDLB1-47 10DESCRIPTION CAT. NO. QTYDepth 35 mm, aperture 73 mm x 73 mm, board thickness 6 mm - 16 mm CDLB1-35 10• Spring action lugs will self align to thickness between 6 mm & 16 mm• Conforms to BS4662• Made from self-extinguishing PVCuSPRINGACTIONLUGSCIRCULAR DRY LINING BOXDESCRIPTION CAT. NO. PACK QTY2x 20 mm back entry, depth 55.2 mm, aperture 70 mm, board thickness 9 mm - 31 mm, fixing centres 50.8 mmCDLBR 45 10

53| CENTAURCENTAURDRY LINING BOXES1 GANG DRY LINING BOX2 GANG DRY LINING BOX1 GANG DEEP DRY LINING BOX2 GANG DEEP DRY LINING BOXCIRCULAR DRY LINING BOXMeasurements:Millimetres (mm) unless stated otherwiseDry Lining BoxesDESCRIPTION CAT. NO. PACK QTYDepth 35 mm, aperture 73 mm x 73 mm, board thickness 2 mm - 19 mm CDLB 1W 10DESCRIPTION CAT. NO. PACK QTYDepth 46 mm, aperture 73 mm x 73 mm, board thickness 2 mm - 30 mmCDLB 3W 10DESCRIPTION CAT. NO. PACK QTYDepth 35 mm, aperture 73 mm x 133 mm, board thickness 2 mm - 19 mmCDLB 2W 5DESCRIPTION CAT. NO. PACK QTYDepth 46 mm, aperture 73 mm x 133 mm, board thickness 2 mm - 30 mmCDLB 4W 5DESCRIPTION CAT. NO. PACK QTYDouble back entry, depth 36 mm, aperture 63.5 mm, board thickness 2 mm - 20 mm, fixing centres 50.8 mmCDLBR 5W 10

54CENTAUR |BESPOKE PRODUCT FEATURES3.Guidance led support direct from the manufacturer.2.Precision made products to suit exact specifications.1.Quick and efficient lead times to suit customer requirements.FEATURES:Using their specialised and experienced fabrication department, Centaur are able to provide bespoke cable management solutions to a variety of applications within all sectors of the industry. Considerations such as compliance with current legislation and project budgets are taken into account at an early design stage. Based upon their technical experience, Centaur can assist projects from design through to installation with continuous innovation.Bespoke ProductsMAKE THE PRODUCT FIT THE JOB

55| CENTAURCENTAURBESPOKE PRODUCT FEATURESBespoke ProductsMulti-compartment trunking can be provided for installations that require vast amount of cables. Using Centaur’s innovative base extensions (ABX 1 & ABX 4), customers can be supplied with a large number of extra centre compartments to suit cabling requirements. Working in coordination with this product, Centaur’s flexibility enables them to fabricate accessories to maintain an aesthetically appealing system.A popular choice for specification in hospitals, Centaur offers a complete range of anti-microbial trunking and accessories. A silver based additive added into the PVCu compound enables the prevention of bacteria spreading further if the surfaces are kept free of dirt and grime. From corporate colours to Part M compliance, Centaur offers a vast array of colours and finishes to a wide range of products. A choice of extruded/moulded or paint sprayed colours/finishes can facilitate quick lead times on specialised products. Wood effect trunking is also an option to match existing fixtures with buildings, Centaur offer both a light oak and mahogany finish along with sprayed colour coordinated accessories.MULTI-COMPARTMENT TRUNKING & ACCESSORIESANTI-MICROBIAL TRUNKING & ACCESSORIESCOLOURS/FINISHESILLUMINATED TRUNKINGAvailable plain, populated or pre-wired, the Centaur illuminated trunking is a great product for quiet studying, such as university halls of residence. With the option of cool or warm white LED fitting, illuminated trunking is ideal for a range of ambience. Units are tailor made to the customer’s requirements from lengths to colour to wiring accessories.

