Visually Appealing Yet Cost-Effective
Key Features:
Lumen packages
3400L - 2' x 2'
4000L - 1' x 4' and 2' x 4'
Long-life LEDs maintain 70% of their lumen output at 60,000 hours
0-10V driver with 10% dimming
MVOLT 120-277V standard
EPANL Series
Fully-Luminous LED Flat Panel
The EPANL is a visually stunning, low profile, easy to install luminaire.
The fully luminous lens provides a glare free solution creating a very
comfortable environment. Add in standard 0-10V dimming and you can create
the right amount of light for the space or task. With a depth of only two inches,
restricted plenum space is no longer a concern. The EPANL luminaire is easy
to install with great features making it ideal for many different applications.
The EPANL is available in two lumen packages and three sizes with unmatched
configurations and an advantageous specification locker for a versatile solution
that is DLC qualified (Standard and Premium) and eligible for utility rebates.
Commercial Indoor
One Lithonia Way, Conyers, GA 30012 | Phone: 800.315.4935 | www.acuitybrands.com
© 2017 Acuity Brands Lighting, Inc. All Rights Reserved. | LL _5796_1217
Visit www.lithonia.com for more information.
EPANL Series LED Luminaire
Ordering Information
EPANL Series Stock Solutions
Description* Catalog # UPC Code CI Code Wattage Pallet Quantity
2'x2' EPANL, 3400 Lumens, 3500K EPANL 22 34L 35K 190887602647 *247U4U 31 26
2'x2' EPANL, 3400 Lumens, 3500K, High Efficiency EPANL 22 34LHE 35K 190887602661 *247U4W 26 26
2'x2' EPANL, 3400 Lumens, 4000K EPANL 22 34L 40K 190887602678 *247U4X 31 26
2'x2' EPANL, 3400 Lumens, 4000K, High Efficiency EPANL 22 34LHE 40K 190887602685 *247U4Y 26 26
2'x4' EPANL, 4000 Lumens, 3500K EPANL 24 40L 35K 190887602692 *247U50 39 13
2'x4' EPANL, 4000 Lumens, 3500K, High Efficiency EPANL 24 40LHE 35K 190887602708 *247U51 30 13
2'x4' EPANL, 4000 Lumens, 4000K EPANL 24 40L 40K 190887602715 *247U52 39 13
2'x4' EPANL, 4000 Lumens, 4000K, High Efficiency EPANL 24 40LHE 40K 190887602722 *247U53 31 13
1'x4' EPANL, 4000 Lumens, 3500K EPANL 14 40L 35K 190887602739 *247U54 39 39
1'x4' EPANL, 4000 Lumens, 3500K, High Efficiency EPANL 14 40LHE 35K 190887602746 *247U55 31 39
1'x4' EPANL, 4000 Lumens, 4000K EPANL 14 40L 40K 190887602753 *247U56 39 39
1'x4' EPANL, 4000 Lumens, 4000K, High Efficiency EPANL 14 40LHE 40K 190887602760 *247U57 30 39
EXAMPLE: EPANL 24 40L 35K
*nominal lumen values
Shallow depth 0.64” panel, 2” height
including the driver box
Superior frame design, no light leakage
IP5x rated for bug and dust protection
Fully luminous, glare free surface
Surface Mount and Suspension
Mounting kit options available*
nLight enabled options*
Emergency driver options*
Pre-wire whips*
*Refer to the configurable Spec Sheet on the
product web page for ordering information.
5
YEAR
L
I
M
I
T
E
D
W
A
R
R
A
N
T
Y
L
I
M
I
T
E
D
W
A
R
R
A
N
T
Y
L
I
M
I
T
E
D
W
A
R
R
A
N
T
Y
DesignLights Consortium
®
(DLC) qualified product. Not all versions of this
product may be DLC qualified. Please check the DLC Qualified Products
List at www.designlights.org/QPL to confirm which versions are qualified.
2X2SMK
D
I
M
M
A
B
L
E
TM
Accessories: Order as separate catalog number
2X2SMK 2' x 2' Surface Mount Kit
2X4SMK 2' x 4' Surface Mount Kit
1X4SMK 1' x 4' Surface Mount Kit
LED EPANL
Catalog
Number
Notes
Type
FEATURES & SPECIFICATIONS
INTENDED USE The EPANL Series LED Edge-Lit Flat Panel provides a fully luminous appearance
across the face of the lens. This provides a soft, glare-free solution that is visually comfortable within
the space. Suitable for many lighting applications including schools, offices and other commercial spaces,
retail, convenience stores, hospitals and healthcare facilities. Certain airborne contaminants can
diminish the integrity of acrylic and/or polycarbonate. Click here for Acrylic-Polycarbonate
Compatibility table for suitable uses.
