Metal Sales Product CatalogMetal Roof & Wall SystemsArchitecturalCommercialPost FrameResidential ACR Metal Roofing & Siding Distributors

metalsales.us.com800.406.73872Magna-Loc 90 ������������������������������������������������������������������������4Magna-Loc 180 ����������������������������������������������������������������������4T-Armor Series™ ��������������������������������������������������������������������5Seam-Loc 24® ������������������������������������������������������������������������6Snap-Loc 24 ��������������������������������������������������������������������������6Vertical Seam, Vertical Seam Plus ����������������������������������������7Clip-Loc ���������������������������������������������������������������������������������7THE METAL SALES DIFFERENCEFor more than 60 years, Metal Sales Manufacturing Corporation has earned a reputation as the premier provider of innovative metal building components and accessories� We’ve backed this reputation with the industry’s largest professional sales and service team, supported by 21 branches located throughout the United States�We offer a full line of exceptional quality metal roof and wall panels for agricultural, commercial, architectural, industrial and residential projects of every shape and size – new construction or retrot. But our technology and durable designs are only part of the story� Architects, contractors and installers appreciate the impeccable service from our highly trained professional staff, ready to answer any question, or help devise custom solutions to your building and energy saving needs� n Serving the architectural, commercial, residential, industrial and agricultural markets for over half a centuryn In-house engineering and design assistance availablen A wide selection of materials and nishes available, including MS Colorfast45®, MS Crinkle Finish, ColorFit40™, PVDF, Weathering Steel, Aluminum, Stainless Steel and Coppern Over 100 proles available with matching trim and accessoriesn Metal panels contribute to LEED pointsn 21 convenient locations nationwide, including Alaska n Quoting and shipping projects worldwiden Up to 45 year Finish Warranties availablen Panel testing including, UL 580, ASTM E 1592 and approvals including Miami-Dade County, Florida Building Code (FBC) 2023, ICC Evaluation Report, Texas Department of Insurance and Underwriters Laboratory (UL)n 30 year Weather-Tight Warranty available (on select proles)n Curving capabilities available – (see page 8)Metal Sales is dedicated to leading the metal building component industry, by setting new standards for operating efciency, product design, active service management and lasting value. We strongly believe that by investing in our corporation, we will ensure the best products and services for our customers, high job satisfaction for our employees and continued innovation and growth for our industry.Profile SelectionImage II™ �������������������������������������������������������������������������������8Mini-Batten, Curved Mini-Batten ��������������������������������������������9Maxi-Batten ���������������������������������������������������������������������������9TLC Series ����������������������������������������������������������������������10,11Apex Series (CFWP) �����������������������������������������������������������12Contempra Series (CFWP) ��������������������������������������������������12Empire Line (CFWP) �����������������������������������������������������������13Soft Panel ��������������������������������������������������������������������������14T10 Series ���������������������������������������������������������������������������157/8" Corrugated �������������������������������������������������������������������165V-Crimp ������������������������������������������������������������������������������16IC72-Panel, V-Line 32 ���������������������������������������������������������17Low Rib Series ���������������������������������������������������������������18,192" Rib Series ������������������������������������������������������������������������203" Rib Series ������������������������������������������������������������������������20Deep Rib Series ������������������������������������������������������������������21IMPACT Steel Building Systems����������������������������������������� 28Self Storage Solutions �������������������������������������������������������� 29Secondary Framing ������������������������������������������������������������ 29Retro-Master®��������������������������������������������������������������������� 30Roof Hugger® – Metal over Metal ��������������������������������������� 30 Perforation and Mitered Corners ���������������������������������������� 31Coating Systems ���������������������������������������������������������������� 31IMPower Series™ ���������������������������������������������������������������� 27PBR-Panel, R-Panel �����������������������������������������������������������22PBU-Panel, U-Panel �����������������������������������������������������������22Pro-Panel II® ����������������������������������������������������������������������� 23Classic Rib® ������������������������������������������������������������������������ 231�25" Corrugated ����������������������������������������������������������������242�5" Corrugated ������������������������������������������������������������������24Strongpanel ������������������������������������������������������������������������ 25DL-3 Panel ��������������������������������������������������������������������������25Bi-Rib, Delta Rib, Dual Rib �������������������������������������������������26STANDING SEAM PANELSCONCEALED FASTENED PANELSEXPOSED FASTENED PANELSMETAL BUILDING PANELSINSULATED WALL & ROOF PANELSBUILDINGS & COMPONENTS

800.406.7387metalsales.us.com3

metalsales.us.com800.406.73874 Architectural/structural at pan standing seam roof panel 16" or 18" panel coverage, 2" rib height Gauges: 24 ga� standard, 22 ga� optional Minimum roof slope: 1/2:12 Factory-applied side lap sealant Mechanically seamed side lap Concealed clip designed for thermal movement Accommodates 1/2" to 6" blanket insulation Applies over open framing or solid substrate Finishes: PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilities Architectural/structural at pan standing seam roof panel 16" or 18" panel coverage, 2" rib height Gauges: 24 ga� standard, 22 ga� optional Minimum roof slope: 1/2:12 Factory-applied side lap sealant Mechanically seamed side lap Concealed clip designed for thermal movement Accommodates 1/2" to 6" blanket insulation Applies over open framing or solid substrate Finishes: PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilitiesw UL 263, Fire Resistance Rating – per assemblyw UL 580, Class 90 Wind Uplift, Construction #576, 577 and 583w UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew ASTM E 1592 Roof Upliftw ASTM E 1646 Water Penetrationw ASTM E 1680 Air Leakagew 2023 FBC Approved – Magna-Loc 180 24 ga� over 16 ga� Purlins, FL10999�6 (16" Panel)w UL 263, Fire Resistance Rating – per assemblyw UL 580, Class 90 Wind Uplift, Construction #506, 506A and 506Bw UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew ASTM E 1592 Roof Uplift w ASTM E 1646 Water Penetration - none at 12 psf*w ASTM E 1680 Air Leakage - 0�016 cfm/ft2 at 12 psf*w ASTM E 2140 Water Penetration, Static Head - none*w Texas Department of Insurance Evaluation Report, RC-197w Factory Mutual Approved, 1-90, 1-105, 1-165w Miami-Dade County Approved, NOA 23-1011�10 and 23-1011�11 w ICC Evaluation Report, ESR-2385w 2023 FBC Approved – Magna-Loc 90 24 ga� over 16 ga� Purlins, FL10999�5 (16" Panel) – Magna-Loc 90 24 ga� over 5/8" Plywood, FL11560�5 (16" Panel) – Magna-Loc 90 24 ga� over 22 ga� Metal Deck, FL11560�6 (16" Panel) – Magna-Loc 90 0�032" Alum over 22 ga� Metal Deck, FL10999�2 (16" Panel)*with tube sealant at clip locations16" Coverage16" or 18" Coverage16" or 18" Coverage2"2"2"Factory-Applied SealantFactory-Applied SealantFactory-Applied Sealant16" Coverage16" or 18" Coverage16" or 18" Coverage2"2"2"Factory-Applied SealantFactory-Applied SealantFactory-Applied Sealant16" Coverage16" or 18" Coverage16" or 18" Coverage2"2"2"Factory-Applied SealantFactory-Applied SealantFactory-Applied Sealant16" Coverage16" or 18" Coverage16" or 18" Coverage2"2"2"Factory-Applied SealantFactory-Applied SealantFactory-Applied Sealant16" Coverage16" or 18" Coverage16" or 18" Coverage2"2"2"Factory-Applied SealantFactory-Applied SealantFactory-Applied SealantTesting and ApprovalsTesting and ApprovalsStriatedStriatedPencil RibsFlatPencil RibsFlat16" Coverage16" or 18" Coverage16" or 18" Coverage2"2"2"Factory-Applied SealantFactory-Applied SealantFactory-Applied SealantMagna-Loc 90Magna-Loc 180