56CENTAUR |PENDANTSPRE-WIRED & POPULATEDBEDHEAD UNITSFABRICATED ANGLESFabricated as a bespoke solution to eliminate tripping hazards and keep sockets out of arms reach from vulnerable people such as hospitals patients or students, pendants are available in a variety of lengths with a selection of wiring accessory configurations to install. Pendants are manufactured from a powder coated solid aluminium body, with a four compartment surrounding for added accessory space and a fixing plate included.Working in coordination with another of the Installation Materials Division operations, Centaur are able to offer trunking both pre-wired and populated with matching accessories. Pre-wired units vary from cut lengths of trunking to power posts to bench units and can be wired to tails or for a plug and play system.With vertical or horizontal bedhead units available, Centaur offer a wide variety of accessories made for hospital applications. Penlon or Gem 10 medical gas plates can be fitted into the centre compartment of the Meridian or President ranges to enable fixing of gas, air and vacuum outlets. These outlets along with nurse call points can be fabricated into the trunking if provided with them. Specialist angles can be fabricated to adapt to pre-existing objects in buildings e.g. odd shaped pillars or existing trunking. Odd angles can also be created to provide a more pleasing to the eye finish in difficult installations. A variety of different compartment options are also available e.g. an angle that comes down from a four compartment trunking down to a three compartment trunking. BESPOKE PRODUCTSBespoke Products

57| CENTAURCENTAURCAROUSELSPODSPIPE ENCASEMENTENDLESS POSSIBILITIESBoasting four sides and a massive twelve compartments, the Centaur carousel systems is ideal for supplying several areas with power, data and voice from a central location. Available in light PVCu, sturdy aluminium or aluminium base with a PVCu lid, carousels are a very popular source within commercial applications.For use on the large (192 mm) President chamfered compartments only, the Centaur pod accessory allows for the easy creation of a local extension (above or below the trunking run) where wiring accessories are required. Special accessories can be fabricated to order. Supplying 10 mm and 15 mm pipe clips and offering a tidy pipe trunking outlet, Centaur pipe encasement is a practical yet visibly appealing method of housing pipe work. Centaur pipe clips are capable of holding pipes that operate up to a working temperature of 80°C and the pipes should not come into contact with the trunking walls. Clips are recommended to be installed at approximately one metre intervals along the trunking length.From RCD/MCB/surge protection device housing to transparent trunking, Centaur offers a vast array of bespoke products beyond this page. To help transform ideas into products, please contact the Centaur sales office.BESPOKE PRODUCTSBespoke Products