CONSTRUCTION — Built to last with an aluminum frame for strength and durability, the seamless frame
prevents light leak in the corners. The satin white lens provides excellent shielding and fully luminous
appearance. EPANL's low-profile design provides increased installation flexibility especially in restricted
plenum spaces. The back plate includes integral T-bar clips for installation exclusively into 15/16” T-grid
ceilings. Fixture may be mounted and wired in continuous rows.
ELECTRICAL Long-life LEDs, coupled with a high-efficiency driver, provide superior illumination
for extended service life. 70% LED lumen maintenance at 60,000 hours (L70/60,000). 0-10V dimming
driver, dims to 10%.
LISTINGS CSA certified to meet US and Canadian standards. DesignLights Consortium® (DLC) Premium
qualified product. Not all versions of this product may be DLC Premium qualified. Please check the DLC
Qualified Products List at www.designlights.org/QPL to confirm which versions are qualified. Damp
location listed. IC rated. IP5X rated.
WARRANTY — 5-year limited warranty. Complete warranty terms located at:
www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
Note: Actual performance may differ as a result of end-user environment and application.
All values are design or typical values, measured under laboratory conditions at 25 °C.
Specifications subject to change without notice.
EPANL LED
1' x 4', 2' x 2'and 2' x 4'
ORDERING INFORMATION
Catalog Number UPC Description Lumens Color Temperature CRI Voltage Wattage Efficacy Pallet Qty. Standard Carton Qty.
EPANL 14 40L 35K 190887602739 1x4 Flat Panel 3905 3500K >80 120-277V 38.6W 101 39 1
EPANL 14 40LHE 35K 190887602746 1x4 Flat Panel 3922 3500K >80 120-277V 30.6W 128 39 1
EPANL 14 40L 40K 190887602753 1x4 Flat Panel 4397 4000K >80 120-277V 38.5W 114 39 1
EPANL 14 40LHE 40K 190887602760 1x4 Flat Panel 3857 4000K >80 120-277V 30.2W 128 39 1
EPANL 22 34L 35K 190887602647 2x2 Flat Panel 3285 3500K >80 120-277V 31.3W 105 26 1
EPANL 22 34LHE 35K 190887602661 2x2 Flat Panel 3357 3500K >80 120-277V 26.0W 129 26 1
EPANL 22 34L 40K 190887602678 2x2 Flat Panel 3479 4000K >80 120-277V 30.8W 113 26 1
EPANL 22 34LHE 40K 190887602685 2x2 Flat Panel 3361 4000K >80 120-277V 25.9W 130 26 1
EPANL 24 40L 35K 190887602692 2x4 Flat Panel 4039 3500K >80 120-277V 38.8W 104 13 1
EPANL 24 40LHE 35K 190887602708 2x4 Flat Panel 3953 3500K >80 120-277V 30.3W 130 13 1
EPANL 24 40L 40K 190887602715 2x4 Flat Panel 4351 4000K >80 120-277V 38.9W 112 13 1
EPANL 24 40LHE 40K 190887602722 2x4 Flat Panel 4013 4000K >80 120-277V 30.7W 131 13 1
[2.19 in] 55.50 mm
[11.85 in] 301.00 mm
2.19 in [55.50 mm]
23.70 in [602.00 mm]
Notes:
1. Please refer to Emergency Battery Delivered
Lumen section for lumen caculation.
http://www.acuitybrands.com/products/detail/753016/Lithonia-Lighting/
EPANL-Flat-Panel/EPANL-Fully-Luminous-Flat-Panel/specification-sheets
EPANL 22 34L 40K (2x2), EPANL 24 40L 40K (2x4)
EPANL LED Flat Panel
EPANL
LED: One Lithonia Way Conyers, GA 30012 Phone: 800-858-7763 www.acuitybrands.com © 2017-2018 Acuity Brands Lighting, Inc. All rights reserved. Rev. 01/24/18
ACCESSORIES
Accessories: Order as separate catalog number. Options:
DGA14 Drywall grid adapter for 1x4
recessed fixture.
DGA22 Drywall grid adapter for 2x2
recessed fixture.
DGA24 Drywall grid adapter for 2x4
recessed fixture.
PS1050DL EMI Power Sentry emergency
battery pack field installation
kit (Not CEC compliant).
1
PS1050DL EMI T20C Power Sentry emergency
battery pack field installation
kit for T20 CEC compliance.