800.406.7387metalsales.us.com5 Structural "T" standing seam roof panel 12", 16" or 18" panel coverage Rib Height: 2-3/8" or 3" Finishes: PVDF and Acrylic Coated Galvalume® Gauges: 24 ga� standard, 22 ga� optional Aluminum: 0�032" Minimum roof slope: 1/2:12 Integral mechanically seamed side lap "T" style rib allows for easy single panel replacement Factory-applied side lap sealant Concealed clip designed for thermal movement Accommodates 1/2" to 6" blanket insulation Applies over open framing or solid substrate Contact Metal Sales for load-carrying capabilitiesTesting and Approvalsw UL 263, Fire Resistance Rating – per assemblyw UL 580, Class 90 Uplift, Construction #268, 268A and 268Bw UL 790, Class A Fire Resistance Rating – per assemblyw UL 1897, Uplift Loadw UL 2218, Class 4 Impact Resistancew ASTM E 283 Air Inltrationw ASTM E 330 Uniform Static Air Pressure Differencew ASTM E 331 Water Penetrationw ASTM E 1592 Roof Upliftw ASTM E 1646 Water Penetrationw ASTM E 1680 Air Leakagew ASTM E 1886, 1996 Impact w ASTM E 2140 Water Penetration, Static Head - none*w TAS 201, 203 Impactw TAS 100, Wind Driven Rainw ICC 500 / FEMA 361w AAMA 501�1, Dynamic Waterw FM 4470, Foot Trafc*with tube sealant at clip locations2-3/8” or 3”12”, 16” or 18” CoverageFlat2-3/8” or 3”12”, 16” or 18” Coverage2-3/8” or 3”12”, 16” or 18” Coverage2-3/8” or 3”12”, 16” or 18” CoverageMinor Rib2-3/8” or 3”12”, 16” or 18” CoveragePlank12”, 16” or 18” Coverage2-3/8” or 3”MesaT-Armor SeriesTMStriatedPencil Rib

metalsales.us.com800.406.73876 Structural trapezoidal standing seam roof panel 24" panel coverage, 2-11/16" rib height Gauges: 24 ga� standard, 22 ga� optional Minimum roof slope: 1/4:12 Factory-applied side lap sealant Pittsburgh double at locking mechanically seamed side lap Concealed clip designed for thermal movement Accommodates 1/2" to 6" blanket insulation Applies over open framing or solid substrate Finishes: PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilitiesw UL 263, Fire Resistance Rating – per assemblyw UL 580, Class 90 Wind Uplift, Construction, #197 and 197Aw UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew ASTM E 1592 Roof Upliftw ASTM E 1646 Water Penetrationw ASTM E 1680 Air Leakagew Factory Mutual Approved, 1-90 and 1-165w 2023 FBC Approved – 24" wide over 16 ga� Purlins, FL10999�8 – 24" wide (with clamps) over 16 ga� Purlins, FL10999�9 Structural trapezoidal standing seam roof panel 24" panel coverage, 3" rib height Gauges: 24 ga� standard, 22 ga� optional Minimum roof slope: 1/4:12 Factory-applied side lap sealant Snap-together panel system Concealed clip designed for thermal movement Accommodates 1/2" to 6" blanket insulation Applies over open framing or solid substrate Finishes: PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilitiesw UL 263, Fire Resistance Rating – per assemblyw UL 580, Class 90 Uplift, Construction, #240w UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew ASTM E 330, Uniform Static Air Pressure Differencew ASTM E 1592 Roof Upliftw ASTM E 1646 Water Penetrationw ASTM E 1680 Air LeakageTesting and ApprovalsTesting and Approvals24" Coverage2-11/16"Factory-Applied Sealant24" Coverage3"Factory-Applied SealantSeam-Loc 24®Snap-Loc 24®

800.406.7387metalsales.us.com7w UL 263, Fire Resistance Rating – per assemblyw UL 580, Class 90 Wind Uplift, Construction, #254, 255, 261, 303, 342, 343, 436, 445, 446, 447, 448, 508 and 508Aw UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew ASTM E 1592 Roof Upliftw ASTM E 1646 Water Penetrationw ASTM E 1680 Air Leakagew Miami-Dade County Approved, NOA 18-1227�01w Texas Department of Insurance Evaluation Report, RC-412w ICC Evaluation Report, ESR-2385w 2023 FBC Approved –26 ga� over 1/2" Plywood, FL11560�9 (16" Panel) –24 ga� over 1/2" Plywood, FL11560�7 (16" Panel) –24 ga� over 1/2" Plywood, FL11560�8 (18" Panel) –0�032" Aluminum over 7/16" OSB, FL14645�4 (16" Panel) –0�032" Aluminum over 5/8" Plywood, FL14645�5 (16" Panel) Architectural/structural standing seam panel Panel Coverage: 12", 16" or 18"  Rib Height: 1-3/4" Gauges: 26 ga� and 24 ga� standard, 22 ga� optional Snap-together panel system with factory-applied side lap sealant Minimum roof slope over open framing 3:12 Minimum roof slope over solid substrate 1:12 Concealed clip designed for unlimited thermal movement Accommodates up to 4" blanket insulation Finishes: PVDF, MS Colorfast45® and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilities Architectural/structural integral standing rib roof system Snap-together panel system 16" panel coverage, major rib: 8" centers, 1-5/8" rib height Gauges: 26 ga�, 24 ga� standard and 22 ga� optional Minimum roof slope: 1:12 Applies over open framing or solid substrate Concealed clip designed for thermal movement Accommodates up to 4" blanket insulation Finishes: PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilitiesw UL 263, Fire Resistance Rating – per assemblyw UL 580, Class 90 Wind Uplift, Construction, #586 and 586Aw UL 790, Class A Fire Resistance Rating – per assemblyw UL 1897, Uplift Tests for Roof Covering Systemsw UL 2218, Class 4 Impact Resistancew ASTM E 1592 Roof Uplift w ASTM E 1680 Air Leakagew ICC Evaluation Report, ESR-2385Testing and ApprovalsTesting and ApprovalsStriatedFlat Pan12", 16" or 18" Coverage1-7/8"1-5/8"Vertical Seam Plus Square Batten Cap option for Vertical Seam Panel Available at the Fontana Branch only12",16" or 18" Coverage1-3/4"12" or16" Coverage1-3/4"12",16" or 18" Coverage1-3/4"12" or16" Coverage1-3/4"16" Coverage1-5/8"8"Vertical SeamClip-Loc