58CENTAUR |* - Typical values for guideline purposes only. i - denotes no outlet box fitted in compartment. ii - denotes 32 mm deep outlet box fitted in compartment. iii - denotes 40 mm deep outlet box fitted in compartment. iv - denotes 60 mm radius corner guard fitted in compartment for internal/external angles. v - denotes 60 mm radius corner guard protection fitted in compartment for flat angles.MERIDIAN CABLE CAPACITY ACD 3 TECHNICAL INFORMATIONCHEMICAL RESISTANCEFIRE RESISTANCESTRENGTHPRESIDENT PVCu TRUNKINGThe PVCu material used in the manufacture of President trunking systems is resistant to most organic chemicals, solutions of organic acids, alkalis and salts. It may possibly be softened by some organic materials such as ketones and aromatic compounds. If in doubt please contact Centaur sales office.High impact resistance. The material is formulated to comply with the –5°C clause of BS 4678 Part 4 (1982), cable trunking standard.The materials used in Centaur President trunking system are non-flame propagating and comply with the requirements of BS 476 Part 7 and BS 4678 Part 4.President systems are designed to accommodate local thermal expansion and contraction. The coefficient of linear expansion: 7.0 x 10 –5°C operating temperatures –5°C to 60°C. 17360DO NOT SCALE DRAWINGMerian ProfileSHEET 1 OF 1UNLESS OTHERWISE SPECIFIED:SCALE: 1:5WEIGHT: REVDWG. NO.ASIZETITLE:NAMEDATECOMMENTS:Q.A.MFG APPR.ENG APPR.CHECKEDDRAWNFINISHMATERIALINTERPRET GEOMETRICTOLERANCING PER:DIMENSIONS ARE IN INCHESTOLERANCES:FRACTIONALANGULAR: MACH BEND TWO PLACE DECIMAL THREE PLACE DECIMAL APPLICATIONUSED ONNEXT ASSYPROPRIETARY AND CONFIDENTIALTHE INFORMATION CONTAINED IN THISDRAWING IS THE SOLE PROPERTY OF<INSERT COMPANY NAME HERE>. ANY REPRODUCTION IN PART OR AS A WHOLEWITHOUT THE WRITTEN PERMISSION OF<INSERT COMPANY NAME HERE> IS PROHIBITED.5432155173608440A B CCONDUCTOR SIZE mm2CABLE FACTORCAPACITY A @ 45% FULLCAPACITY B @ 45% FULL CAPACITY C @ 45% FULLFull Term CSA 100% FIll (mm2) 1711 i-4442; ii-1758; iii-1356; iv-3202; v-33251711PVC power stranded 1.5 8.6 i-89 i-232; ii-92; iii-71; iv-167; v-174 i-89PVC power stranded 2.5 12.6 i-61 i-158; ii-63; iii-48; iv-113; v-118 i-61PVC power stranded 4.0 16.6 i-46 i-120; ii-48; iii-37; iv-86; v-90 i-46PVC power stranded 6.0 21.2 i-36 i-94; ii-37; iii-29; iv-67; v-70 i-36Cat. 6 UTP 6.5* dia. 42.2 i-18 i-47; ii-18; iii-14; iv-33; v-35 i-18Cat. 6 STP 7.0* dia. 49.0 i-15 i-40; ii-16; iii-12; iv-28; v-30 i-15Cat. 7 8.0* dia. 64.0 i-12 1-31; ii-12; iii-9; iv-22; v-23 i-12Technical Information

59| CENTAURCENTAURTECHNICAL INFORMATIONPRESIDENT SKIRTING TRUNKING CABLE CAPACITY ASKT 3/BSKT 3W5580.61926048.5A B C* - Typical values for guideline purposes only. i - denotes no outlet box fitted in compartment. ii - denotes 32 mm deep outlet box fitted in compartment. iii - denotes 40 mm deep outlet box fitted in compartment. iv - denotes 60 mm radius corner guard fitted in compartment for internal/external angles. v - denotes 60 mm radius corner guard protection fitted in compartment for flat angles.For ASD 1/BSD 1W, use the cable capacity section C twice and section B. For ACD 2/BCD 2W, use the cable capacity section A twice and section B.CONDUCTOR SIZE mm2CABLE FACTORCAPACITY A @ 45% FULLCAPACITY B @ 45% FULL CAPACITY C @ 45% FULLPVC