1
2X2SMK 2'x2' Surface Mount Troffer Kit
2X4SMK 2'x4' Surface Mount Troffer Kit
1X4SMK 1'x4' Surface Mount Troffer Kit
PANLACG__ EPANL adjustable aircraft cable gripper suspension kit
(specify length as 36 or 72 inches) (specify ceiling type F1 or
F2 - see mounting data); for 1x4 & 2x2 fixtures
PANLACGF__ EPANL adjustable aircraft cable gripper with power feed
(specify length as 36 or 72 inches) (specify ceiling type F1 or
F2 - see mounting data); for 1x4 & 2x2 fixtures
PANLACGE__ EPANL adjustable aircraft cable gripper with emergency
power feed(specify length as 36 or 72 inches) (specify ceiling
type F1 or F2 - see mounting data); for 1x4 & 2x2 fixtures
2X4PANLACG__ EPANL adjustable aircraft cable gripper suspension kit
(specify length as 36 or 72 inches) (specify ceiling type F1 or
F2 - see mounting data); for 2x4 fixtures
2X4PANLACGF__ EPANL adjustable aircraft cable gripper with power feed
(specify length as 36 or 72 inches) (specify ceiling type F1 or
F2 - see mounting data); for 2x4 fixtures
2X4PANLACGE__ EPANL adjustable aircraft cable gripper with emergency
power feed(specify length as 36 or 72 inches) (specify ceiling
type F1 or F2 - see mounting data); for for 2x4 fixtures
WPLT 54” x 54” pallet;
doubles pallet QTY.
Emergency Battery Delivered Lumens
Use the formula below to determine the
delivered lumens in emergency mode
Delivered Lumens = 1.25 x P x LPW
P = Output power of emergency driver (10W
for PS1050DL)
LPW = Lumen per watt rating of the luminaire.
EPANL LED Flat Panel
PHOTOMETRICS
EPANL 14 40L 40K, 4397 delivered lumens, tested in accordance to IESNA LM-79.
EPANL 22 34L 40K, 3479 delivered lumens, tested in accordance to IESNA LM-79.
EPANL 24 40L 40K, 4351 delivered lumens, tested in accordance to IESNA LM-79.
20°
40°
60°
80°
90°
90°
180°
200
400
600
800
1000
1200
1400
Coefficients of Utilization
pf 20%
pc 80% 70% 50%
pw 70%50%30% 50%30%10% 50%30%10%
121
110
100
91
84
77
71
66
61
57
54
121
106
92
81
71
64
57
52
47
43
40
121
101
85
72
62
55
48
43
39
35
32
118
103
90
79
70
62
56
51
47
43
40
118
99
83
71
62
54
48
43
38
35
32
118
95
78
65
55
47
41
37
33
29
27
112
98
86
76
67
60
54
49
45
41
38
112
95
81
69
60
53
47
42
38
34
31
112
92
76
64
54
47
41
36
32
29
26
RCR
0
1
2
3
4
5
6
7
8
9
10
Zonal Lumen Summary
Zone Lumens % Lamp % Fixture
0° - 30°
0° - 40°
0° - 60°
0° - 90°
90° - 120°
90° - 130°
90° - 150°
90° - 180°
0° - 180°
1092
1789
3158
4007
26
37
57
72
4079
27.3
44.7
79.0
100.2
0.7
0.9
1.4
1.8
102.0
26.8
43.8
77.4
98.2
0.6
0.9
1.4
1.8
100.0
CP Summary
90
15°
25°
35°
45°
55°
65°
75°
85°
90
1407
1418
1400
1324
1188
1001
773
523
269
60
6
1408
1401
1350
1251
1109
931
726
500
269
70
6
20°
40°
60°
80°
90°
90°
180°
200
400
600
800
1000
1200
Coefficients of Utilization
pf 20%
pc 80% 70% 50%
pw 70%50%30% 50%30%10% 50%30%10%
119
109
99
90
82
76
70
65
60
56
53
119
104
91
79
70
63
57
51
47
43
40
119
100
84
71
62
54
48
43
38
35
32
116
102
89
78
69
62
56
51
46
42
39
116
98
82
70
61
53
47
42
38
35
32
116
94
77
64
54
47
41
36
32
29
26
111
97
85
75
67
60
54
49
45
41
38
111
94
80
68
59
52
46
41
37
34
31
111
91
75
63
54
46
41
36
32
29
26
RCR
0
1
2
3
4
5
6
7
8
9
10
Zonal Lumen Summary