metalsales.us.com800.406.73878 Architectural concealed direct-fastened roof panel  Panel coverage: 12" or 16"  1" rib height  Gauges: 26 ga� standard  Minimum roof slope: 3:12  Applies over solid substrate with 30# felt underlayment  Finishes: MS Colorfast45®, PVDF and Acrylic Coated Galvalume®  Contact Metal Sales for load-carrying capabilitiesw UL 263, Fire Resistance Rating – per assembly w UL 580, Class 90 Wind Uplift, Construction, #529w UL 790, Class A Fire Resistance Rating – per assembly w UL 2218, Class 4 Impact Resistancew Miami-Dade County approved, NOA 23-0711�05 w Texas Department of Insurance Evaluation Reports, RC-162, RC-398 and RC-399w ICC Evaluation Report, ESR-2385 w 2023 FBC Approved –26 ga� over 1/2" Plywood, FL11560�4 –26 ga� over 7/16" OSB, FL14645�10 –0�032" Aluminum over 7/16" OSB, FL11560�2 –0�032" Aluminum over 1/2" Plywood, FL11560�3Testing and ApprovalsStriatedFastening GrooveSlotted FlatFastening legs vary by branch16" Minor RibFastening GrooveSlotted FlatFastening legs vary by branch12" Minor RibFastening GrooveSlotted FlatFastening legs vary by branch12" or 16" Coverage1"1"12" Coverage16" Coverage1"12" or 16" Coverage1"1"12" Coverage16" Coverage1"12" or 16" Coverage1"1"12" Coverage16" Coverage1"Image II

800.406.7387metalsales.us.com9 Architectural standing seam roof panel  12", 16" or 18" panel coverage, minimum roof slope: 3:12  Mini-Batten offers, 1" & 1-1/2" high rib utilizing a narrow batten cap  Gauges: 26 ga� and 24 ga� standard, 22 ga� optional  Concealed clip designed for thermal movement  Applies over solid substrate with 30# felt underlayment  Finishes: PVDF, MS Colorfast45® and Acrylic Coated Galvalume®  Contact Metal Sales for load-carrying capabilitiesw UL 263, Fire Resistance Rating – per assembly w UL 580, Class 90 Wind Uplift, Construction, #398 and 398Aw UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew ASTM E 283 Air Leakage w ASTM E 331 Water Penetrationw UL 263, Fire Resistance Rating – per assembly w UL 580, Class 90 Wind Uplift, Construction, #397, 397A and 430 (1" Mini-Batten) w UL 580, Class 90 Wind Uplift, Construction, #352 (1-1/2" Mini-Batten)w UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew ASTM E 283 Air Leakage w ASTM E 331 Water Penetration Architectural standing seam roof panel  12", 16" or 18" panel coverage, minimum roof slope: 3:12  Maxi-Batten Cap, 1-5/8" x 1-7/8" Gauges: 26 ga� and 24 ga� standard, 22 ga� optional  Concealed clip designed for thermal movement  Applies over solid substrate with 30# felt underlayment  Finishes: PVDF, MS Colorfast45® and Acrylic Coated Galvalume®  Contact Metal Sales for load-carrying capabilitiesTesting and ApprovalsTesting and Approvals1" Mini-Batten1.5" Mini-Batten12",16" or 18" Coverage5/8"Curved Mini-Batten Minimum radius 4'-0"12", 16" or 18" Coverage13/16"1"12", 16" or 18" Coverage1-1/2"12", 16" or 18" Coverage13/16"1-5/8”1-7/8”Maxi-BattenMini-Batten

metalsales.us.com800.406.738710

800.406.7387metalsales.us.com11 Concealed direct-fastened panel for wall, soft, fascia or liner applications  12" panel coverage  1-1/2" panel depth  40'-0" maximum length , roll-formed panel  Gauges: 24 ga� standard, 22 ga� and 20 ga� optional  Optional Alum: 0�032" or 0�040" Aluminum  Applies over open framing or solid substrate Finishes: PVDF and Acrylic Coated Galvalume® Optional material: stainless steel, aluminum and copper  Custom capabilities include: – Perforated panels for wind screens and liner panels  Contact Metal Sales for load-carrying capabilitiesTLC-1Testing and Approvalsw UL 263, Fire Resistance Rating – per assemblyw ASTM E 283 Air Inltrationw ASTM E 330 Uniform Static Air Pressure Differencew ASTM E 331 Water Penetrationw ASTM E 1592 Roof UpliftTLC-2TLC-3TLC-412" Coverage6"1-1/2"12" Coverage1-1/2"4"12" Coverage1-1/2"4"12" Coverage1-1/2"2"12" Coverage1-1/2"2"12" Coverage1-1/2"1"12" Coverage1-1/2"1"12" Coverage6"1-1/2"TLC-9TLC-11TLC-13TLC-15TLC-10TLC-12TLC-14TLC-1612" Coverage1-1/2"12" Coverage1-1/2"12" Coverage1-1/2"4"12" Coverage1-1/2"TLC SeriesCCCCCCCCCCCC

metalsales.us.com800.406.738712 Concealed direct-fastened panel for wall applications  Panel lengths available from 5'-0" to 30'-0" max*  Gauges: 24 ga� standard; 22 ga� optional  Applies over open framing or solid substrate Finishes: PVDF and Acrylic Coated Galvalume® Horizontal and Vertical installation  Common joinery allows panel prole to be mixed and matched for increased design exibility  High-strength clip allows for thermal and seismic movementTesting and Approvalsw ASTM E 283 Air Inltrationw ASTM E 330 Load Testingw ASTM E 331 Water Penetrationw ASTM E 1592 Roof Upliftw 2023 FBC Approved – 24 ga� Apex Series, FL34027�1 – 24 ga� Contempra Series, FL34027�2 – 24 ga� EM1 Series, FL34027�3 – 24 ga� EM15 Series, FL34027�4 – 24 ga� EM15-1222 Series, FL34027�5Apex Series™Contempra Series™AP1-121212" Coverage2-2/3"1"AP1-12412" Coverage4"1"AP1-16816" Coverage8"1"AP1-165316" Coverage5-1/3"1"AP1-16416" Coverage4"1"CN88-121212" Coverage2-7/8"7/8"CN88-12412" Coverage4"7/8"CN88-16816" Coverage8"7/8"CN88-165316" Coverage5-1/3"7/8"CN88-16416" Coverage4"7/8"Symmetrical RibAsymmetrical Rib*Standard max length of 20' for AP1-1212, CN88-1212 and EM1-1212.Concealed Fastened Wall Panels

