HARDSCAPE CATALOGUE
caseyltd.ca
Casey Concrete Ltd. has produced quality
Ready-Mix concrete and concrete products
since the 1950's in Atlantic Canada. Family
owned and operated throughout its history,
Casey Concrete has grown through customer
service and technical expertise in all areas of
concrete technology.
Casey Concrete has developed a line of
concrete hardscape products that meet the
demands of Atlantic Canada.
Produced in Amherst, Nova Scotia in the most
modern concrete products plant in Atlantic
Canada, Casey Blocks are built to last.
We stand behind our products and take pride in
our customer service.
Who
we are
2
32
PAVERS
ALPINE
COASTAL
4
AVALON
BORDERS
SHERBROOKE
54
PAVERS
ALPINE
Our Alpine line has a smooth surface and slightly
bevelled edge. They are available in six colours
and when combined with dierent patterns and
borders, the combinations are endless. They
nicely complement our other product lines
including our retaining walls.
6
Earthblend
Charcoal
Natural Grey
Sand-Charcoal
Granite
Casey-Mix
Available in 60 mm & 80 mm thickness
ALPINE
4 L x 4 W (in)
100 x 100 mm
ALPINE
8 L x 4 W (in)
200 x 100 mm
ALPINE
8 L x 8 W (in)
200 x 200 mm
ALPINE
12 L x 8 W (in)
300 x 200 mm
ALPINE
12 L x 12 W (in)
300 x 300 mm
76
COASTAL
Our Coastal line has a rich stone textured surface
that resembles hand-cut natural material that can
lend softness and elegance to your landscape
project. They are available in six colours and
when combined with dierent patterns and
borders, the combinations are endless. They
nicely complement our other product lines
including our retaining walls.
PAVERS
8
COASTAL
4 L x 4 W (in)
100 x 100 mm
COASTAL
8 L x 4 W (in)
200 x 100 mm
COASTAL
8 L x 8 W (in)
200 x 200 mm
COASTAL
12 L x 8 W (in)
300 x 200 mm
COASTAL
12 L x 12 W (in)
300 x 300 mm
Earthblend
Charcoal
Natural Grey
Sand-Charcoal
Granite
Casey-Mix
Available in 60 mm & 80 mm thickness
98
AVALON
Our Avalon line has a smooth surface and slightly
bevelled edge. Having a larger footprint than our
Alpine line makes them faster to install and will
give your project a dierent finished appearance.
They are available in six colours and when
combined with dierent patterns and borders,
the combinations are endless. They nicely
complement our other product lines including
our retaining walls.
PAVERS
10
AVALON
12 L x 6 W (in)
300 x 150 mm
AVALON
12 L x 12 W (in)
300 x 300 mm
AVALON
18 L x 12 W (in)
450 x 300 mm
Earthblend
Charcoal
Natural Grey
Sand-Charcoal
Granite
Casey-Mix
Available in 60 mm & 80 mm thickness
1110
SHERBROOKE
Our Sherbrooke line has a rich stone textured
surface that resembles hand-cut natural material
that can lend softness and elegance to your
landscape project. Having a larger footprint than
our Coastal line makes them faster to install
and will give your project a dierent finished
appearance. They are available in six colours
and when combined with dierent patterns and
borders, the combinations are endless. They
nicely complement our other product lines
including our retaining walls.
PAVERS
12
SHERBROOKE
12 L x 6 W (in)
300 x 150 mm
SHERBROOKE
12 L x 12 W (in)
300 x 300 mm
SHERBROOKE
18 L x 12 W (in)
450 x 300 mm
Earthblend
Charcoal
Natural Grey
Sand-Charcoal
Granite
Casey-Mix
Available in 60 mm & 80 mm thickness
1312
PAVERS
BORDERS
Border stones can be used as accents or to
create a border around your walkway or patio.
Contrasting or complementary colours can be
incorporated into any project. Border stones are
sold in their individual sizes (not as part of
multi-piece sets) and can be used as a stand-
alone product.
Border stones are sold by the layer and can be
used entirely on their own or in combination with
any of our paver products, not just for borders.