power stranded 1.5 8.6 i-101 i-225; ii-90; iii-71; iv-163; v-170 i-128PVC power stranded 2.5 12.6 i-69 i-153; ii-61; iii-48; iv-111; v-115 i-87PVC power stranded 4.0 16.6 i-52 i-116; ii-47; iii-36; iv-84; v-87 i-66PVC power stranded 6.0 21.2 i-41 i-91; ii-36; iii-28; iv-66; v-68 i-52Cat. 6 UTP 6.5* dia. 42.2 i-21 i-46; ii-18; iii-14; iv-33; v-35 i-26Cat. 6 STP 7.0* dia. 49.0 i-18 i-39; ii-16; iii-12; iv-28; v-30 i-22Cat. 7 8.0* dia. 64.0 i-13 i-29; ii-11; iii-8; iv-20; v-21 i-16Technical InformationPOWER POLE & POST CABLE CAPACITY AP 1/AP 2/AP 680 & ACD 4* - Typical values for guideline purposes only. i - denotes no outlet box fitted in compartment. ii - denotes 32 mm deep outlet box fitted in compartment. ACD 4 only - iii - denotes 40 mm deep outlet box fitted in compartment. iv - denotes 50 mm radius corner guard fitted in compartment for internal/external angles. v - denotes 50 mm radius corner guard protection fitted in compartment for flat angles.80.6455013521CONDUCTOR SIZE mm2CABLE FACTORCAPACITY A @ 45% FULLCAPACITY B @ 45% FULL CAPACITY C @ 45% FULLPVC power stranded 1.5 8.6 i-39 i-183; ii-53; iii-33; iv-121; v-141 i-39PVC power stranded 2.5 12.6 i-27 i-125; ii-36; iii-22; iv-83; v-96 i-27PVC power stranded 4.0 16.6 i-20 i-95; ii-27; iii-17; iv-63; v-73 i-20PVC power stranded 6.0 21.2 i-16 i-74; ii-21; iii-12; iv-49; v-57 i-16Cat. 6 UTP 6.5* dia. 42.2 i-8 i-37; ii-11; iii-6; iv-25; v-29 i-8Cat. 6 STP 7.0* dia. 49.0 i-7 i-32; ii-9; iii-5; iv-21; v-25 i-7Cat. 7 8.0* dia. 64.0 i-5 i-24; ii-6; iii-4; iv-15; v-18 i-5

60CENTAUR |CABLE CAPACITIESCAROUSEL POST CABLE CAPACITY AP 5680/6680/7680* - Typical values for guideline purposes only. i - denotes no outlet box fitted in compartment. ii - denotes 32 mm deep outlet box fitted in compartment. iii - denotes 40 mm deep outlet box fitted in compartment.C22520511065POWER POLE & POST CABLE CAPACITY AP 1, AP 2 & AP 680 * - Typical values for guideline purposes only. i - denotes no outlet box fitted in compartment. ii - denotes 32 mm deep outlet box fitted in compartment. ACD 4 only - iii - denotes 40 mm deep outlet box fitted in compartment. iv - denotes 50 mm radius corner guard fitted in compartment for internal/external angles. v - denotes 50 mm radius corner guard protection fitted in compartment for flat angles.14080.5451022222CONDUCTOR SIZE mm2CABLE FACTORCAPACITY A @ 45% FULLCAPACITY B @ 45% FULL CAPACITY C @ 45% FULLPVC power stranded1.5 8.6 i-39 i-183; ii-53; iii-33; iv-121; v-141 i-39PVC power stranded2.5 12.6 i-27 i-125; ii-36; iii-22; iv-83; v-96i-27PVC power stranded4.0 16.6 i-20 i-95; ii-27; iii-17; iv-63; v-73i-20PVC power stranded6.0 21.2 i-16 i-74; ii-21; iii-12; iv-49; v-57i-16Cat. 6 UTP 6.5* dia. 42.2 i-8 i-37; ii-11; iii-6; iv-25; v-29 i-8Cat. 6 STP 7.0* dia. 49.0 i-7 i-32; ii-9; iii-5; iv-21; v-25 i-7Cat. 7 8.0* dia. 64.0 i-5 i-24; ii-6; iii-4; iv-15; v-18 i-5Technical InformationBENCH TRUNKING CABLE CAPACITY ABT 1/DBT 1* - Typical values for guideline purposes only. i - denotes no outlet box fitted in compartment. ii - denotes 32 mm deep outlet box fitted in compartment. iii - denotes 40 mm deep outlet box fitted in