800.406.7387metalsales.us.com1312" Coverage2-2/3"1"12" Coverage2-2/3" 1-1/3"1"16" Coverage2-2/3" 8"1"12" Coverage6"1-1/2"16" Coverage2-2/3" 2-2/3"1"16" Coverage8"1-1/2"12" Coverage6"1-1/2"12" Coverage4"2"1-1/2"12" Coverage9"1-1/2"12" Coverage2"4"1-1/2"12" Coverage7"1-1/2"12" Coverage2"6"1-1/2"12" Coverage10"1-1/2"12" Coverage2"2"1-1/2"12" Coverage8"1-1/2"12" Coverage2"6"1-1/2"12" Coverage11"1-1/2"12" Coverage2"4"1-1/2"EM1 Series ■ EMPIRE LINEEM15 Series ■ EMPIRE LINEEM15-1222 Series ■ EMPIRE LINEBox RibBox RibBox RibEM1-1212EM1-168EM15-126EM15-1266EM15-1222EM15-1293EM15-1224EM1-124EM1-1653EM1-168EM15-1284EM15-262EM15-1211EM15-622EM15-1275EM15-1226EM15-1210EM15-1262

metalsales.us.com800.406.73871412" Coverage1"12" Coverage1"12" Coverage1"12" Coverage1" Concealed direct-fastened system for soft, wall, fascia or liner applications  12" panel coverage  1" depth  Max Panel Length: 26 ga� 5'-0", 24 ga� 20'-0" and 0�032" Alum 25'-0"  Gauges: 26 ga�, 24 ga� std� 20 ga� and 0�032" aluminum optional Optional Aluminum: 0�032"  Lanced and Perforated versions are available  Applies over solid substrate with 30# felt underlayment  Finishes: MS Colorfast45®, PVDF and Acrylic Coated Galvalume®  Contact Metal Sales for load-carrying capabilitiesTesting and Approvalsw UL 263, Fire Resistance Rating – per assembly w ASTM E 283 Air Inltrationw ASTM E 330 Uniform Static Air Pressure Differencew ASTM E 331 Water Penetrationw 2023 FBC Approved –24 ga� panel over 16 ga� Girts, 9482�5FlatV-GroovesLanced FlatLanced V-GroovesPerforated FlatPerforated V-GroovesLanced Soft V-Grooves12" Coverage1"12" Coverage1"Soffit Panel

800.406.7387metalsales.us.com152-2/3"32" (Roof Coverage)7/8"34-2/3" (Wall Coverage)CFlat PanWith V-Groovesw UL 263, Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Rating w ICC Evaluation Report, ESR 4633Testing and Approvals Exposed direct-fastened panel for wall, soft, fascia and liner panel Applies over open framing or solid substrate 28", 30" and 36" panel coverages, 1-1/2" rib height 90° vertical box ribs on 4", 6" and 9" centers Gauges: 24 ga� standard, 22 ga�, 20 ga� and 18 ga� optional Optional Aluminum: 0�032", 0�040" or 0�050" Optional material: stainless steel, aluminum and copper Custom capabilities include: – Perforated panels for wind screens and liner panels Standard Finish: PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilitiesT10-B Wall PanelT10-A Wall PanelT10-C Wall PanelT10-D Wall PanelT10-C Wall 4"1-1/2"28" Coverage6"1-1/2"30" Coverage6"1-1/2"30" Coverage9"1-1/2"36" CoverageT10 SeriesCCCC

metalsales.us.com800.406.738716Testing and Approvalsw UL 263, Fire Resistance Rating – per assemblyw UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew ASTM E 283 Air Inltrationw ASTM E 330 Uniform Static Air Pressure Differencew ASTM E 331 Water Penetrationw ASTM E 1592 Roof Uplift Capacityw ASTM E 1646 Water Penetrationw ASTM E 1680 Air Leakagew Texas Department of Insurance Evaluation Report, RC-409w ICC Evaluation Report, ESR-2385w 2023 FBC Approved –24 ga� roof panel over 16 ga� Purlins, FL10999�1 –24 ga� wall panel over 16 ga� Girts, FL9482�1 Exposed direct-fastened panel for roof and wall applications 32" roof coverage (34-2/3" wall coverage) 7/8" rib height, 2-2/3" centers Gauges: 26 ga� and 24 ga� standard, 22 ga� and 20 ga� optional Optional materials: stainless steel, aluminum and weathering steel Minimum roof slope: 1:12 Applies over open framing or solid substrate Finishes: MS Colorfast45®, PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilitiesRoof PanelWall Panel© Anice Hoachlander Exposed direct-fastened roof panel, traditional "V" rib  24" panel coverage  1/2" rib height  Gauges: 29 ga� and 26 ga� standard  Optional Aluminum: 0�032" Minimum roof slope: 3:12  Applies over solid substrate with 30# felt underlayment  Finishes: MS Colorfast45® and Acrylic Coated Galvalume®  Contact Metal Sales for load-carrying capabilitiesw UL 263, Fire Resistance Rating – per assemblyw UL 580, Class 90 Wind Uplift, Construction, #453 and 579w UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Rating w Miami-Dade County Approved, NOA 23-0222�06 (26 gauge)w Miami-Dade County Approved, NOA 18-1227�02 (0�032" Aluminum) w Texas Department of Insurance Evaluation Report, RC-160 w 2023 FBC Approved –26 ga� over 5/8" Plywood, FL14645�2 –26 ga� over 7/16" OSB, FL14645�3 –0�032" Aluminum over 7/16" OSB, FL11560�1Testing and Approvals© Anice Hoachlander2-2/3"32" Coverage7/8"24" Coverage1/2"2-2/3"34-2/3" Coverage7/8"5V-Crimp7/8" Corrugated

800.406.7387metalsales.us.com17CFlat PanWith V-GroovesTesting and Approvalsw UL 263, Fire Resistance Rating – per assemblyw UL 790, Class A Fire Resistance Rating – per assemblyw ASTM E 283 Air Inltrationw ASTM E 330 Uniform Static Air Pressure Differencew ASTM E 331 Water Penetrationw ICC Evaluation Report, ESR-2385w UL 263, Fire Resistance Rating – per assemblyw UL 580, Class 90 Wind Uplift, Construction, #187w UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact ResistanceTesting and Approvals Exposed direct-fastened panel for roof and wall applications 32" panel coverage Trapezoidal rib on 4-9/16" centers 1-3/8" rib height Gauges: 26 ga� and 24 ga� standard, 22 ga� optional Minimum roof slope: 1:12 Applies over open framing or solid substrate Finishes: MS Colorfast45®, PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilitiesRoof PanelWall Panel Exposed direct-fastened industrial panel Roof and wall applications 36" panel coverage, minimum roof slope: 1:12 1-1/2" rib height at 7�2" centers Gauges: 24 ga� standard, 22 ga� and 20 ga� optional Optional Aluminum: 0�032" or 0�040" Applies over open framing or solid substrate Finishes: PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilities36" Coverage1-1/2"7.2"36" Coverage1-1/2"7.2"4-9/16"32" Coverage1-3/8"IC72-PanelV-Line 32

metalsales.us.com800.406.738718 Exposed direct-fastened panel for roof and wall applications Applies over open framing or solid substrate Panel coverage: 32" to 44" Rib height: 5/8" to 1-3/4" Optional material: stainless steel, aluminum and copper Gauges: 24 ga� standard, 22 ga�, 20 ga� and 18 ga� optional Optional Aluminum: 0�032", 0�040" or 0�050" Minimum roof slope: 1:12 Standard Finish: PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilitiesOther proles are available. Please inquire.44" Coverage5/8"44" Coverage5/8"36" Coverage1"36" Coverage1"36" Coverage1"36" Coverage1"40" Coverage1"40" Coverage1"T1 WallT2 WallT3 WallT4 WallT1 RoofT2 RoofT3 RoofT4 RoofT16-E WallT5, T6-A Wall7�33"4"6"8"36" Coverage1-1/2"36" Coverage1-1/2"T5 WallT5 Roof6"EXPOSED FASTENED LINELOW RIB SeriesRib Height Under 2" w ICC Evaluation Report, ESR-4633 – T6-A Wall, T16-E Wall, T16-L WallTesting and ApprovalsCCCCCCCCCC