Zone Lumens % Lamp % Fixture
0° - 30°
0° - 40°
0° - 60°
0° - 90°
90° - 120°
90° - 130°
90° - 150°
90° - 180°
0° - 180°
945
1542
2704
3425
1
2
3
3
3429
27.6
45.0
78.9
99.9
0.0
0.0
0.1
0.1
100.0
27.6
45.0
78.9
99.9
0.0
0.0
0.1
0.1
100.0
CP Summary
90
15°
25°
35°
45°
55°
65°
75°
85°
90
1226
1222
1178
1089
963
805
626
437
240
66
1
1226
1221
1176
1085
956
796
612
415
216
49
0
20°
40°
60°
80°
90°
90°
180°
200
400
600
800
1000
1200
1400
Coefficients of Utilization
pf 20%
pc 80% 70% 50%
pw 70%50%30% 50%30%10% 50%30%10%
119
109
98
90
82
75
69
64
60
56
52
119
104
90
79
70
62
56
51
46
42
39
119
99
83
71
61
53
47
42
37
34
31
116
101
88
77
68
61
55
50
45
42
38
116
97
82
69
60
52
46
41
37
34
31
116
94
76
63
53
46
40
35
31
28
25
111
97
85
74
66
59
53
48
44
40
37
111
94
79
68
58
51
45
40
36
33
30
111
91
74
62
53
45
40
35
31
28
25
RCR
0
1
2
3
4
5
6
7
8
9
10
Zonal Lumen Summary
Zone Lumens % Lamp % Fixture
0° - 30°
0° - 40°
0° - 60°
0° - 90°
90° - 120°
90° - 130°
90° - 150°
90° - 180°
0° - 180°
1111
1845
3327
4263
3
3
4
4
4267
26.1
43.3
78.0
99.9
0.1
0.1
0.1
0.1
100.0
26.0
43.2
78.0
99.9
0.1
0.1
0.1
0.1
100.0
CP Summary
90
15°
25°
35°
45°
55°
65°
75°
85°
90
1397
1399
1393
1370
1275
1087
852
594
326
90
5
1397
1370
1288
1172
1027
856
659
446
223
42
0
EPANL compatible with Sensor Switch™
WSX-D and SPOD wall switches.
WSX-D SPOD
EPANL
LED: One Lithonia Way Conyers, GA 30012 Phone: 800-858-7763 www.acuitybrands.com © 2017-2018 Acuity Brands Lighting, Inc. All rights reserved. Rev. 01/24/18
EPANL
LED: One Lithonia Way Conyers, GA 30012 Phone: 800-858-7763 www.acuitybrands.com © 2017-2018 Acuity Brands Lighting, Inc. All rights reserved. Rev. 01/24/18
EPANL LED Flat Panel
DIMENSIONS
MOUNTING DATA
23.70
2.42
.50
23.70
23.70
6.53
12.44
.79 1.07
2.42in
61.53mm
23.70in
602mm
47.72
.50
2.45
11.85
47.72
12.82 13.06
1.00
6.12
11.85in
301mm
2.447in
62.16mm
2.42
.50
47.72
47.72
23.70
12.44
6.53
12.82
13.06
23.70in
602mm
2.42in
61.53mm
47.72 in [1212.00 mm]
11.85 in [301.00 mm]
23.70 in [602.00 mm]
23.70 in [602.00 mm]
23.70 in [602.00 mm]
0.50 in [12.60 mm]
2.19 in [55.50 mm]
8.20 in [208.24 mm]
9.31 in [236.59 mm]
23.70 in [602.00 mm]
23.70 in [602.00 mm]
2.19 in [55.50 mm]
23.70 in [602.00 mm]
Ø0.24 in [6.00 mm] SUSPENSION OPTION LOCATIONS4x
23.70 in [602.00 mm]
47.72 in [1212.00 mm]
47.72 in [1212.00 mm] 0.50 in [12.60 mm]
2.19 in [55.50 mm]
47.72 in [1212.00 mm]
23.70 in [602.00 mm]
9.31 in [236.59 mm]
19.10 in [485.19 mm]
23.70 in [602.00 mm]
2.19 in [55.50 mm]
31.30 in [795.00 mm]
21.89 in [555.90 mm]
Ø0.24 in [6.00 mm]4X
SUSPENSION OPTION LOCATIONS
Suspension Kit Ceiling Types:
F1 for use with most T-bar and screw slot grid ceiling applications. Designed for on-grid and off-grid installations.
F2 for use with recessed or surface-mount horizontal J-box applications.
Example Configurations: PANLACG36 F1, PANLAGF36 F2, PANLAGE72 F1, etc.
For 2X2 and 1X4, use two kits per fixture. Single kit utilizes “Y” split cable to allow for connection with 2 suspension points on one end of the fixture.
For 2X4 fixtures, use four kits per fixture. Single cable to allow for connection with single suspension point of the four on the fixture.