compartment30110110CONDUCTOR SIZE mm2CABLE FACTORCAPACITY A @ 45% FULLCAPACITY B @ 45% FULLCAPACITY C @ 45% FULLPVC power stranded 1.5 8.6 i-64 i-288; ii-168 iii-150i-64PVC power stranded 2.5 12.6 i-44 i-197; ii-115 iii-102i-44PVC power stranded 4.0 16.6 i-33 i-150; ii-87 iii-78i-33PVC power stranded 6.0 21.2 i-26 i-117; ii-68 iii-61i-26Cat. 6 UTP 6.5* dia. 42.2 i-13 i-56; ii-32 iii-28 i-13Cat. 6 STP 7.0* dia. 49.0 i-11 i-50; ii-28 iii-25 i-11Cat. 7 8.0* dia. 64.0 i-8 i-38; ii-21 iii-19 i-8CONDUCTOR SIZE mm2CABLE FACTORCAPACITY A @ 45% FULLCAPACITY B @ 45% FULLCAPACITY C @ 45% FULLPVC power stranded 1.5 8.6 i-64 i-288; ii-168 iii-150i-64PVC power stranded 2.5 12.6 i-44 i-197; ii-115 iii-102i-44PVC power stranded 4.0 16.6 i-33 i-150; ii-87 iii-78i-33PVC power stranded 6.0 21.2 i-26 i-117; ii-68 iii-61i-26Cat. 6 UTP 6.5* dia. 42.2 i-13 i-56; ii-32 iii-28 i-13Cat. 6 STP 7.0* dia. 49.0 i-11 i-50; ii-28 iii-25 i-11Cat. 7 8.0* dia. 64.0 i-8 i-38; ii-21 iii-19 i-8

61| CENTAURCENTAURCABLE CAPACITIESCAMPUS CABLE CAPACITY DMXT 42W* - Typical values for guideline purposes only. i - denotes no outlet box or dividers fitted in compartment. ii - denotes 32 mm deep outlet box and no dividers fitted in compartment. iii - denotes 50 mm corner guard fitted for external angle only.22 222222474750200CAMPUS CABLE CAPACITY CMXT 42W, BMXT 42W & AP 3 POWER POLE* - Typical values for guideline purposes only. i - denotes no outlet box or dividers fitted in compartment. ii - denotes 32 mm deep outlet box and no dividers fitted in compartment. CMXT 42W/BMXT 42W only - iii - denotes 50 mm corner guard fitted for external angle only.CAMPUS CABLE CAPACITY CMXT 41* - Typical values for guideline purposes onlyi - denotes no outlet box or dividers fitted in compartment.2580KENSINGTONSKIRTING TRUNKING CKD22224750100100308025* - Typical values for guideline purposes onlyi - denotes no outlet box or dividers fitted in compartmentTechnical InformationCONDUCTOR SIZE mm2CABLE FACTORCAPACITY A @ 45% FULLCAPACITY B @ 45% FULLPVC power stranded 1.5 8.6 i-217; ii-64; iii-137 i-217; ii-64; iii-137PVC power stranded 2.5 12.6 i-150; ii-44; iii-95 i-150; ii-44; iii-95PVC power stranded 4.0 16.6 i-113; ii-33; iii-71 i-113; ii-33; iii-71PVC power stranded 6.0 21.2 i-88; ii-26; iii-55 i-88; ii-26; iii-55Cat. 6 UTP 6.5* dia. 42.2 i-45; ii-13; iii-28 i-45; ii-13; iii-28Cat. 6 STP 7.0* dia. 49.0 i-39; ii-11; iii-24 i-39; ii-11; iii-24Cat. 7 8.0* dia. 64.0 i-29; ii-8; iii-18 i-29; ii-8; iii-18CONDUCTOR SIZE mm2CABLE FACTORCAPACITY A @ 45% FULLCAPACITY B @ 45% FULLCAPACITY C @ 45% FULLPVC power stranded 1.5 8.6 i-48; ii-15 iii-33i-110; ii-31 iii-71i-48; ii-15 iii-33PVC power stranded 2.5 12.6 i-33; ii-10 iii-23i-75; ii-21 iii-49 i-33; ii-10 iii-23PVC power stranded 4.0 16.6 i-25; ii-8 iii-17i-57; ii-16 iii-37 i-25; ii-8 iii-17PVC power stranded 6.0 21.2 i-19; ii-6 iii-13i-45; ii-12 iii-29 i-19; ii-6 iii-13Cat. 6 UTP 6.5* dia. 42.2 i-10; ii-3 iii-7 i-22; ii-6 iii-14 i-10; ii-3 iii-7Cat. 6 STP 7.0* dia. 49.0 i-8; ii-2 iii-6 i-19; ii-5 iii-12 i-8; ii-2 iii-6Cat. 7 8.0* dia. 64.0 i-6; ii-2; iii-4 i-14; ii-4; iii-6 i-6; ii-2; iii-4CONDUCTOR SIZE mm2CABLE