800.406.7387metalsales.us.com1936" Coverage1-1/2"36" Coverage1-1/2"36" Coverage1-1/2"36" Coverage1-1/2"39" Coverage1-1/2"39" Coverage1-1/2"34-1/8" Coverage1-3/4"34-1/8" Coverage1-3/4"36-1/2" Coverage1-3/8"36-1/2" Coverage1-3/8"36" Coverage4-1/2"C3/4"T6-A WallT7 WallT7-A WallT11-A WallT12 WallT6-A RoofT7 RoofT7-A RoofT11-A RoofT12 RoofT16-E WallT16-E RoofT16-L WallSame prole for Roof and WallSame prole for Roof and Wall7�2"9"7�8"4�875"4�563"32" Coverage3/4"4"36" Coverage3/4"4�5"LOW RIB SeriesRib Height Under 2" T5, T6-A WallCCCCCCCCCCCCC

metalsales.us.com800.406.738720 Exposed direct-fastened panel for roof and wall applications Applies over open framing or solid substrate 24", 30" or 32" panel coverages 2", 3" or 3-1/2" rib heights Optional material: stainless steel, aluminum and copper Gauges: 24 ga� standard, 22 ga�, 20 ga� and 18 ga� optional Optional Aluminum: 0�032", 0�040" or 0�050" Minimum roof slope: 1:12 Custom capabilities include: Perforated panels  Standard Finish: PVDF and Acrylic Coated Galvalume®T13 WallT13-A WallT13-B WallT14 WallT13 RoofT13-A RoofT13-B RoofT14 Roof32" Coverage2"8"C24" Coverage3"8"C24" Coverage3"6"C30" Coverage3"10"30" Coverage3-1/2"10"30" Coverage2"6"CT2832 WallT2832 RoofT2630 WallT2630 Roof30" Coverage2"6"C32" Coverage2"8"C24" Coverage3"8"24" Coverage3"6"30" Coverage3"10"30" Coverage3-1/2"10"T13-B WallEXPOSED FASTENED LINE2" RIB SeriesRib Height 2"-3" 3" RIB SeriesRib Height 3"-4" w ICC Evaluation Report, ESR-4633 – T2630 WallTesting and ApprovalsCCCCCCCCCCCC

800.406.7387metalsales.us.com21 Exposed direct-fastened panel for roof and wall applications Applies over open framing or solid substrate Various panel coverages 4" and 4-1/2" rib heights Trapezoidal ribs on various centers Optional material: stainless steel, aluminum and copper Gauges: 24 ga� standard, 22 ga�, 20 ga� and 18 ga� optional Optional Aluminum: 0�032", 0�040" or 0�050" Minimum roof slope: 1:12 Custom capabilities include: – Perforated panels for wind screens and liner panels Standard Finish: PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilities T15 WallT15 RoofT25 WallT25 Roof4"30" Coverage10"4"30" Coverage10"24" Coverage4"12"24" Coverage4"12"18" Coverage4-1/2"6"TDR-6 Roof18" Coverage4-1/2"6"TDR-6 Wall18" Coverage4-1/2"9"TDR-9 Roof18" Coverage4-1/2"9"TDR-9 WallRib Height 4" and Over DEEP RIB SeriesTDR-6 WallCCCCCCCC

metalsales.us.com800.406.738722 Exposed direct-fastened panel for roof and wall applications 36" panel coverage Trapezoidal rib on 12" centers 1-1/4" rib height PBR-Panel Gauges: 26 ga� and 24 ga� standard, 22 ga� optional R-Panel Gauges: 26 ga� standard Minimum roof slope: 1:12  Applies over open framing or solid substrate Finishes: MS Colorfast45®, PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilitiesTesting and ApprovalsTesting and Approvalsw UL 580, Class 90 Wind Uplift, Construction, #161w UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew ASTM E 455 Diaphragm Testw Miami-Dade County Approved, NOA 20-0131�03 and 20-0131�02 (24 ga� roof & wall)w Texas Department of Insurance Evaluation Reports, RC-198, RC-265, RC-279, RC-391w ICC Evaluation Report, ESR-2385 (R-Panel)w 2023 FBC Approved –26 ga� over 16 ga� Purlins, FL10999�7 –26 ga� over 16 ga� Girts, FL9482�4 –26 ga� over 1/2" Plywood, FL14645�11PBR-PanelPBU-PanelR-PanelU-Panel Exposed direct-fastened panel for roof and wall applications 36" panel coverage Trapezoidal rib on 6" centers 3/4" rib height Gauges: 29 ga�, 26 ga� and 24 ga� standard, 22 ga� optional Minimum roof slope: 1:12  Applies over open framing or solid substrate Finishes: MS Colorfast45®, PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilitiesw UL 263, Fire Resistance Rating – per assemblyw UL 580, Class 90 Wind Uplift, Construction, #39w UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew Texas Department of Insurance Evaluation Report, RC-196w ICC Evaluation Report, ESR-23851-1/4"36" Coverage12"3/4"36" Coverage6"1-1/4"36" Coverage12"3/4"36" Coverage6"PBU-Panel, U-PanelPBR-Panel, R-Panel

800.406.7387metalsales.us.com23Pro-Panel IIClassic RibPro-Panel II (Alt)w UL 263, Fire Resistance Rating – per assemblyw UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew ASTM E 455 Diaphragm Testw 2023 FBC Approved –29 ga� over 1/2" Plywood, 14645�12w UL 263, Fire Resistance Rating – per assemblyw UL 580, Class 90 Wind Uplift, Construction, #560 and 584w UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew ASTM E 455 Diaphragm Testw ASTM E 564-95 Diaphragm Testw Miami-Dade County Approved, NOA 21-0629�10w Texas Department of Insurance Evaluation Reports, RC-161 and RC-391w ICC Evaluation Report, ESR-2385w 2023 FBC Approved –29 ga� over 2x Purlins, FL10999�4 –29 ga� over 2x Girts, FL9482�3 –29 ga� over 7/16" OSB, FL14645�8 –29 ga� over 1/2" Plywood, FL14645�9 –29 ga� over 1/2" Plywood, FL14645�6–26 ga� over 5/8" Plywood, FL14645�7–26 ga� over 16 ga� Girts, FL9482�2–26 ga� over 16 ga� Purlins, FL10999�3–0�032" Alum over 7/16" OSB, FL14645�5Testing and ApprovalsTesting and Approvals Exposed direct-fastened, low prole panel for roof and wall 36" panel coverage Trapezoidal rib on 9" centers 5/8" rib height Gauges: 29 ga� and 26 ga� standard Minimum roof slope: 3:12  Applies over open framing or solid substrate Finishes: MS Colorfast45®, ColorFit40™, PVDF and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilities Exposed direct-fastened, low prole panel for roof and wall 36" panel coverage Trapezoidal rib on 9" centers 3/4" bell-top rib height Gauges: 29 ga� and 26 ga� standard Minimum roof slope: 3:12  Applies over open framing or solid substrate Finishes: MS Colorfast45®, ColorFit40™, Acrylic Coated Galvalume® and Galvanized Contact Metal Sales for load-carrying capabilitiesAvailable in select branches only5/8"36" Coverage9"36" Coverage3/4"9"5/8"36" Coverage9"Classic Rib®Pro-Panel II®