14
BORDER STONE
8 L x 4 W (in)
200 x 100 mm
Available only in
60 mm smooth
BORDER STONE
8 L x 8 W (in)
200 x 200 mm
Available only in
60 mm smooth
BORDER STONE
12 L x 8 W (in)
300 x 200 mm
Available in 60 mm
and 80 mm smooth
and textured
Earthblend
Charcoal
Natural Grey
Sand-Charcoal
Granite
Casey-Mix
1514
EC-STONE
Our EC-Stone line has been around for
many years. It comes with three options for
a surface finish; brick, smooth and slate
top. It is a proven attractive landscape pad
at an aordable price. EC-Stones come in
our main six colours and complement all
our other landscape products.
EC-STONE
16
EC-STONE BRICK
18 L x 18 W x 2 H (in)
445 x 445 x 50 mm
EC-STONE SMOOTH
18 L x 18 W x 2 H (in)
445 x 445 x 50 mm
EC-STONE SLATE
18 L x 18 W x 2 H (in)
445 x 445 x 50 mm
Stone Red
Casey-Mix
Charcoal
Natural Grey
1716
WALLS & STEPS
HIGHLAND WALL
18
WALLS & STEPS
GARDEN WALL
CAPS AND STEPS
1918
HIGHLAND WALL
The multiple sizes of the Highland Stone® retaining
wall system evokes the charming, hand-stacked
walls of centuries past. The unique 6” system
oers a hand-hewn face that portrays a stone-like
appearance. The patented rear lip allows for faster,
more reliable construction.
WALLS & STEPS
20
6 " RETAINING BLOCK
6 L x 12 W x 6 H (in)
150 x 305 x 152 mm
12 " RETAINING BLOCK
12 L x 12 W x 6 H (in)
302 x 305 x 152 mm
18 " RETAINING BLOCK
18 L x 12 W x 6 H (in)
451 x 305 x 152 mm
CORNER BLOCK
16 L x 8 W x 6 H (in)
406 x 203 x 152 mm
Earthblend
Casey-Mix
Natural Grey
Sand-Charcoal
Charcoal
Granite
2120
CAPS AND STEPS
Caps give a finished appearance to our Highland
retaining wall system. Available in both long and
short styles to give flexibility in design and function.
Steps can be used to incorporate a staircase into
a retaining wall or to build a stand-alone stairway.
Steps create accessibility to patios and other areas
of your property.
WALLS & STEPS
22
SHORT CAP
7 – 8 L x 13 W x 3 H (in)
174 210 x 330 x 76 mm
LONG CAP
18 – 12 L x 14.5 W x 3 H (in)
457 305 x 368 x 76 mm
STEP BLOCK
16 L x 16 W x 6 H (in)
406 x 406 x 152 mm
PRECAST STEP
16 L x 48 W x 6 H (in)
1219 x 406 x 152 mm
Wet cast product,
natural colour range
Earthblend
Casey-Mix
Natural Grey
Sand-Charcoal
Charcoal
Granite
2322
GARDEN WALL
Garden Wall stones have a nice split-texture on
both front and back for versatility and easy to
construct curves and circles. The stones are ideal
for enriching the look of your garden or flower-
beds. They come in six colours and complement
all our other landscape products.
WALLS & STEPS
24
TOP BLOCK
(Reverse Side)
MIDDLE BLOCK
(Reverse Side)
MIDDLE BLOCK
(Front)
8 L x 7 W x 4 H (in)
200 x 178 x 100 mm
TOP BLOCK
(Front)
8 L x 7 W x 4 H (in)
200 x 178 x 100 mm
Earthblend
Casey-Mix
Natural Grey
Sand-Charcoal
Charcoal
Granite
2524
GRASS PAVER Our environmentally friendly grass pavers can be filled with grass, sand or gravel, letting water permeate the...
FIRE PIT Our fire pits are ideal for small, controlled fires that bring the comfort  and beauty of a wood burning fire to ...
HARDSCAPE PRODUCT DISCLAIMER
COLOUR
Concrete products are composed of
natural raw materials and therefore slight
colour variances should be expected.