FACTOR CAPACITY A @ 45% FULLPVC power stranded 1.5 8.6 i-115PVC power stranded 2.5 12.6 i-77PVC power stranded 4.0 16.6 i-59PVC power stranded 6.0 21.2 i-46Cat. 6 UTP 6.5* dia. 42.2 i-23Cat. 6 STP 7.0* dia. 49.0 i-19Cat. 7 8.0* dia. 64.0 i-15CONDUCTOR SIZE mm2CABLE FACTORCAPACITY A @ 45% FULLCAPACITY B @ 45% FULLPVC power stranded 1.5 8.6 i-23 i-56PVC power stranded 2.5 12.6 i-16 i-38PVC power stranded 4.0 16.6 i-12 i-29PVC power stranded 6.0 21.2 i-9 i-23Cat. 6 UTP 6.5* dia. 42.2 i-5 i-11Cat. 6 STP 7.0* dia. 49.0 i-4 i-10Cat. 7 8.0* dia. 64.0 i-3 i-7

62CENTAUR |CONDUCTOR SIZE mm2CABLE FACTORCAPACITY A @ 45% FULLCAPACITY B @ 45% FULLPVC power stranded 1.5 8.6 i-23 i-49PVC power stranded 2.5 12.6 i-16 i-33PVC power stranded 4.0 16.6 i-12 i-25PVC power stranded 6.0 21.2 i-9 i-20Cat. 6 UTP 6.5* dia. 42.2 i-5 i-9Cat. 6 STP 7.0* dia. 49.0 i-4 i-8Cat. 7 8.0* dia. 64.0 i-3 i-6CAT. NO. SIZE NOMINAL CROSS SECTION AREA BASED ON 45 % CAPACITYCMT 0 16 mm x 10 mm 42 mm2 CMT 1 16 mm x 16 mm 66 mm2CMT 2 25 mm x 16 mm 120 mm2CMT 3 38 mm x 16 mm 185 mm2CMT 4 38 mm x 25 mm 325 mm2CMT 5 50 mm x 25 mm 410 mm2CAT. NO. SIZE NOMINAL CROSS SECTION AREA BASED ON 45 % CAPACITYCMXT 22 50 mm x 50 mm 930 mm2 CMXT 32 75 mm x 50 mm 1415 mm2CMXT 33 75 mm x 75 mm 2200 mm2CMXT 41 100 mm x 30 mm 1020 mm2CMXT 42 100 mm x 50 mm 1895 mm2CMXT 44 100 mm x 100 mm 4030 mm2TYPE OF CONDUCTORCONDUCTOR CROSS SECTIONAL AREA FACTORSolid 1.5 mm27.12.5 mm210.2Stranded 1.5 mm28.12.5 mm211.44 mm215.26 mm222.910 mm236.3Choice of trunking is normally controlled by the quantity of cable to be carried. In accordance with the requirements of IEE. wiring regulations, the space factor of trunking occupied should not exceed 45% of the cross sectional area of the section.CABLE CAPACITIESChoice of trunking is normally controlled by the quantity of cable to be carried. In accordance with the requirements of IEE wiring regulations, the space factor of trunking occupied should not exceed 45% of the cross sectional area of the section.MAXI TRUNKING SELECTION & CAPACITYPVC INSULATED SINGLECORE CABLE IN TRUNKINGFor each cable to be used, obtain the cable factors from the table above, add all factors together and compare to the capacities given.Any trunking with a space factor equal to or larger than that of the cable factors will satisfactorily accommodate the desired cables.Centaur conduit is light in weight (16% of weight of steel conduit), is clean and easy to handle, does not require the use of on site special equipment such as vice bender or thread cutting gear, is non-conductive, will not corrode or stain plaster.Centaur conduit, oval conduit and high impact channelling should be installed using the special Centaur accessories.MINI TRUNKING SELECTION & CAPACITYTechnical InformationKENSINGTONARCHITRAVE TRUNKING CDA* - Typical values for guideline purposes onlyi - denotes no outlet box or dividers fitted in compartment25808025CONDUIT SELECTION & CAPACITY