metalsales.us.com800.406.738724w UL 263, Fire Resistance Rating – per assemblyw UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew Texas Department of Insurance Evaluation Report, RC-159w ICC Evaluation Report, ESR-2385w 2023 FBC Approved –26 ga� over 5/8" Plywood, FL14645�1 Testing and ApprovalsTesting and Approvalsw UL 263, Fire Resistance Rating – per assemblyw UL 580, Class 90 Wind Uplift, Construction, #161w UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact ResistanceWallRoof Exposed direct-fastened panel for roof and wall applications 24" panel coverage (wall) 21-1/3" panel coverage (roof) Corrugated ribs on 2-2/3" centers 1/2" rib height Gauges: 29 ga� and 26 ga� standard Minimum roof slope: 3:12  Applies over open framing or solid substrate Finishes: MS Colorfast45® and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilities Exposed direct-fastened panel for roof and wall applications 24" panel coverage Corrugated ribs on 1-1/4" centers 1/4" rib height Gauges: 29 ga� and 26 ga� standard Minimum roof slope: 3:12  Applies over open framing or solid substrate Finishes: MS Colorfast45® and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilities24" Coverage1/2"2-2/3"21-1/3" Coverage1/2"2-2/3"24" Coverage1/4"1-1/4"1.25" Corrugated2.5" Corrugated

800.406.7387metalsales.us.com25Testing and Approvals Exposed direct-fastened roof and wall panel 36" panel coverage 5/8" rib height Classic board and batten design, on 9" centers Gauges: 29 ga� and 28 ga� standard Minimum roof slope: 3:12 Applies over open framing or solid substrate Finishes: MS Strongcoat45® and Galvanized Contact Metal Sales for load-carrying capabilitiesTesting and Approvalsw UL 263, Fire Resistance – per assemblyw UL 580, Class 90 Wind Uplift, Construction, #161w UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistancew Texas Department of Insurance, RC-405 and RC-406 ASTM E 1592 Structural Performance Exposed direct-fastened panel for roof and wall applications 36" panel coverage �39" rib height Trapezoidal ribs on 3" centers Gauges: 29 ga� standard Minimum roof slope: 3:12 Applies over open framing or solid substrate Finishes: MS Colorfast45® and Bare Galvanized Contact Metal Sales for load-carrying capabilities5/8"36" Coverage9"36" Coverage.39"3"DL-3 PanelStrongpanel®

metalsales.us.com800.406.738726 Mill-nished diamond-embossed aluminum Exposed direct-fastened, low prole panel for roof and wall 36" panel coverage 3/4" bell-top rib height Twin trapezoidal ribs on 9" centers Thickness: 0�0155" and 0�018" Minimum roof slope: 3:12  Contact Metal Sales for load-carrying capabilitiesTesting and Approvals UL 263, Fire Resistance – per assembly UL 790, Class A Fire Resistance Rating – per assembly UL 2218, Class 4 Impact Resistance Exposed direct-fastened panel for roof and wall applications 36" panel coverage 7/16" rib height Double trapezoidal ribs on 9" centers Gauges: 29 ga� and 26 ga� standard Minimum roof slope: 3:12 Applies over open framing or solid substrate Finishes: MS Colorfast45® and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilitiesTesting and Approvals Exposed direct-fastened panel for roof and wall applications 24" panel coverage 13/16" rib height Trapezoidal rib on 8" centers Gauges: 29 ga� and 26 ga� standard Minimum roof slope: 3:12 Applies over open framing or solid substrate Finishes: MS Colorfast45® and Acrylic Coated Galvalume® Contact Metal Sales for load-carrying capabilitiesw UL 263, Fire Resistance Rating – per assemblyw UL 790, Class A Fire Resistance Rating – per assemblyw UL 2218, Class 4 Impact Resistance36" Coverage7/16"9"24" Coverage13/16"8"36" Coverage3/4"9"2-1/2"Bi-RibDelta RibDual RibOnly available at select branches. Please inquire.

800.406.7387metalsales.us.com27 Insulated metal wall and roof systems Factory-injected foam insulation between dual steel facings Closed cell insulating core provides approximately R-8 per inch Panel Coverage: 40" Wall Panel Thickness: 2", 2�5", 3" and 4" Roof Panel Thickness: 2�5", 3�25", 4", 5" and 6" Gauges: 26 ga� standard 24 ga� and 22 ga� optional Finishes: PVDF and SMP coatings Contact Metal Sales for load-carrying capabilitiesSR2 Standing Seam RoofHR3 High Rib RoofDM40 Double Mesa WallFL40 Flat WallHE40 Heavy Embossed WallHE40A AdobeTextureTM WallST40 Striated Wall40”2.062”2.125”1.375”2.125”40”40”2.062”2.125”2.125”40”Testing and Approvalsw ASTM E 283 Air Inltrationw ASTM E 331 Water Penetrationw ASTM E 1646 Water Penetrationw ASTM E 1680 Air LeakageIMPower SeriesTM

metalsales.us.com800.406.738728Find out how easy it is to instantly provide your customers with a building design, cost estimate, construction contract, blueprints and more. Metal Sales IMPACT Steel Building program brings you a powerful, free software tool that allows you to sit down with your customers and help them design their next steel building from the ground up. There’s never been a better, faster and more appreciated way to help your customers than by saving them all the problems and inconvenience of designing and erecting a custom building from scratch. From engineered foundation designs to steel supply at the job site, IMPACT has it all covered.IMPACTSteel BuildingsIMPACT Steel Building SystemsCold-Formed Bolt-Up Steel Building SolutionsWhy Cold-Formed Steel Buildings?A cold-formed steel building is any building constructed with cold-formed steel and CEE sections that are bolted or screwed together to form clear span frames, columns and rafters. No welding is required.Advantages of Cold-Formed Steel High strength-to-weight ratio Non-combustibility Termite resistant Ease of construction123

800.406.7387metalsales.us.com29CHANNELS, HAT SECTIONS AND ANGLESCEES, ZEES AND EAVE STRUTSSingle SlopeDouble SlopeUniversalCee Standard Zee LGSI ZeeOther Components are available. Please inquire.Angle 3/4" Sub-girt 1-1/2" Hat SectionChannel 1-1/2" Channel 1-1/4" Hat Section Cees and Zees 4" to 12" deep with 2-1/2" to 4" ange widths Gauges: 10, 12, 14 or 16 Symmetrical and unsymmetrical anges Red Oxide nish ASTM A 1011 Grade 50, Class 2 (55 ksi min yield) Galvanized nish ASTM A 653 Grade 50, Class 2 (55 ksi min yield) Single Slope Eave Struts for high-side applications Double Slope Eave Struts for low-side applicationsMetal Sales can oer you the exibility to quote a wide variety of shapes and sizes. With our panels and ashings pre-loaded into the software, MBS allows for quick and easy building data input resulting in a complete Self Storage building solution. Contact Metal Sales for custom building designs.Powered by MBS, the number one Self Storage software program in the United States. Trusted by over 200 metal building manufacturers.The MBS program automatically prepares erection drawings unique to each building inputed, including Anchor Bolt Plans.A stamped Engineer Seal is available for the erection drawings upon request. Contact Metal Sales for the latest testing and approval information.Trained Metal Sales team members will work with you to take your self storage building concepts and make them a reality. SELFSTORAGEASSOCIATION Powered by:Metal Building SoftwareSelf Storage SolutionsSecondary Framing