For our products that are coloured with
pigment during production, the recipes
are designed with natural raw materials
such as the sand and stone, allowing
the products to vary slightly in colour
tone, veining and texture from one unit
to the next. Therefore, colour samples
are approximate representations of our
standard colours and actual product
colours may vary. Final colour selection
should be made at your local dealer from
stocked product.
Casey Concrete recommends immediate
verification of product condition and
colour upon receipt. If there are any
discrepancies, contact your dealer before
continuing with the project. Installation
of the product constitutes acceptance of
the product.
COLOUR DISTRIBUTION AND
LAYING METHOD
Proper installation enhances the overall
colour of a project. Where possible,
product should be randomly selected
from at least two pallets when installing.
This creates an attractive and subtle
blending of colour.
EFFLORESCENCE
Elorescence is a naturally occurring
process in all concrete products and may
appear on the product surface as a white
powdery substance. Elorescence is
more noticeable on darker products due
to the contrast with white. Elorescence
does not, in any way, compromise the
functionality, structural integrity or
long-term durability of the product. We
take every measure in our production
process to reduce elorescence but
eliminating all elorescence from ever
occurring is not possible. However, it
will wear or wash o over time or can be
removed with an elorescence removal
product. Casey Concrete Ltd. accepts no
responsibility or liability for this naturally
occurring condition to which all concrete
products are susceptible.
PLEASE NOTE
Concrete and concrete products are
manufactured from raw materials and
therefore variation in colour and texture
can occur.
PRODUCT DIMENSONS
Metric dimensions indicated are accurate
to the nearest 1 mm. Imperial units are
rounded to the measurements they are
most often known as.
26
CONCRETE MASONRY AND
HARDSCAPE PRODUCT WARRANTY
DEFINITION OF WARRANTY
Casey Concrete hereby guarantees
that, on the date of delivery, its concrete
products meet or exceed the current
applicable standards set by the CSA
(Canadian Standards Association).
Under the strict condition that the
provisions stated hereinafter are
complied with, Casey Concrete Ltd.
guarantees the structural integrity of
its concrete landscaping and masonry
products, for a minimum period of fifty
(50) years from the date of purchase
of the product. The warranty applies to
normal, non-abusive use of the product.
It covers any abnormal deterioration of
surfaces that may be caused by typical
use of sodium chloride for de-icing
pavers, slabs or steps.
WARRANTY EXCLUSION
The warranty does not apply to spalling
or other breakages caused by impacts,
abrasions or over stressing. The warranty
does not apply when deterioration
results from design or installations
not complying with applicable codes,
standards and recognized best work
practices and procedures.
The warranty does not apply to any
impacts by any mechanical snow
removal equipment.
This warranty does not apply to any
damage resulting from an “Act of God
or damage that results from a deliberate
act or negligence on the part of the
customer, owner, installer or third party.
IMPLEMENTATION OF
WARRANTY
In the event of a claim, the Customer
must present a valid proof of purchase,
namely the invoice and delivery slip(s).
Casey Concrete will supply, free of
charge, a new product in replacement of
the defective one if necessary, following
inspection of the product by Casey
Concrete or one of its representatives or
agents. Installation expenses remain the
responsibility of the Customer.
TRANSFERABILITY
The warranty is transferable to the
current owner or to any subsequent
owner of the building or the job, on the
condition that it is accompanied by a
valid proof of purchase and certificate
of warranty.
27
26
000521
Amherst NS
T: 902 667 3395
Bouctouche NB
T: 902 743 6472
Trenton NS
T: 902 755 5550
Antigonish NS
T: 902 863 7070
East Hants NS
T: 902 758 2775
Truro NS
T: 902 895 1618
Bedford NS
T: 902 835 9199
Moncton NB
T: 506 867 0888
Wallace NS
T: 902 257 2010
Bedford (Casey-Metro Ltd.)
East Hants
Truro
Antigonish
Trenton
Wallace
Bouctouche
Moncton
Amherst
caseyltd.ca
For more info