63| CENTAURCENTAURCABLE CAPACITIESCONDUIT CABLE CAPACITYCalculation system based on Appendix 12 IEE Wiring Regulations.1. Use table 12A or 12C to determine the factor for each cable being used.2. Add the appropriate cable factors and compare with the conduit factor from table 12B or 12D.3. The required conduit size is the one having a factor equal to or greater than the sum of the cable factors.Single-core PVC insulated cables in straight runs of conduit exceeding 3m in length or in runs of any length incorporating bends or sets. The information in the tables is intended only for guidance.Table 12A. Cable factors short straight runsTable 12D Conduit factors for runs incorporating bends.CONDUIT CABLE CAPACITYTechnical InformationCONDUCTOR CONDUCTOR CROSS SECTIONAL AREAFACTOR CONDUIT DIA. FACTOR CONDUCTOR CONDUCTOR CROSS SECTIONAL AREAFACTORSolid 1 mm222 16 mm 290 Solid or stranded1 mm2161.5 mm227 20 mm 460 1.5 mm2222.5 mm239 25 mm 800 2.5 mm230Stranded 1.5 mm231 32 mm 1400 4 mm2432.5 mm243 Table 12B.Conduit factors short straight runs6 mm2584 mm258 10 mm21056 mm288 Table 12C. Cable factors for long straight or runs incorporating bends 10 mm2146LENGTH OF RUN (m)CONDUIT DIAMETER (mm)16 20 25 32 16 20 25 32 16 20 25 32 16 20 25 32 16 20 25 32Straight One Bend Two Bends Three Bends Four Bends1 Covered By Tables 12A and 12B188 303 543 947 177 286 514 900 158 256 463 818 130 213 288 6921.5182 294 528 923 167 270 487 857 143 233 422 750 111 182 333 6002177 286 514 900 158 256 463 818 130 213 388 692 97 159 292 5292.5171 278 500 878 150 244 442 783 120 196 358 643 86 141 260 4743167 270 487 857 143 233 422 750 111 182 333 6003.5179 290 521 911 162 263 475 837 136 222 404 720 103 169 311 5634177 286 514 900 158 256 463 818 130 213 388 692 97 159 292 5294.5174 282 507 889 154 250 452 800 125 204 373 667 91 149 275 5005171 278 500 878 150 244 442 873 120 196 358 643 86 141 260 4746167 270 487 857 143 233 422 750 111 182 333 6007162 263 475 837 136 222 404 720 103 169 311 5638158 256 463 818 130 213 388 692 97 159 292 5299154 250 452 800 125 204 373 667 91 149 275 50010150 244 442 783 120 196 358 643 86 141 260 474Oval conduit and high impact channel are usually used for short runs in domestic situations, for external fixing or where the deep chasing required for round conduit is not possible. PVCu conduit has a rate of expansion greater than that of steel; it is therefore important to make sure that surface work allows for sliding joint into boxes or couplers, this will permit movement along the conduit run and avoid distortion. The distance between saddles or clips should not exceed 4’ 0’ (1.20 m). If possible the boxes should be fixed first and a line used to establish correct alignment, which will ease the threading of cable through the conduit. Cutting can be performed with any fine-toothed saw. Bending or forming of conduit of 25 mm Dia. or less can be achieved cold, provided the appropriate bending spring is employed internally in the location of the bend. Greater diameters may need local application of gentle heat. Cable is threaded by using the Centaur draw tape. Centaur plastic conduit cement provides a waterproof joint which is easily made by painting the female internal surface of any joint before sliding the male section in with a twisting action to spread the cement evenly.