metalsales.us.com800.406.738730RETROMASTER SYSTEM OVER CONCRETE SUBSTRATERETROMASTER SYSTEM OVER WOOD SUBSTRATESolutions for existing at roofsRetro-Master® is a complete retrot roof system that easily and aordably transforms old and failing roofs into a new code-compliant and energy-ecient sloped metal roof. As a single-source solution Retro-Master® retrot roof system is backed by a 20 year weathertight warranty and an industry-leading 45 year paint nish warranty. It is the ideal solution for schools, universities, retail centers, industrial or oce building, military or any other building needing a new, long-lasting, high performance roof.Solutions for existing sloped metal roofsIf your building has an existing sloped metal roof in need of replacement, Roof Hugger™ is the most complete and convenient solution. This easy, ecient and virtually waste-free system is installed over your existing roof, allowing your business to operate uninterrupted and allowing the option to install new insulation if needed.This Metal-Over-Metal Reroof Solution combines high quality Metal Sales roof panels with a patented Roof Hugger™ sub-purlin retrot framing system to deliver a new, structurally sound roof that will stand the test of time.NEW METAL ROOF PANELS OVER EXISTING FLAT ROOF.Post-Purlin Retrot SystemPost-Purlin over Concrete SubstratePost-Purlin over failing at roofRoof Hugger®FramingNew Metal Sales PanelExisting Roof PanelNew Metal Sales PanelExisting Flat RoofPost Purlin SystemNew Insulation Added slope minimizes maintenance at roof and geometry problems  Roong systems designed for a longer life cycle  In-house engineering and design assistance availableRetro-Master® SystemNEW METAL ROOF PANELS OVER EXISTING SLOPED METAL PANELSRoof Hugger™ System

800.406.7387metalsales.us.com31Perforated panels are an aesthetic design solution Wide array of panel prolesAvailable gauges: 24, 22, 20 or 18Windscreens, balcony railings, equipment and concealment screens, ventilation and interior linerNon-Insulated panels up to 3” deepVertical & Horizontal applicationsProle widths or modules up to 36”+/- 90 Degrees (Inside – Outside – Double Corners) Corner leg dimensions up to 4’-0” in either directionTOPCOATExceptional color duarability and gloss retentionBACK COATCovers primer and ensures consistent colorPRIMERCorrosion resistance and bondingPRIMERPRETREATMENTAdhesion, moisture and corrosion protectionPRETREATMENTGALVALUME/GALVANIZEDInhibits corrosionGALVALUME/GALVANIZEDInhibits corrosionBARE STEELMill certied to meet ASTM standardsMeet or exceed codes and standardsOur advanced coating technology ensures Metal Sales nishes and colors meet demonstrated energy performance requirements established by ENERGY STAR® and the Cool Roof Rating Council (CRRC) for solar reectance and thermal emittance for steep sloped and/or low sloped buildings. Benets of cool colorsCool roof colors are oered from an engaging palette of light neutrals to dark saturated hues that respect the environment and help achieve your vision. Cool roofs may also contribute to other strategies for optimizing energy performance. Energy savings and other direct benets are contingent upon building type, location and use.Substrate MaterialsOur line of durable materials includes steel, stainless steel, weathering steel, copper and aluminum. Your Metal Sales representative has technical information on material and coating compatibility.PerforationMitered CornersCoating Systems

Metal Sales Branch LocationsANCHORAGE, ALASKA 4625 Old Seward Highway Anchorage, AK 99503 866.640.7663 ■ 907.646.7664/FaxBAY CITY, MICHIGAN 5209 Mackinaw Road Bay City, MI 48706 888.777.7640 ■ 888.777.0112/FaxDEER LAKE, PENNSYLVANIA 29 Pinedale Industrial Road Orwigsburg, PA 17961 800.544.2577 ■ 800.544.2574/FaxDENVER, COLORADO 7990 East I-25, Frontage Road Longmont, CO 80504 800.289.7663 ■ 800.289.1617/FaxDETROIT LAKES, MINNESOTA 1435 Egret Avenue Detroit Lakes, MN 56501 888.594.1394 ■ 888.594.1454/FaxFONTANA, CALIFORNIA 14213 Whittram Avenue Fontana, CA 92335 800.782.7953 ■ 909.829.9083/FaxFORT SMITH, ARKANSAS 7510 Ball Road Fort Smith, AR 72908 877.452.3915 ■ 479.646.5204/FaxINDEPENDENCE, MISSOURI 1306 South Powell Road Independence, MO 64057 800.747.0012 ■ 800.409.3069/FaxJACKSONVILLE, FLORIDA 7110 Stuart Avenue Jacksonville, FL 32254 800.394.4419 ■ 800.413.3292/FaxJEFFERSON, OHIO 352 East Erie Street Jefferson, OH 44047 800.321.5833 ■ 800.233.5719/FaxKELSO, WASHINGTON 2680 Coweeman Park Drive Kelso, WA 98626 800.431.3470 ■ 253.872.2008/FaxMOCKSVILLE, NORTH CAROLINA 188 Quality Drive Mocksville, NC 27028 800.228.6119 ■ 800.228.7916/FaxNASHVILLE, TENNESSEE 4314 Hurricane Creek Boulevard Antioch, TN 37013 800.251.8508 ■ 800.419.4372/FaxNEW ALBANY, INDIANA 999 Park Place New Albany, IN 47150 812.944.2733 ■ 812.944.1418/FaxROCK ISLAND, ILLINOIS 8111 29th Street West Rock Island, IL 61201 800.747.1206 ■ 309.787.1833/FaxROGERS, MINNESOTA 22651 Industrial Boulevard Rogers, MN 55374 800.328.9316 ■ 800.938.9119/FaxSELLERSBURG, INDIANA 7800 Highway 60 Sellersburg, IN 47172 800.999.7777 ■ 800.477.9318/FaxSIOUX FALLS, SOUTH DAKOTA 2700 West 3rd Street Sioux Falls, SD 57104 888.299.0024 ■ 888.960.0429/FaxSPOKANE, WASHINGTON 2727 East Trent Avenue Spokane, WA 99202 800.572.6565 ■ 509.534.4427/FaxTEMPLE, TEXAS 3838 North General Bruce Drive Temple, TX 76501 800.543.4415 ■ 800.543.4473/FaxWOODLAND, CALIFORNIA 1326 Paddock Place Woodland, CA 95776 800.759.6019 ■ 530.668.0901/Fax800.406.7387 ■ metalsales.us.comPrinted in the USA 1024 ©MS /6-24SpokaneFort SmithJeffersonBay CityAnchorageMocksvilleNashvilleJacksonvilleRock IslandRogersDeer LakeWoodlandFontanaDenverKelsoTempleIndependenceNew AlbanySioux FallsDetroit LakesSellersburg

Roof andRoof and WallWall ColorsColorsLinen White (81)SR = 0.73 TE = 0.86 SRI = 89Khaki (88) Classic Green (66) Zinc Grey (29)Burnished Slate (49) Patriot Red (73)SR = 0.35 TE = 0.87 SRI = 37 SR = 0.32 TE = 0.86 SRI = 33 SR = 0.41 TE = 0.86 SRI = 45Polar White (80)SR = 0.58 TE = 0.87 SRI = 68White (30) Light Stone (63) Mocha Tan (22)SR = 0.57 TE = 0.88 SRI = 67 SR = 0.50 TE = 0.88 SRI = 58 SR = 0.52 TE = 0.87 SRI = 60SR = 0.30 TE = 0.85 SRI = 30 SR = 0.29 TE = 0.86 SRI = 29 SR = 0.46 TE = 0.86 SRI = 52Brown (12)SR = 0.31 TE = 0.87 SRI = 32Burgundy (15) Patriot Red (73) Red (24)Burnished Slate (49) Ocean Blue (35) Hawaiian Blue (70) Charcoal (17)SR = 0.25 TE = 0.87 SRI = 24 SR = 0.35 TE = 0.88 SRI = 38 SR = 0.30 TE = 0.86 SRI = 30Ash Grey (25)SR = 0.37 TE = 0.88 SRI = 40Forest Green (26) Patina Green (58)SR = 0.31 TE = 0.87 SRI = 32 SR = 0.32 TE = 0.87 SRI = 33 SR = 0.30 TE = 0.87 SRI = 31PVDF Paint SystemMS Colorfast45® Paint SystemSR = 0.29 TE = 0.86 SRI = 29Black (06)Acrylic Coated Galvalume® (41)SR = 0.30 TE = 0.88 SRI = 31SR = 0.67 TE = 0.14 SRI = 56SR = 0.30 TE = 0.88 SRI = 31SR = 0.27 TE = 0.87 SRI = 27Ocean Blue (35)² Non-Painted FinishVisit metalsales.us.com for valuable tools and resources(Color Code) ● SR = Initial Solar Reectance ● TE = Thermal Emittance ● SRI = Solar Reectance Index²EAST24226645aint finishyearwarrantypaint finishColor selections are close representations but are limited by printing and viewing conditions. Actual samples are available by request.

All colors carry a 45 year limited paint warranty.Color selections are close representations but are limited by printing and viewing conditions. Actual samples are available by request.Premium242424PremiumPremiumRoof andRoof and WallWall ColorsColorsTerra Cotta (W72)Snowdrift White (W81) Linen White (81)Khaki (88)Old Town Grey (W25)Mansard Brown (133)Ocean Blue (35)Ash Grey (25)Colonial Red (W75)Regal Blue (W35)Taupe (74)Hemlock Green (M7) Classic Green (66)Weathered Copper (W50)Aged Copper (65)Sandstone (W51)Felt Green (W66)Slate Grey (W38)Tahoe Blue (W71)Brandywine (P8)Copper Penny (W92)1Patriot Red (73)Parchment (W74)Metallic Silver (K7)1Patina Green (W58)Dark Bronze (50)Matte Black (106)Mistique Plus (W31)1Medium Bronze (H4)Antique Patina (M1)1River Teal (59)Champagne Metallic (168)1Old Zinc Grey (W29)1 Metallic Colors, up-charge will apply PVDF Paint SystemGalvalume® (41)Non-painted Finish25 Year WarrantyAll colors carry a 45 year limited paint warranty.Color selections are close representations but are limited by printing and viewing conditions. Actual samples are available by request.Visit metalsales.us.com for valuable tools and resources.Premium24242445aint finishyearwarrantypaint finishRATEDPRODUCT

Metal Sales Branch Locationsmetalsales.us.comAnchorage, AK: 866.640.7663Bay City, MI: 888.777.7640Deer Lake, PA: 800.544.2577Denver, CO: 800.289.7663Detroit Lakes, MN: 888.594.1394Fontana, CA: 800.782.7953Fort Smith, AR: 877.452.3915Independence, MO: 800.747.0012Jacksonville, FL: 800.394.4419Jefferson, OH: 800.321.5833Mocksville, NC: 800.228.6119Nashville, TN: 800.251.8508Rock Island, IL: 800.747.1206Rogers, MN: 800.328.9316Seattle, WA: 800.431.3470Sellersburg, IN: 800.999.7777Sioux Falls, SD: 888.299.0024Spokane, WA: 800.572.6565Temple, TX: 800.543.4415Woodland, CA: 800.759.6019*LOW SLOPE: Surface with a slope of 2:12 or less ● STEEP SLOPE: Surface with a slope greater than 2:123-2022 1318PVDF Color NamePVDF Color Name(Color Code)(Color Code)Solar Solar ReectanceReectanceASTM C 1549ASTM C 1549ThermalThermalEmittanceEmittanceASTM C 1371ASTM C 1371Solar ReectanceSolar ReectanceIndexIndexASTM E 1980ASTM E 1980Low GlossLow GlossMetallic FinishMetallic FinishENERGY STARENERGY STAR®®Steep Slope*Steep Slope*ENERGY STARENERGY STAR®®Low Slope*Low Slope*CRRCCRRCSteep Slope*Steep Slope*CRRCCRRCLow Slope*Low Slope*LEEDLEEDSteep Slope*Steep Slope*LEED LEED Low Slope*Low Slope*Aged Copper (65) 0.32 0.85 32● ● ●Antique Patina (M1) 0.38 0.85 40● ● ● ●Ash Grey (25) 0.38 0.86 41● ● ●Brandywine (P8) 0.26 0.85 24● ●Champagne Metallic (168) 0.47 0.85 53● ● ● ●Classic Green (66) 0.32 0.86 33● ● ●Colonial Red (W75) 0.35 0.86 37● ● ● ●Copper Penny (W92) 0.45 0.85 50● ● ● ●Dark Bronze (50) 0.30 0.86 30● ● ●Felt Green (W66) 0.31 0.84 31● ● ● ●Galvalume® (41) 0.67 0.14 56● ● ●Hemlock Green (M7) 0.36 0.85 38● ● ● ●Khaki (88) 0.35 0.87 37● ● ●Linen White (81) 0.73 0.86 89● ● ● ● ● ●Mansard Brown (133) 0.30 0.87 31● ● ●Matte Black (106) 0.27 0.86 26● ●Medium Bronze (H4) 0.30 0.87 31● ● ●Metallic Silver (K7) 0.60 0.77 68● ● ● ●Mistique Plus (W31) 0.34 0.82 34● ● ● ●Ocean Blue (35) 0.29 0.86 29● ● ●Old Town Grey (W25) 0.40 0.85 43● ● ● ●Old Zinc Grey (W29) 0.42 0.85 46● ● ● ●Parchment (W74) 0.41 0.86 45● ● ● ●Patina Green (W58) 0.46 0.85 51● ● ● ●Patriot Red (73) 0.46 0.86 52● ● ●Regal Blue (W35) 0.27 0.86 26● ● ●River Teal (59) 0.29 0.86 29● ● ●Sandstone (W51) 0.54 0.86 63● ● ●Slate Grey (W38) 0.30 0.85 30● ● ● ●Snowdrift White (W81) 0.65 0.85 78● ● ● ● ● ●Tahoe Blue (W71) 0.30 0.86 30● ● ● ●Taupe (74) 0.29 0.84 28● ●Terra Cotta (W72) 0.39 0.85 42● ● ● ●Weathered Copper (W50) 0.32 0.84 32● ● ● ●
